EKI-2728I datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Embedded solution> Ethernet and communication module> The Ethernet module> EKI-2728I

EKI-2728I: DescriptionEthernet Module 8Gx Unmanaged Ethernet Switch w/ Wide Temp; CategoryEmbedded solution Ethernet and communication module The Ethernet module; File Size672KB，23 Pages; ManufacturerAdvantech; Websitehttp://www.advantech.com/

Download Datasheet Parametric View All

EKI-2728I Overview

Ethernet Module 8Gx Unmanaged Ethernet Switch w/ Wide Temp

EKI-2728I Parametric

Parameter Name	Attribute value
Maker	Advantech
Product Category	Ethernet module
product	Ethernet Switches, Unmanaged
Number of ports	8 Ethernet
data rate	10 Mb/s, 100 Mb/s, 1000 Mb/s, 16 Gbs
Interface Type	RJ-45
Working power voltage	12 V to 48 V
Minimum operating temperature	- 40 C
Maximum operating temperature	+ 75 C
size	36.6 mm x 140 mm x 95 mm
Power consumption	5.28 W
series	EKI-2728

Preview

Download Datasheet

View All

User Manual

EKI-2728I

8-port Industrial Unmanaged

Gigabit Ethernet Switch

The documentation and the software included with this product are copyrighted 2006
