GS81302DT19GE-400 datasheet, PDF

Datasheet> All Categories > semiconductor> Memory IC> Static random access memory> GS81302DT19GE-400

GS81302DT19GE-400: DescriptionStatic random access memory 1.8 or 1.5V 8M x 18 144M; Categorysemiconductor Memory IC Static random access memory; File Size2MB，31 Pages; ManufacturerGSI Technology; Websitehttp://www.gsitechnology.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

GS81302DT19GE-400 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	GS81302DT19GE-400	-	-	View	Buy Now

GS81302DT19GE-400 Overview

Static random access memory 1.8 or 1.5V 8M x 18 144M

GS81302DT19GE-400 Parametric

Parameter Name	Attribute value
Maker	GSI Technology
Product Category	static random access memory
storage	144 Mbit
organize	8 M x 18
maximum clock frequency	400 MHz
Interface Type	Parallel
Supply voltage - max.	1.9 V
Supply voltage - min.	1.7 V
Supply current—max.	1.055 A
Minimum operating temperature	0 C
Maximum operating temperature	+ 70 C
Installation style	SMD/SMT
Package/box	BGA-165
Encapsulation	Tray
storage type	QDR-II
series	GS81302DT19GE
type	SigmaQuad-II+ B4
Factory packaging quantity	10

Preview

Download Datasheet

View All

GS81302DT07/10/19/37E-450/400/350/333/300

165-Bump BGA

Commercial Temp

Industrial Temp

Features

• 2.0 clock Latency

• Simultaneous Read and Write SigmaQuad™ Interface

• JEDEC-standard pinout and package

• Dual Double Data Rate interface

• Byte Write controls sampled at data-in time

• Burst of 4 Read and Write

• Dual-Range On-Die Termination (ODT) on Data (D), Byte

Write (BW), and Clock (K, K) inputs

• 1.8 V +100/–100 mV core power supply

• 1.5 V or 1.8 V HSTL Interface

• Pipelined read operation

• Fully coherent read and write pipelines

• ZQ pin for programmable output drive strength

• Data Valid Pin (QVLD) Support

• IEEE 1149.1 JTAG-compliant Boundary Scan

• 165-bump, 15 mm x 17 mm, 1 mm bump pitch BGA package

• RoHS-compliant 165-bump BGA package available

144Mb SigmaQuad-II+

Burst of 4 SRAM

450 MHz–300 MHz

1.8 V V

1.8 V and 1.5 V I/O

are just one element in a family of low power, low voltage

HSTL I/O SRAMs designed to operate at the speeds needed to

implement economical high performance networking systems.

Clocking and Addressing Schemes

The GS81302DT07/10/19/37E SigmaQuad-II+ SRAMs are

synchronous devices. They employ two input register clock

inputs, K and K. K and K are independent single-ended clock

inputs, not differential inputs to a single differential clock input

buffer.

Each internal read and write operation in a SigmaQuad-II+ B4

RAM is four times wider than the device I/O bus. An input

data bus de-multiplexer is used to accumulate incoming data

before it is simultaneously written to the memory array. An

output data multiplexer is used to capture the data produced

from a single memory array read and then route it to the

appropriate output drivers as needed. Therefore the address

field of a SigmaQuad-II+ B4 RAM is always two address pins

less than the advertised index depth (e.g., the 16M x 8 has a

4M addressable index).

SigmaQuad™ Family Overview

The GS81302DT07/10/19/37E are built in compliance with

the SigmaQuad-II+ SRAM pinout standard for Separate I/O

synchronous SRAMs. They are 150,994,944-bit (144Mb)

SRAMs. The GS81302DT07/10/19/37E SigmaQuad SRAMs

Parameter Synopsis

-450

tKHKH

tKHQV

2.2 ns

0.45 ns

-400

2.5 ns

0.45 ns

-350

2.86 ns

0.45 ns

-333

3.0 ns

0.45 ns

-300

3.3 ns

0.45 ns

Rev: 1.00b 8/2017

1/30

Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.

