GS81314PT36GK-120 datasheet, PDF

Datasheet> All Categories > semiconductor> Memory IC> Static random access memory> GS81314PT36GK-120

GS81314PT36GK-120: DescriptionStatic random access memory 1.2/1.25V 4M x 36 144M; Categorysemiconductor Memory IC Static random access memory; File Size273KB，40 Pages; ManufacturerGSI Technology; Websitehttp://www.gsitechnology.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

GS81314PT36GK-120 Overview

Static random access memory 1.2/1.25V 4M x 36 144M

GS81314PT36GK-120 Parametric

Parameter Name	Attribute value
Maker	GSI Technology
Product Category	static random access memory
storage	144 Mbit
organize	4 M x 36
maximum clock frequency	1.2 GHz
Interface Type	Parallel
Supply voltage - max.	1.35 V
Supply voltage - min.	1.2 V
Supply current—max.	2.75 A
Minimum operating temperature	0 C
Maximum operating temperature	+ 85 C
Installation style	SMD/SMT
Package/box	BGA-260
Encapsulation	Tray
storage type	DDR-IV
series	GS81314PT36GK
type	SigmaDDR-IVe B2
Factory packaging quantity	10

Preview

Download Datasheet

View All

GS81314PT18/36GK-133/120/106

260-Pin BGA

Com & Ind Temp

POD I/O

Features

•

4Mb x 36 and 8Mb x 18 organizations available

Organized as 16 logical memory banks

1333 MHz maximum operating frequency

1.333 BT/s peak transaction rate (in billions per second)

96 Gb/s peak data bandwidth (in x36 devices)

Common I/O DDR Data Bus

Non-multiplexed SDR Address Bus

One operation - Read or Write - per clock cycle

Certain address/bank restrictions on Read and Write ops

Burst of 2 Read and Write operations

6 cycle Read Latency

On-chip ECC with virtually zero SER

Loopback signal timing training capability

1.25V ~ 1.3V nominal core voltage

1.2V ~ 1.3V POD I/O interface

Configuration registers

Configurable ODT (on-die termination)

ZQ pin for programmable driver impedance

ZT pin for programmable ODT impedance

IEEE 1149.1 JTAG-compliant Boundary Scan

260-pin, 14 mm x 22 mm, 1 mm ball pitch, 6/6 RoHS-

compliant BGA package

144Mb SigmaDDR-IVe™

Burst of 2 Multi-Bank ECCRAM™

Clocking and Addressing Schemes

Up to 1333 MHz

1.25V ~ 1.3V V

1.2V ~ 1.3V V

DDQ

The GS81314PT18/36GK SigmaDDR-IVe ECCRAMs are

synchronous devices. They employ three pairs of positive and

negative input clocks; one pair of master clocks, CK and CK,

and two pairs of write data clocks, KD[1:0] and KD[1:0]. All

six input clocks are single-ended; that is, each is received by a

dedicated input buffer.

CK and CK are used to latch address and control inputs, and to

control all output timing. KD[1:0] and KD[1:0] are used solely

to latch data inputs.

Each internal read and write operation in a SigmaDDR-IVe B2

ECCRAM is two times wider than the device I/O bus. An input

data bus de-multiplexer is used to accumulate incoming data

before it is simultaneously written to the memory array. An

output data multiplexer is used to capture the data produced

from a single memory array read and then route it to the

appropriate output drivers as needed. Therefore, the address

field of a SigmaDDR-IVe B2 ECCRAM is always one address

pin less than the advertised index depth (e.g. the 8M x 18 has

4M addressable index).

On-Chip Error Correction Code

GSI's ECCRAMs implement an ECC algorithm that detects

and corrects all single-bit memory errors, including those

induced by SER events such as cosmic rays, alpha particles,

etc. The resulting Soft Error Rate of these devices is

anticipated to be <0.002 FITs/Mb — a 5-order-of-magnitude

improvement over comparable SRAMs with no on-chip ECC,

which typically have an SER of 200 FITs/Mb or more.

