• The same compact size (width: 55 mm) for all models from 0.1
to 0.4 kW
• Simplified installation using DIN Track. No mounting brackets
required.
• Mount side-by-side (ambient temperature: 45°C max.).
• Easy-to-wire main circuits.
• Models with CompoWay/F communications also available.
• Control mode easily set by simply selecting an application.
• Built-in inrush current suppression circuit.
• Accumulated operating time function for preventive
maintenance of equipment
• Handles temperature controller voltage output signals.
• Conforms to international standards (CE (TÜV certified).
Model Number Structure
■
Model Number Legend
3G3JE-A2@@@@-@@@
1 2
3
4
5
4. Braking Resistor Control
Blank: No braking resistance control
B:
Braking resistance control
5. Communications
Blank: No communications function
FLK: CompoWay/F
1. Degree of Protection
A: Panel-mounting (IP10 or higher)/Closed wall-mounting
2. Voltage Class
2: Three-phase 200 V AC
3. Maximum Applicable Motor Capacity
001: 0.1 kW
002: 0.2 kW
004: 0.4 kW
Compact Simplified Inverters
EasySpeed 3G3JE Series
1
Ordering Information
■
Inverters
Model number
Maximum motor capacity
No braking
resistance control
Standard models
Communications
models
0.1 kW
3G3JE-A2001
3G3JE-A2001-FLK
---
---
---
3G3JE-A2002B
3G3JE-A2002B-FLK
3G3JE
0.2 kW
3G3JE-A2002
---
3G3JE-A2004B
3G3JE-A2004B-FLK
0.4 kW
3G3JE-A2004
Braking resistance Standard models
control
Communications
models
■
Options (Order Separately)
Product name
Fan Unit
Specifications
Special for the 3G3JE
Model number
3G3JE-PFAN2004
Description
Replacement for the existing cooling fan in the
Inverter.
Replace the cooling fan if it has reached the
end of its service life or if a warning of cooling
fan failure (E07) is indicated.
Connect this Filter to the power input side to
suppress noise entering the Inverter from the
power line and reduce noise leaking from the
Inverter into the power line.
Input Noise Filter
For three-phase 200 V
3G3AX-NFI22
2
Compact Simplified Inverters
EasySpeed
3G3JE Series
Specifications
■
Ratings
Item
Power
supply
Three-phase 200-V AC models
(3G3JE)
Rated voltage and power supply
Allowable voltage fluctuation
Allowable frequency fluctuation
Input power supply capacity (kVA) (See note 1.)
Heat radiation (W) (See note 2.)
Approximate weight (kg)
Cooling method
Maximum motor capacity (kW)
Output
specifica-
tions
Rated output capacity (kVA)
Rated output current (A)
Rated output voltage (V)
Maximum output frequency
Short-circuit current rating for power output (motor output) (A)
Short-circuit designation for auxiliary circuit (braking resistor
connection)
Control
Power supply harmonics countermeasures
character-
Control method
istics
Carrier frequency
Frequency control range
Frequency precision
(temperature characteristics)
Frequency setting resolution
−15
to 10%
±5%
0.4
6.8
0.3
Self cooling
0.1
0.3
0.8
Three-phase 200 to 230 V AC
120 Hz
36
---
AC reactor
Sine wave PWM (V/f control)
4 kHz/7 kHz (switched according to setting)
0.0 to 120 Hz
±0.3%
of frequency reference (−10 to 50°C)
Digital commands:
0.1 Hz (less than 100 Hz)
1 Hz (100 Hz or greater)
Time-proportional pulse input:
±0.5%
of frequency reference
150% of rated output current for 1 min
Time-proportional pulse input
0.1 to 999 s (independent acceleration and deceleration time settings)
Approx. 20% (with no Braking Resistor connected)
Approx. 100% (with Braking Resistor connected)
Constant torque characteristics or gradually decreasing torque characteristics
(with automatic torque boost)
Protection by electronic thermal
Stops at approx. 250% of rated output current.
Stops in 1 min at approximately 150% of rated output current.
Stops when main-circuit DC voltage is approximately 410 V.
Stops when main-circuit DC voltage is approximately 200 V.
Select from not restarting (stops for interruption of 15 ms or longer), continuing operation if
power is restored within approx. 0.5 s, or continuing operation regardless of length of
interruption
Temperature is detected by a thermistor.
Protected by overcurrent protection.
Lit until the main circuit DC voltage drops to 60 V or less.
Inside a control panel (with no corrosive gas, dust, etc.)
