NOTES:
UNLESS OTHERWISE SPECIFIED
1. CORNERS DRAWN SHARP TO BE R.005 MAXIMUM.
2. EXTERIOR SURFACE TEXTURE TO BE LIGHT EDM FINISH.
EQUIVALENT TO MT-11010. TEXTURE ON ENCLOSURE
WILL VARY FROM TIME TO TIME AS THE TOOL WEARS AND
IT BECOMES NESSESARY TO REAPPLY.
3. INTERIOR SURFACE TEXTURE TO BE: NONE.
4. ALL INSIDE RADII .010R. UNLESS OTHERWISE SPECIFIED.
5. ALL EXTERNAL DIMENSIONS AFFECTED BY THE DRAFT APPLY AT THE
LARGE END OF THE FEATURE, AND ALL INTERNAL FEATURES AFFECTED
BY THE DRAFT APPLY AT THE SMALL END OF THE FEATURE UNLESS
OTHERWISE SPECIFIED.
6. 1 DEGREE DRAFT IN THE DIRECTION OF PULL IS PERMISSIBLE UNLESS
OTHERWISED SPECIFIED.
7. MATERIAL / COLOR:
ASA PLASTIC IS STANDARD IN BLACK OR GRAY.
CUSTOM MATERIALS AND COLORS ARE AVAILABLE UPON REQUEST FOR QUOTE.
ALTERNATE RESINS HAVE DIFFERENT SHRINK RATES, AND WILL EFFECT
DIMENSIONS.
8. PCB SIZES ARE RECOMMENDATIONS ONLY. FINAL SIZES AND VERIFICATION
OF ITS FIT ARE THE SOLE RESPONSIBILITY OF EACH CUSTOMER.
10. ASSEMBLY SCREWS FOR THE ENCLOSURE INCLUDED.
FOR THE PCB ARE SOLD SEPARATELY.
MOUNTING SCREWS
REV.
A
B
C
D
E
F
G
H
I
DRAWN BY
M BOYER
M BOYER
M BOYER
M BOYER
M BOYER
M BOYER
M BOYER
M BOYER
R CRUZ
ECO No
DR XXXX
DESCRIPTION
R
E
V
I
S
I
O
N
DATE
2017-Jun-27
2017-Jul-13
2017-Sep-08
2018-Jan-09
2018-Mar-08
2018-Mar-19
2018-Apr-03
2018-Apr-06
2018-Apr-25
APPROVE
D.C.
D.C.
D.C.
D.C.
D.C.
D.C.
D.C.
D.C.
PRELIMINARY RELEASE
REPLACED DOMED COVER WITH CURVED COVER
REVISE ORING PATH
UPDATE FEET HEIGHT
UPDATE HEIGHT AND ADD STRAP
ADAPT GENERIC FEATURES FOR NAE LINE
UPDATE TEXTURE INFORMATION
REVISE TITLE OF DRAWING
UPDATE TO #037 O-RING
2
11. THIS DRAWING IS BASED ON A SOLID MODEL, AND IS FURTHER DEFINED
BY THE SOLID MODEL FILE.
12. ALLOWABLE FLASH: 0.010 MAX.
13. ALL EJECTOR PIN MARKS TO BE WITHIN 0.010" OF FLUSH,
PROTRUDING OR BELOW FLUSH.
14. THIS ENCLOSURE IS DESIGNED FOR OUTDOOR USE
AND MEETS IPX7 INGRESS PROTECTION STANDARD.
7
3
4
6
1
5
SCALE 0.900
7
6
5
4
3
2
1
PEM-INSERT_6-32
303013-ORING
6-32_PHILLIPS_SCREW
SCREW_HILO-NO4X250
303013-PCB
303013-COVER
303013-BASE
PEM INSERT 6-32 x .250"
303011 ORING - OTS #037
6-32 PHILLIPS SCREW x .500"
#4 HiLo SCREW x .250"
303011 PCB - REFERENCE
303011 COVER - STANDARD
303011 BASE - STANDARD
BRASS
BUNA-N
70A
STAINLESS STEEL
ZINK PLATED
.062" THICK
ASA
ASA
OVER MOLDED
NATURAL
MMC 91772A146
CUSTOMER SUPPLIED
CUSTOMER SUPPLIED
BLACK or GREY
BLACK or GREY
4
1
4
4
1
1
1
DO NOT SCALE DRAWING
NOTICE: THE INFORMATION AND DATA
CONTAINED HEREIN IS CONSIDERED
PROPRIETARY TO ALLTEC INTEGRATED
MFG INC & SHALL REMAIN THE EXCLUSIVE
PROPERTY OF ALLTEC INTEGRATED MFG INC
THE HOLDER WILL ASSUME CUSTODY AND
CONTROL THAT THIS DOCUMENT WILL
NOT BE COPIED, REPRODUCED, OR
DISCLOSED WITHOUT THE EXPRESS WRITTEN
CONSENT OF ALLTEC INTEGRATED MFG INC
POSSESSION OF THIS DOCUMENT DOES
NOT CONSTITUTE A GRANT TO
MANUFACTURE ANY ITEMS.
© 2018
SCALE 0.800
THIRD ANGLE PROJECTION
TOLERANCES: UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN U.S. INCHES.
NEW AGE ENCLOSURES
Customer's Part No:
APPROVAL
CHECK
ENG.
SCALE
DRAWN BY
BY
DATE
X.XX = .015 X.XXXX = .001
X.XXX = .010
X.X° = 1°
303013
2240 South Thornburg Street
ph. (805) 595-1310
www.newageenclosures.com
Santa Maria, CA. 93455
fax (805) 595-1024
3" ROUND OUTDOOR - STANDARD
ITEM
FILE
NAME
DESCRIPTION
MATERIAL
COLOR
QTY.
AS NOTED
SIZE
SXX-303013-XXX
SHEET
BILL OF MATERIALS
M BOYER
2017-Jun-27
A
DRAWING NAME
REV.DOC
303013_RI
1 OF 8
I