All quoted SER values are at sea level in New York City.

SigmaDDR-IVe™ Family Overview

SigmaDDR-IVe ECCRAMs are the Common I/O half of the

SigmaQuad-IVe/SigmaDDR-IVe family of high performance

ECCRAMs. Although similar to GSI's third generation of

networking SRAMs (the SigmaQuad-IIIe/SigmaDDR-IIIe

family), these fourth generation devices offer several new

features that help enable significantly higher performance.

Parameter Synopsis

Speed Grade

-133

-120

-106

Max Operating Frequency

1333 MHz

1200 MHz

1066 MHz

Read Latency

6 cycles

1.2V to 1.35V

Rev: 1.09 5/2016

1/40

Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.

GS81314PT36GK-120 Related Products

	GS81314PT36GK-120	GS81314PT18GK-120I	GS81314PT18GK-133I	GS81314PT18GK-106	GS81314PT36GK-106	GS81314PT18GK-133	GS81314PT36GK-133I	GS81314PT36GK-106I	GS81314PT18GK-106I
Description	Static random access memory 1.2/1.25V 4M x 36 144M	SRAM 1.2/1.25V 8M x 18 144M	SRAM 1.2/1.25V 8M x 18 144M	SRAM 1.2/1.25V 8M x 18 144M	SRAM 1.2/1.25V 4M x 36 144M	SRAM 1.2/1.25V 8M x 18 144M	Static random access memory 1.2/1.25V 4M x 36 144M	Static random access memory 1.2/1.25V 4M x 36 144M	Static random access memory 1.2/1.25V 8M x 18 144M
Product Category	static random access memory	SRAM	SRAM	SRAM	SRAM	SRAM	static random access memory	static random access memory	static random access memory
Interface Type	Parallel	Parallel	Parallel	Parallel	Parallel	Parallel	Parallel	Parallel	Parallel
Product Attribute	-	Attribute Value	Attribute Value	Attribute Value	Attribute Value	Attribute Value	-	-	-
Manufacturer	-	GSI Technology	GSI Technology	GSI Technology	GSI Technology	GSI Technology	-	-	-
RoHS	-	Details	Details	Details	Details	Details	-	-	-
Memory Size	-	144 Mbit	144 Mbit	144 Mbit	144 Mbit	144 Mbit	-	-	-
Organization	-	8 M x 18	8 M x 18	8 M x 18	4 M x 36	8 M x 18	-	-	-
Maximum Clock Frequency	-	1.2 GHz	1.333 GHz	1.066 GHz	1.066 GHz	1.333 GHz	-	-	-
Supply Voltage - Max	-	1.35 V	1.35 V	1.35 V	1.35 V	1.35 V	-	-	-
Supply Voltage - Min	-	1.2 V	1.2 V	1.2 V	1.2 V	1.2 V	-	-	-
Supply Current - Max	-	2.15 A	2.35 A	1.9 A	2.4 A	2.35 A	-	-	-
Minimum Operating Temperature	-	- 40 C	- 40 C	0 C	0 C	0 C	-	-	-
Maximum Operating Temperature	-	+ 100 C	+ 100 C	+ 85 C	+ 85 C	+ 85 C	-	-	-
Mounting Style	-	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	-	-	-
Package / Case	-	BGA-260	BGA-260	BGA-260	BGA-260	BGA-260	-	-	-
Packaging	-	Tray	Tray	Tray	Tray	Tray	-	-	-
Memory Type	-	DDR-IV	DDR-IV	DDR-IV	DDR-IV	DDR-IV	-	-	-
Type	-	SigmaDDR-IVe B2	SigmaDDR-IVe B2	SigmaDDR-IVe B2	SigmaDDR-IVe B2	SigmaDDR-IVe B2	-	-	-
Moisture Sensitive	-	Yes	Yes	Yes	Yes	Yes	-	-	-
Factory Pack Quantity	-	10	10	10	10	10	-	-	-
