SB570 - SB5100

5.0A SCHOTTKY BARRIER RECTIFIER

Features

·

Guard Ring Die Construction for

Transient Protection

Low Power Loss, High Efficiency

High Surge Capability

High Current Capability

Surge Overload Rating to 150A Peak

For Use in Low Voltage, High Frequency Inverters, Free

Wheeling, and Polarity Protection Applications

Lead Free Finish, RoHS Compliant (Note 2)

A

B

A

C

D

Mechanical Data

·

Case: DO-201AD

Case Material: Molded Plastic. UL Flammability

Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020C

Terminals: Finish - Bright Tin. Plated Leads Solderable per

MIL-STD-202, Method 208

Polarity: Cathode Band

Ordering Information: See Last Page

Marking: Type Number

Weight: 1.1 grams (approximate)

Dim

A

B

C

D

DO-201AD

Min

25.40

7.20

1.20

4.80

Max

¾

9.50

1.30

5.30

All Dimensions in mm

Maximum Ratings and Electrical Characteristics

Single phase, half wave, 60Hz, resistive or inductive load.

For capacitive load, derate current by 20%.

Characteristic

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

RMS Reverse Voltage

Average Rectified Output Current

@ T

L

= 80°C

Non-Repetitive Peak Forward Surge Current 8.3ms

single half sine-wave superimposed on rated load

(JEDEC Method)

Forward Voltage

@ I

F

= 5.0A

Peak Reverse Current

at Rated DC Blocking Voltage

Typical Junction Capacitance

Typical Thermal Resistance Junction to Ambient

Operating and Storage Temperature Range

Notes:

@ T

A

= 25°C unless otherwise specified

Symbol

V

RRM

V

RWM

V

R

V

R(RMS)

I

O

I

FSM

V

FM

I

RM

C

j

R

qJA

T

j,

T

STG

SB570

70

49

SB580

80

56

5.0

150

0.80

0.5

50

400

10

SB590

90

63

SB5100

100

70

Unit

V

A

V

mA

pF

K/W

°C

@ T

A

= 25°C

@ T

A

= 100°C

(Note 1)

-65 to +150

1. Measured at 1.0MHz and applied reverse voltage of 4.0V DC.

2. RoHS revision 13.2.2003. Glass and High Temperature Solder Exemptions Applied, see

EU Directive Annex Notes 5 and 7.

DS30135 Rev. 5 - 2

1 of 3

www.diodes.com

SB570 - SB5100

ã

Diodes Incorporated
