No load condition, f = 20 MHz, Vdd = 2.5V, 2.8V or 3.3V
No load condition, f = 20 MHz, Vdd = 1.8V
Vdd = 2.5V, 2.8V, 3.3V, ST = GND, output is Weakly Pulled Down
Vdd = 1.8V, ST = GND, output is Weakly Pulled Down
See the Absolute Pull Range and APR table on
page 10
Vdd = 1.8V, Voltage at which maximum deviation is guaranteed.
Vdd = 2.5V, Voltage at which maximum deviation is guaranteed.
Vdd = 2.8V, Voltage at which maximum deviation is guaranteed.
Vdd = 3.3V, Voltage at which maximum deviation is guaranteed.
Voltage at which minimum deviation is guaranteed.
Additional supply voltages between 2.5V and 3.3V can be
supported. Contact
SiTime
for additional information.
Condition
Refer to
Table 11
for the exact list of supported frequencies
Inclusive of Initial tolerance
[4]
at 25 °C, and variation over
temperature, rated supply voltage and load.
10 years, 25°C
Extended Commercial
Industrial
Frequency Range
Frequency Stability and Aging
Supply Voltage and Current Consumption
VCXO Characteristics
±25, ±50, ±100, ±150, ±200
1.7
2.4
2.7
3.2
Lower Control Voltage
Control Voltage Input Impedance
Control Voltage Input Capacitance
Linearity
Frequency Change Polarity
Control Voltage Bandwidth (-3dB)
Duty Cycle
Rise/Fall Time
Output High Voltage
VC_L
Z_in
C_in
Lin
–
V_BW
DC
Tr, Tf
VOH
–
45
–
90%
–
100
–
–
–
–
–
–
–
–
5
0.1
Positive slope
8
–
1.5
–
–
–
–
–
0.1
–
–
1
Upper Control Voltage
LVCMOS Output Characteristics
Output Low Voltage
VOL
–
–
10%
Vdd
SiTime Corporation
Rev. 1.01
990 Almanor Avenue, Sunnyvale, CA 94085
SiT3807
Standard Frequency MEMS VCXO
The Smart Timing Choice
The Smart Timing Choice
Table 1. Electrical Characteristics
[1, 2, 3]
Parameter
Input Pull-up Impedance
Input Capacitance
Startup Time
OE Enable/Disable Time
Resume Time
RMS Period Jitter
RMS Phase Jitter (random)
Symbol
Z_in
C_in
T_start
T_oe
T_resume
T_jitt
T_phj
Electrical Specifications
(continued)
Min.
–
–
–
–
–
–
–
–
Typ.
100
5
–
–
7
1.5
2
0.5
Max.
250
–
10
180
10
Jitter
2
3
1
ps
ps
ps
f = 20 MHz, Vdd = 2.5V, 2.8V or 3.3V
f = 20 MHz, Vdd = 1.8V
f = 20 MHz, Integration bandwidth = 12 kHz to 20 MHz, All Vdds
Unit
kΩ
PF
ms
ns
ms
Condition
For the OE/ST pin for 6-pin devices
For the OE/ST pin for 6-pin devices
See Figure 7 for startup resume timing diagram
f = 40 MHz, all Vdds. For other freq, T_oe = 100 ns + 3 clock
periods
See Figure 8 for resume timing diagram
Input Characteristics
Startup and Resume Timing
Notes:
1. All electrical specifications in the above table are specified with 15 pF output load and for all Vdd(s) unless otherwise stated.
2. The typical value of any parameter in the Electrical Characteristics table is specified for the nominal value of the highest voltage option for that parameter and at
25 °C temperature.
3. All max and min specifications are guaranteed across rated voltage variations and operating temperature ranges, unless specified otherwise
4. Initial tolerance is measured at Vin = Vdd/2
5. Absolute Pull Range (APR) is defined as the guaranteed pull range over temperature and voltage.
6. APR = pull range (PR) - frequency stability (F_stab) - Aging (F_aging)
Rev. 1.01
Page 2 of 11
www.sitime.com
SiT3807
Standard Frequency MEMS VCXO
The Smart Timing Choice
The Smart Timing Choice
Table 2. Pin Description. 4-Pin Configuration
(For 2.5 x 2.0 mm and 3.2 x 2.5 mm packages)
Pin
1
2
3
4
Symbol
VIN
GND
CLK
VDD
Input
Power
Power
Input
Power
Electrical ground
Power supply voltage
Oscillator output power
[7]
GND
2
3
Top View
Functionality
VIN
1
4
0-Vdd: produces voltage dependent frequency change
VDD
CLK
Note:
7. A capacitor value of 0.1 µF between VDD and GND is recommended.
Figure 1.
Table 3. Pin Description. 6-Pin Configuration
(For 5.0 x 3.2 mm and 7.0 x 5.0 mm packages)
Pin
1
Symbol
VIN
Input
No
Connect
2
NC/OE/ ST
Output
Enable
Standby
3
4
5
6
GND
CLK
NC
VDD
Power
Output
No
Connect
Power
Functionality
0-Vdd: produces voltage dependent frequency change
H or L or Open: No effect on output frequency or other device
functions
H or Open
[8]
: specified frequency output
L: output is high
H or Open
[8]
: specified frequency output
L: output is low (weak pull down)
[9]
. Oscillation stops
Electrical ground
Oscillator output
H or L or Open: No effect on output frequency or other device
functions
Power supply
voltage
[10]
VIN
NC/OE/ST
GND
1
6
Top View
VDD
NC
CLK
2
5
3
4
Figure 2.
Notes:
8. In OE or ST mode, a pull-up resistor of 10 kΩ or less is recommended if pin 2 in the 6-pin package is not externally driven. If pin 2 needs to be left floating, use
the NC option
9. Typical value of the weak pull-down impedance is 5 mΩ
10. A capacitor value of 0.1 µF between VDD and GND is recommended.
Table 4. Absolute Maximum Limits
Attempted operation outside the absolute maximum ratings may cause permanent damage to the part. Actual performance of
the IC is only guaranteed within the operational specifications, not at absolute maximum ratings.
Parameter
Storage Temperature
VDD
Electrostatic Discharge
Soldering Temperature (follow standard Pb free soldering guidelines)
Min.
-65
-0.5
–
–
Max.
150
4
2000
260
Unit
°C
V
V
°C
Table 5. Thermal Consideration
Parameter
7050
5032
3225
2520
JA, 4 Layer Board
(°C/W)
191
97
109
117
JA, 2 Layer Board
(°C/W)
263
199
212
222
JC, Bottom
(°C/W)
30
24
27
26
Table 6. Environmental Compliance
Parameter
Mechanical Shock
Mechanical Vibration
Temperature Cycle
Solderability
Moisture Sensitivity Level
Rev. 1.01
Condition/Test Method
MIL-STD-883F, Method 2002
MIL-STD-883F, Method 2007
JESD22, Method A104
MIL-STD-883F, Method 2003
MSL1 @ 260°C
Page 3 of 11
www.sitime.com
SiT3807
Standard Frequency MEMS VCXO
The Smart Timing Choice
The Smart Timing Choice
Phase Noise Plot
-100
-110
-120
-130
-140
-150
-160
-170
3
10
Integrated random phase jitter (RMS, 12kHz-5MHz): 0.52ps
