Product Brief
MegaRAID
®
SAS 9266-8i
Eight-Port 6Gb/s PCI Express SATA+SAS RAID Controller
Highest Server RAID Performance for Database and Multimedia Applications
Key Features
■■
■■
As storage demands expand and processing loads grow, it becomes increasingly more difficult
for administrators to achieve maximum performance from their applications. The newest line
of MegaRAID
®
6Gb/s SATA+SAS controller cards, built on the LSI SAS 2208 dual-core ROC, offer
unmatched I/O performance for database applications and streaming digital media environments.
The MegaRAID SAS 9266-4i controller, with four internal ports, delivers two 800MHz PowerPC
processor cores and a 72-bit DDRIII interface that drives 1GB cache memory. Users can deploy
the MegaRAID SAS 9266-8 i controller in existing HDD-based server environments for significant
performance gains. Alternatively, for users implementing server platforms based on solid-state
storage, these next-generation MegaRAID controllers exploit the potential of SSDs for unsurpassed
performance and enterprise-class reliability.
Eight Internal 6Gb/s SATA+SAS ports
Two Mini-SAS internal connector
(SFF8087)
LSI SAS 2208 Dual- core 6Gb/s ROC
–x2 800MHz PowerPC Processors
1GB DDRIII cache memory
RAID Levels 0, 1, 5, 6, 10, 50 and 60
Support for NAND flash or BBU cache
protection solution
■■
■■
■■
■■
Key Advantages
■■
■■
Unmatched RAID performance
Connect up to 128 3Gb/s and 6Gb/s
SATA and SAS hard drives or SSDs
Helps users realize potential of solid-
state storage deployments
CacheVault technology option for
greener, lower total cost cache
protection (LSICVM01)
Heat-tolerant battery backup option
(LSIiBBU09)
Protect Cached Data with MegaRAID CacheVault
™
Technology or BBU
RAID caching is a cost-effective way to improve I/O performance by writing data to a controllers’
cache before it is written to disk. In write-back mode, data written to cache is vulnerable until it
is made permanent on disk. To avoid the possibility of data loss or corruption during a power or
server failure, Avago offers the CacheVault flash cache protection module or the LSIiBBU09 battery
backup unit for the MegaRAID SAS 9266-8i controller. CacheVault flash cache protection uses
NAND flash memory powered by a super-capacitor to help protect data stored in the MegaRAID
controller cache. The RAID controller automatically writes the data in cache to flash when a power
failure occurs, while the super-capacitor keeps the current going during the process. When the
power comes back, the DRAM is recovered from flash and the system goes on without loss of data.
Customers have the flexibility to choose a traditional LiON battery solution or a greener, lower TCO
cache protection solution with MegaRAID CacheVault technology.
■■
■■
■■
Support for Advanced Software Options
The LSI family of 6Gb/s MegaRAID controllers are designed to support advanced software options
that provide white box channel partners with enhanced performance and data protection
capabilities. These new software options help enable end users to address key business challenges
while helping to deliver a higher return on their IT investments. MegaRAID CacheCade
®
software and
MegaRAID Fast Path software boost transactional I/O performance of solid state disk configurations,
while MegaRAID Recovery software and MegaRAID SafeStore
™
software enable enhanced data
protection and security.
Intuitive RAID Management Utility
The MegaRAID Management Suite
™
of software provides essential tools to manage MegaRAID
products, whether deployed in an enterprise or small business. Avago offers a collection of
applications and tools including a pre-boot setup utility and a full spectrum of online RAID
management utilities. This suite of applications allows administrators to adjust SAS or SATA topology
views from the system host, controller and disk enclosure down to the logical and physical drive
level. Extending to enterprise deployments, these tools scale to more easily configure, monitor and
manage RAID and JBOD volumes locally or over the LAN network.
Product Brief
LSI MegaRAID
®
SAS 9266-8i
Solution Provided
Physical Dimensions
Internal Connectors
Device Support
Host Bus Type
Data Transfer Rates
I/O Processor/SAS Controller
Cache Memory
Cache Protection
Key RAID Data Protection
Features
Eight-port internal SAS solution for performance-hungry applications using up to 128 SAS, SATA and solid state drives (SSDs)
MD2 Low Profile (6.6” x 2.536”)
Two Mini-SAS SFF8087 Internal connector (side mount)
Up to 128 SAS and/or SATA hard drives and SSDs
x8 lane PCI Express 2.0 compliant
Up to 6Gb/s per port
LSI SAS 2208 Dual-Core RAID on Chip (ROC)
1 GB 1333MHz DDRIII SDRAM
MegaRAID CacheVault flash cache protection (optional – LSICVM01 / LSI00297)
MegaRAID LSIiBBU09 (optional – LSIiBBU09 / LSI00279)
• RAID levels 0, 1, 5, and 6
• RAID spans 10, 50 and 60
• Online Capacity Expansion (OCE)
• Online RAID Level Migration (RLM)
• Auto resume after loss of system power during array rebuild or
reconstruction (RLM)
• Single controller Multipathing (failover)
• Load Balancing
• Configurable stripe size up to 1MB
• Fast initialization for quick array setup
• Check Consistency for background data integrity
• Patrol read for media scanning and repairing
+3.3V, +12V
1,031,514 hours
3 years, free advanced technical support, advanced replacement option
EN55022, EN55024, EN60950, EN 61000-3-2, EN 61000-3-3; FCC Class A, Class B; UL1950; UL; CSA C22.2; VCCI; RRL for MIC; BSMI;
C-tick
MegaRAID Management Suite
• MegaRAID Storage Manager
• MegaCLI (command-line interface)
• WebBIOS
• MegaRAID CacheCade Software leverages SSDs in front of HDD volumes to create high-capacity, high-performance control-
ler cache pools
• MegaRAID Fast Path Software provides high-performance I/O acceleration for SSD arrays connected to 6Gb/s MegaRAID
SATA+SAS controllers
OS Support
Extensive support includes Microsoft
®
Windows
®
Vista/2008/Server 2003, Linux
®
, Solaris
™
(x86), FreeBSD
®
, VMware
®
and more.
* Visit the download center for the most complete list of supported operating systems: www.lsi.com/support
• 64 logical drive support
• DDF compliant Configuration on Disk (COD)
• S.M.A.R.T support
• Global and dedicated Hot Spare with Revertible Hot
Spare support
– Automatic rebuild
– Enclosure affinity
– Emergency SATA hot spare for SAS arrays
• Enclosure management
– SES (inband)
– SGPIO (sideband)
Operating Temperature
Operating Voltage
MTBF (Calculated)
Hardware Warranty
Regulatory Certifications
Maximum ambient: Controller Card: 55°C, with optional CVM01: 55°C, with optional LSIiBBU09: 55°C
RAID Management
Optional SSD Optimization
Ordering Information
MegaRAID SAS 9266-8i Single Pack
MPN: L5-25413-16
OPN: LSI00295
LSICVM01
MPN: L5-25419-04
OPN: LSI00297
LSIiBBU09
MPN: L5-25407-00
OPN: LSI00279
Visit the Avago Server Storage website at:
avagotech.com/server-storage
Avago, Avago Technologies, MegaRAID, and the Storage by LSI logo are trademarks of Avago Technologies. All other trademarks are the
property of their respective owners.
Copyright ©2015 Avago Technologies. All rights reserved. > 9.18.15
