F-217 (Rev 01AUG17)
HTST–08–01–L–DV
CC83L-2426-L
ISDM–15
ISSM–05
(2.54 mm) .100"
ISSM, ISDM, CC83L, CC83R, TST, HTST SERIES
DISCRETE WIRE COMPONENTS & TOOLING
SPECIFICATIONS
For complete specifications
www.samtec.com?ISSM,
www.samtec.com?ISDM
www.samtec.com?CC83R
or www.samtec.com?CC83L
TYPE
POSITIONS
PER ROW
OPTION
TYPE
WIRE
GAUGE
PLATING
OPTION
TOOLING
• Hand tool:
CAT-HT-383-2426-13
• Mini Applicator:
CAT-MA-383-2426-XX-01
• Extraction Tool:
CAT-EX-74-01
ISSM
= Single
Row
–02, –05,
–10, –15, –20
(Standard sizes)
Leave blank for no
polarization
ISDM
= Double
Row
= Keyed Polarization
(For TSS/HTSS/ZSS,
TST/HTST/ZST)
(3.81)
.150
(12.45)
.490
(1.27)
.050
(5.08)
.200
–K
CC83L
= Contact,
Loose
= 24, 26 AWG
–2426
CC83R
= Contact,
Full Reel
(7,000 Parts
per reel)
(2.03)
.080
= Gold flash
on contact,
Matte Tin
on tail
–F
–K
(2.54)
.100
(11.00)
.433
ISSM
No. of
positions
(2.54)
.100 x (2.54) .100
+ (1.27) .050
ISDM
(2.54)
.100
(1.91)
.075
(19.81)
.780
(1.57)
.062
DIA
= 10 µ"
(0.25 µm)
Gold on
contact,
Matte Tin
on tail
–L
Insulator Material:
Nylon 6/6, White
(3.81).150
Contact Material:
Phosphor Bronze
Mates with:
IDSD, SMSD
SPECIFICATIONS
For complete specifications
www.samtec.com?TST or
www.samtec.com?HTST
Insulator Material:
Black Glass Filled
Polyester (TST)
Natural PCT (HTST)
Terminal Material:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
RoHS Compliant:
Yes
TYPE
STRIP
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart.
PLATING
OPTION
ROW
OPTION
= Cable Strip
TST
= High Temp
Cable Strip
Note:
Some lengths, styles
and options are non-standard,
non-returnable.
LEAD
STYLE
–01
–02
–03
T/H
(A)
(2.92)
.115
(4.19)
.165
(14.35)
.565
(2.54) .100 x No. of Positions + (7.62) .300
(2.54) .100 x No. of Positions + (5.08) .200
HTST
05, 07, 08, 10,
12, 13, 15, 17,
20, 25, 32, 36
(Standard sizes)
= Gold flash on post,
Matte Tin on tail
(Not available on –DV)
–F
–L
–T
= Double Row
Through-hole
(lead style –01,
–02 & –03 only)
–D
= 10 µ" (0.25 µm)
Gold on post,
Matte Tin on tail
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
= Matte Tin
= Double Row
Surface Mount
(lead style
–01 only)
(HTST only)
–DV
02
OTHER
SOLUTIONS
• For other mates also
see TSW, HTSW, TSM,
MTSW, HMTSW, PHT,
TLW, MTLW, DW, EW,
ZW, HW, TSSH, TSS,
HTSS, ZSS, ZST
(9.27)
.365
01
RIGHT
LEAD ANGLE
STYLE
(B)
–04
(3.30) .130
–05
(5.84) .230
(2.54)
.100
(2.54)
.100
= Double Row
Right-angle
(lead style –04
& –05 only)
–D–RA
(8.89)
.350
(10.16)
.400
(6.35)
.250
B
(5.08)
.200
A
(0.38)
.015
(0.64) .025 SQ TYP
(11.18) .440
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