−10
to 50°C
5% to 85% (with no condensation)
−20
to 60°C
5% to 85% (with no condensation)
1,000 m max.
5 MΩ min.
9.8 m/s
2
max.
IP20
54
No short-circuit protection
0.7
14.8
0.4
Forced cooling
0.2
0.5
1.4
0.4
1.0
2.5
1.2
21.9
0.4
A2001
Three-phase 200 to 230 V AC at 50/60 Hz
A2002
A2004
Overload capacity
External frequency set signal
Acceleration/deceleration times
Braking torque
Voltage/frequency characteristics
Protective
functions
Motor protection
Instantaneous overcurrent protection
Overcurrent protection
Overvoltage protection
Undervoltage protection
Momentary power interruption restart selection
Radiation fin overheating
Grounding protection
Charge indicator
Environ-
ment
Location
Ambient operating temperature
Ambient operating humidity
Shipping and storage temperature
Shipping and storage humidity
Altitude
Insulation resistance
Vibration resistance
Degree of protection
Note: 1.
The power supply capacity is the capacity for the Inverter's rated output. It will vary depending on the impedance at the input power supply. (The input power
supply's power factor fluctuates, so it can be improved by inserting an AC reactor.) There will also be variations in the ratio between the rated current of the
motor that is used and the rated output current of the Inverter.
2.
The heat radiation is the electric power consumed in the Inverter at the Inverter's rated output. (Calculated as the input power minus the output power during
rated operation.)
■
Certified Standards
Safety standards
EMC Directive
EN 61800-5-1 (Pollution Level 2/Overvoltage Category II)
EN61800-3
Compact Simplified Inverters
EasySpeed 3G3JE Series
3
Dimensions
Note:
All units are in millimeters unless otherwise indicated.
■
Inverter
3G3JE-A2001/-A2002/-A2004: Three-phase 200-V AC Input
Panel Mounting Dimensions
55
123.3
(including 0.3 for height of raised characters)
4.5 dia. or M4
3-Phase
AC power supply
R/L1
S/L2
T/L3
B1
B2
Hz set
Hz out
A
Kh
Brake
resistor
3-Phase
AC power supply
Brake
resistor
B1 B2
R/L1 S/L2 T/L3
RUN
RVS
ALM
COM
Hz set
Hz out
A
Kh
RUN
RVS
ALM
COM
EasySpeed
3G3JE
INVERTER
EasySpeed
3G3JE INVERTER
RUN
STOP
RESET
115
95
106
1
2
3
4
5
6
7
8
9
10
U/T1 V/T2
W/T3
Motor
U/T1 V/T2 W/T3
45
Note:
All models are the same size.
4
Compact Simplified Inverters
EasySpeed
3G3JE Series
Nomenclature and Functions
■
Indicators
Mounting holes
3-Phase
AC power supply
Brake
resistor
B1 B2
R/L1 S/L2 T/L3
Terminal cover
RUN
RVS
ALM
COM
Data display
Hz set
Hz out
A
Kh
Simple indicators
(setting/monitoring indicators)
Digital Operator
EasySpeed
3G3JE INVERTER
Keys
Motor
U/T1 V/T2 W/T3
Terminal cover
Mounting holes
■
Digital Operator Part Names
Name
Data display
Function
Displays relevant data items, such as frequency reference, output frequency, output current,
parameters, parameter set values, and accumulated operating time.
The Hz set indicator is lit when the frequency reference is displayed on the data display.
The Hz out indicator is lit when the output reference is displayed on the data display.
The A indicator is lit when the output current is displayed on the data display.
The Kh indicator is lit when the accumulated operating time is displayed on the data display.
The RUN indicator is lit while the Inverter is operating.
The RVS indicator is lit while the Inverter is operating in reverse.
The ALM indicator is lit when a fault is detected and a protective function has been triggered.
(The error contents can be monitored in RUN Mode.)
The COM indicator is lit while communications are in progress (sending or receiving).
(Communications models only.)
Switches the simple indicators (setting/monitoring indicators) in RUN Mode. When this key is
pressed for one second or longer, the mode changes from the RUN Mode to the Initial Settings
Mode.
Enters set values, display items, etc. When this key is pressed for one second or longer, the mode
changes from the RUN Mode to the Adjustment Mode.
Starts the Inverter. (This applies only when the operation using the Digital Operator has been
selected.)
Stops the Inverter. Also, clears error when an error has been detected and a protection function
has been triggered. (This applies only when the operation using the Digital Operator has been
selected.)
These keys increment or decrement the displayed set value. They also change parameters in the
