GS81302T38GE-500 datasheet, PDF

Datasheet> All Categories > semiconductor> Memory IC> Static random access memory> GS81302T38GE-500

GS81302T38GE-500: DescriptionStatic random access memory 1.8 or 1.5V 4M x 36 144M; Categorysemiconductor Memory IC Static random access memory; File Size2MB，30 Pages; ManufacturerGSI Technology; Websitehttp://www.gsitechnology.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

GS81302T38GE-500 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	GS81302T38GE-500	-	-	View	Buy Now

GS81302T38GE-500 Overview

Static random access memory 1.8 or 1.5V 4M x 36 144M

GS81302T38GE-500 Parametric

Parameter Name	Attribute value
Maker	GSI Technology
Product Category	static random access memory
storage	144 Mbit
organize	4 M x 36
maximum clock frequency	500 MHz
Interface Type	Parallel
Supply voltage - max.	1.9 V
Supply voltage - min.	1.7 V
Supply current—max.	1.3 A
Minimum operating temperature	0 C
Maximum operating temperature	+ 70 C
Installation style	SMD/SMT
Package/box	BGA-165
Encapsulation	Tray
storage type	DDR-II
series	GS81302T38GE
type	SigmaDDR-II+
Factory packaging quantity	10

Preview

Download Datasheet

View All

GS81302T06/11/20/38E-500/450/400/350

165-Bump BGA

Commercial Temp

Industrial Temp

Features

• 2.5 Clock Latency

• Simultaneous Read and Write SigmaDDR

Interface

• JEDEC-standard pinout and package

• Double Data Rate interface

• Byte Write controls sampled at data-in time

• Burst of 2 Read and Write

• On-Die Termination (ODT) on Data (D), Byte Write (BW),

and Clock (K, K) inputs

• 1.8 V +100/–100 mV core power supply

• 1.5 V or 1.8 V HSTL Interface

• Pipelined read operation

• Fully coherent read and write pipelines

• ZQ pin for programmable output drive strength

• Data Valid Pin (QVLD) Support

• IEEE 1149.1 JTAG-compliant Boundary Scan

• 165-bump, 15 mm x 17 mm, 1 mm bump pitch BGA package

• RoHS-compliant 165-bump BGA package available

144Mb SigmaDDR

-II+

Burst of 2 SRAM

500 MHz–350 MHz

1.8 V V

1.8 V or 1.5 V I/O

SRAMs are just one element in a family of low power, low

voltage HSTL I/O SRAMs designed to operate at the speeds

needed to implement economical high performance

networking systems.

Clocking and Addressing Schemes

The GS81302T06/11/20/38E SigmaDDR-II+ SRAMs are

synchronous devices. They employ two input register clock

inputs, K and K. K and K are independent single-ended clock

inputs, not differential inputs to a single differential clock input

buffer.

Each internal read and write operation in a SigmaDDR-II+ B2

RAM is two times wider than the device I/O bus. An input data

bus de-multiplexer is used to accumulate incoming data before

it is simultaneously written to the memory array. An output

data multiplexer is used to capture the data produced from a

single memory array read and then route it to the appropriate

output drivers as needed. Therefore, the address field of a

SigmaDDR-II+ B2 RAM is always one address pin less than

the advertised index depth (e.g., the 16M x 8 has an 8M

addressable index).

SigmaDDR-II™ Family Overview

The GS81302T06/11/20/38E are built in compliance with the

SigmaDDR-II+ SRAM pinout standard for Common I/O

synchronous SRAMs. They are 150,994,944-bit (144Mb)

SRAMs. The GS81302T06/11/20/38E SigmaDDR-II+

Parameter Synopsis

-500

tKHKH

tKHQV

2.0 ns

0.45 ns

-450

2.2 ns

0.45 ns

-400

2.5 ns

0.45 ns

-350

2.86 ns

0.45 ns

Rev: 1.03d 8/2017

1/29

Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
