Thick Film Resistors
Welwyn Components
VRW Series
VRW Series
meets the requirements of BS / EN /
•
VRW37
IEC 60065
VRW37 meets requirements of BS / EN / IEC 60065
•
High
working voltage to 10kV
10kV in compact
High
working voltage to
in compact size
size
High ohmic range to 68M
•
High ohmic range to 68M
High pulse load capability
•
High pulse load capability
Robust flameproof coating material
•
Robust flameproof coating material
Surface mount ZI-form option
•
RoHS compliant
All Pb-free parts comply with EU Directive 2011/65/EU amended by (EU) 2015/863 (RoHS3)
Electrical Data
VRW25
Power rating at 70˚ C
Resistance range
Limiting element voltage
Isolation voltage
TCR
Resistance Tolerance
Standard Values
Thermal Impedance
Ambient temperature range
˚ C/watt
˚C
140
watts
(Ohms)
volts dc or ac peak
volts
ppm/˚ C
%
0.25
100K to 30M
1600
VRW37
0.5
100K to 30M
3500
700
200
1, 2, 5
E24 or E96
112
-55 to +155˚ C
70
VRW68
1.0
100K to 68M
10000
Physical Data
Type
L
Max
6.2
9.0
15.5
(Dimensions (mm) & Weight (g)
f
min
21
19.6
27
d
Nom
0.6±0.05
0.8±0.05
0.8±0.05
PCB
mount
centres
10.2
12.7
20.3
Min
bend
radius
0.6
1.2
1.2
Wt.
nom
0.3
0.5
1.15
d
D
Max
2.5
3.7
5.0
VRW25
VRW37
VRW68
D
L
f
Construction
Resistive thick film material is applied to high-grade ceramic
rods. Tin-plated steel caps are force fitted and the
termination wires are welded to the caps. The value is
obtained by a helical cut in the film and finally the resistor
body is protected by a cement coating.
Terminations
Material:
Strength:
Solderability:
Hot tin dipped copper wire
The terminations meet the requirements
of IEC 68.2.21
The terminations meet the requirements
of IEC 115-1 Clause 4.17.3.2
Marking
1% tolerance resistors are colour coded with 5 bands. 2%
and 5% tolerance have 4 bands. IEC62 colours are used.
Solvent Resistance
The body protection and marking are resistant to all normal
industrial cleaning solvents suitable for printed circuits.
Flammability
The resistor coating will not burn under any condition of
applied temperature or power overload.
General Note
General Note
TT Electronics reserves the right to make changes in product specification without notice
without notice or liability.
Welwyn Components reserves the right to make changes in product specification
or liability.
All information is
is subject to Welwyn’s own data and is considered
accurate at time of going to
to print.
All information
subject to TT Electronics’ own data and is considered
accurate at time of going
print.
BI Technologies IRC Welwyn
A subsidiary of
www.ttelectronics.com/resistors
TT electronics plc
Issue C ·
05.08
07.06
06.18
© Welwyn Components Limited
· Bedlington, Northumberland NE22 7AA, UK
© TT Electronics plc
Telephone: +44 (0) 1670 822181 · Facsimile: +44 (0) 1670 829465 · Email: info@welwyn-tt.com · Website: www.welwyn-tt.com