GS81302DT19GE-400 Related Products

	GS81302DT19GE-400	GS81302DT19GE-300	GS81302DT37GE-300I	GS81302DT19E-333I	GS81302DT10E-350	GS81302DT19GE-400I	GS81302DT19GE-350I	GS81302DT10GE-450I	GS81302DT10GE-450
Description	Static random access memory 1.8 or 1.5V 8M x 18 144M	Static random access memory 1.8 or 1.5V 8M x 18 144M	Static random access memory 1.8 or 1.5V 4M x 36 144M	Static random access memory 1.8 or 1.5V 8M x 18 144M	Static random access memory 1.8 or 1.5V 16M x 9 144M	Static random access memory 1.8 or 1.5V 8M x 18 144M	Static random access memory 1.8 or 1.5V 8M x 18 144M	Static random access memory 1.8 or 1.5V 16M x 9 144M	Static random access memory 1.8 or 1.5V 16M x 9 144M
Maker	GSI Technology	GSI Technology	GSI Technology	GSI Technology	GSI Technology	GSI Technology	GSI Technology	GSI Technology	GSI Technology
organize	8 M x 18	8MX18	4MX36	8MX18	16MX9	8MX18	8MX18	16MX9	16MX9
Minimum operating temperature	0 C	-	-40 °C	-40 °C	-	-40 °C	-40 °C	-40 °C	-
Maximum operating temperature	+ 70 C	70 °C	85 °C	85 °C	70 °C	85 °C	85 °C	85 °C	70 °C
Is it lead-free?	-	Lead free	Lead free	Contains lead	Contains lead	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	-	conform to	conform to	incompatible	incompatible	conform to	conform to	conform to	conform to
Parts packaging code	-	BGA	BGA	BGA	BGA	BGA	BGA	BGA	BGA
package instruction	-	LBGA,	LBGA,	LBGA,	LBGA,	LBGA,	LBGA,	LBGA,	LBGA,
Contacts	-	165	165	165	165	165	165	165	165
Reach Compliance Code	-	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant
ECCN code	-	3A991.B.2.B	3A991.B.2.B	3A991.B.2.B	3A991.B.2.B	3A991.B.2.B	3A991.B.2.B	3A991.B.2.B	3A991.B.2.B
Factory Lead Time	-	12 weeks	12 weeks	12 weeks	12 weeks	12 weeks	12 weeks	12 weeks	12 weeks
Maximum access time	-	0.45 ns	0.45 ns	0.45 ns	0.45 ns	0.45 ns	0.45 ns	0.45 ns	0.45 ns
Other features	-	PIPELINED ARCHITECTURE	PIPELINED ARCHITECTURE	PIPELINED ARCHITECTURE	PIPELINED ARCHITECTURE	PIPELINED ARCHITECTURE	PIPELINED ARCHITECTURE	PIPELINED ARCHITECTURE	PIPELINED ARCHITECTURE
JESD-30 code	-	R-PBGA-B165	R-PBGA-B165	R-PBGA-B165	R-PBGA-B165	R-PBGA-B165	R-PBGA-B165	R-PBGA-B165	R-PBGA-B165
JESD-609 code	-	e1	e1	-	-	e1	e1	e1	e1
length	-	17 mm	17 mm	17 mm	17 mm	17 mm	17 mm	17 mm	17 mm
memory density	-	150994944 bit	150994944 bit	150994944 bit	150994944 bit	150994944 bit	150994944 bit	150994944 bit	150994944 bit
Memory IC Type	-	QDR SRAM	QDR SRAM	QDR SRAM	QDR SRAM	QDR SRAM	QDR SRAM	QDR SRAM	QDR SRAM
memory width	-	18	36	18	9	18	18	9	9
Humidity sensitivity level	-	3	3	-	-	3	3	3	3
Number of functions	-	1	1	1	1	1	1	1	1
Number of terminals	-	165	165	165	165	165	165	165	165
word count	-	8388608 words	4194304 words	8388608 words	16777216 words	8388608 words	8388608 words	16777216 words	16777216 words
character code	-	8000000	4000000	8000000	16000000	8000000	8000000	16000000	16000000
Operating mode	-	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS
Package body material	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	-	LBGA	LBGA	LBGA	LBGA	LBGA	LBGA	LBGA	LBGA
Package shape	-	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	-	GRID ARRAY, LOW PROFILE	GRID ARRAY, LOW PROFILE	GRID ARRAY, LOW PROFILE	GRID ARRAY, LOW PROFILE	GRID ARRAY, LOW PROFILE	GRID ARRAY, LOW PROFILE	GRID ARRAY, LOW PROFILE	GRID ARRAY, LOW PROFILE
Parallel/Serial	-	PARALLEL	PARALLEL	PARALLEL	PARALLEL	PARALLEL	PARALLEL	PARALLEL	PARALLEL
Peak Reflow Temperature (Celsius)	-	260	260	NOT SPECIFIED	NOT SPECIFIED	260	260	260	260
Certification status	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	-	1.5 mm	1.5 mm	1.5 mm	1.5 mm	1.5 mm	1.5 mm	1.5 mm	1.5 mm
Maximum supply voltage (Vsup)	-	1.9 V	1.9 V	1.9 V	1.9 V	1.9 V	1.9 V	1.9 V	1.9 V
Minimum supply voltage (Vsup)	-	1.7 V	1.7 V	1.7 V	1.7 V	1.7 V	1.7 V	1.7 V	1.7 V
Nominal supply voltage (Vsup)	-	1.8 V	1.8 V	1.8 V	1.8 V	1.8 V	1.8 V	1.8 V	1.8 V
surface mount	-	YES	YES	YES	YES	YES	YES	YES	YES
technology	-	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	-	COMMERCIAL	INDUSTRIAL	INDUSTRIAL	COMMERCIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	COMMERCIAL
Terminal surface	-	Tin/Silver/Copper (Sn/Ag/Cu)	Tin/Silver/Copper (Sn/Ag/Cu)	-	-	Tin/Silver/Copper (Sn/Ag/Cu)	Tin/Silver/Copper (Sn/Ag/Cu)	Tin/Silver/Copper (Sn/Ag/Cu)	Tin/Silver/Copper (Sn/Ag/Cu)
Terminal form	-	BALL	BALL	BALL	BALL	BALL	BALL	BALL	BALL
Terminal pitch	-	1 mm	1 mm	1 mm	1 mm	1 mm	1 mm	1 mm	1 mm
Terminal location	-	BOTTOM	BOTTOM	BOTTOM	BOTTOM	BOTTOM	BOTTOM	BOTTOM	BOTTOM
Maximum time at peak reflow temperature	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
width	-	15 mm	15 mm	15 mm	15 mm	15 mm	15 mm	15 mm	15 mm
