HS1-26CLV31RH/PROTO

Description
RS-422 interface integrated circuit RAD HARD 3.3V RS422 CMOS LINE TRANSMITTER,DIP,PROTO
CategoryAnalog mixed-signal IC    Drivers and interfaces
File Size441KB,9 Pages
ManufacturerRenesas Electronics Corporation
Websitehttps://www.renesas.com/
Related ProductsFound6parts with similar functions to HS1-26CLV31RH/PROTO
Download Datasheet Parametric Compare View All

HS1-26CLV31RH/PROTO Overview

RS-422 interface integrated circuit RAD HARD 3.3V RS422 CMOS LINE TRANSMITTER,DIP,PROTO

HS1-26CLV31RH/PROTO Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
MakerRenesas Electronics Corporation
Parts packaging codeDIP
package instructionDIP,
Contacts16
Reach Compliance Codecompliant
ECCN codeEAR99
Differential outputYES
Number of drives4
Input propertiesSTANDARD
Interface integrated circuit typeLINE DRIVER
Interface standardsEIA-422
JESD-30 codeR-CDIP-T16
JESD-609 codee0
Number of functions4
Number of terminals16
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
Package body materialCERAMIC, METAL-SEALED COFIRED
encapsulated codeDIP
Package shapeRECTANGULAR
Package formIN-LINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusNot Qualified
Maximum receive delay
Maximum seat height5.08 mm
Maximum supply voltage3.6 V
Minimum supply voltage3 V
Nominal supply voltage3.3 V
surface mountNO
technologyCMOS
Temperature levelMILITARY
Terminal surfaceTIN LEAD
Terminal formTHROUGH-HOLE
Terminal pitch2.54 mm
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
total dose300k Rad(Si) V
width7.62 mm
Base Number Matches1
DATASHEET
HS-26CLV31RH, HS-26CLV31EH
Radiation Hardened 3.3V Quad Differential Line Drivers
The
HS-26CLV31RH
and
HS-26CLV31EH
are radiation
hardened 3.3V quad differential line drivers designed for
digital data transmission over balanced lines, in low voltage
RS-422 protocol applications. CMOS processing assures low
power consumption, high speed, and reliable operation in the
most severe radiation environments.
The HS-26CLV31RH and HS-26CLV31EH accept CMOS level
inputs and converts them to differential outputs. Enable pins
allow several devices to be connected to the same data source
and addressed independently. These devices have unique outputs
that become high impedance when the driver is disabled or
powered-down, maintaining signal integrity in multi-driver
applications.
FN4898
Rev 5.00
Oct 26, 2018
Features
• Electrically screened to SMD #
5962-96663
• QML qualified per MIL-PRF-38535 requirements
• 1.2 micron radiation hardened CMOS
- Total dose . . . . . . . . . . . . . . . . . . . 300krad (Si) (maximum)
- Single event upset LET . . . . . . . . . . . . . . 100MeV/mg/cm
2
- Single event latch-up immune
• Extremely low stand-by current . . . . . . . . 100µA (maximum)
• Operating supply range . . . . . . . . . . . . . . . . . . . . . 3.0V to 3.6V
• CMOS level inputs . . . . . . .V
IH
> (0.7) (V
DD
); V
IL
< (0.3) (V
DD
)
• Differential outputs . . . . . . . . . . . . . . . V
OH
> 1.8V; V
OL
< 0.5V
• High impedance outputs when disabled or powered down
• Low output impedance . . . . . . . . . . . . . . . . . . . . . . 10Ω or less
• Full -55°C to +125°C military temperature range
• Pb-free (RoHS compliant)
Related Literature
For a full list of related documents, visit our website:
HS-26CLV31RH, HS-26CLV31EH
product pages
Applications
• Line transmitter for MIL-STD-1553 serial data bus
FN4898 Rev 5.00
Oct 26, 2018
Page 1 of 8

HS1-26CLV31RH/PROTO Related Products

HS1-26CLV31RH/PROTO HS9-26CLV31RH/PROTO
Description RS-422 interface integrated circuit RAD HARD 3.3V RS422 CMOS LINE TRANSMITTER,DIP,PROTO RS-422 interface integrated circuit RAD HARD 3.3V RS422 CMOS LINE TRANSMITTER, FLATPACK, PROTO
Is it lead-free? Contains lead Contains lead
Is it Rohs certified? incompatible conform to
Maker Renesas Electronics Corporation Renesas Electronics Corporation
Parts packaging code DIP DFP
package instruction DIP, DFP,
Contacts 16 16
Reach Compliance Code compliant compliant
ECCN code EAR99 USML XV(E)
Differential output YES YES
Number of drives 4 4
Input properties STANDARD STANDARD
Interface integrated circuit type LINE DRIVER LINE DRIVER
Interface standards EIA-422 EIA-422
JESD-30 code R-CDIP-T16 R-CDFP-F16
JESD-609 code e0 e4
Number of functions 4 4
Number of terminals 16 16
Maximum operating temperature 125 °C 125 °C
Minimum operating temperature -55 °C -55 °C
Package body material CERAMIC, METAL-SEALED COFIRED CERAMIC, METAL-SEALED COFIRED
encapsulated code DIP DFP
Package shape RECTANGULAR RECTANGULAR
Package form IN-LINE FLATPACK
Peak Reflow Temperature (Celsius) NOT SPECIFIED NOT SPECIFIED
Certification status Not Qualified Not Qualified
Maximum seat height 5.08 mm 2.92 mm
Maximum supply voltage 3.6 V 3.6 V
Minimum supply voltage 3 V 3 V
Nominal supply voltage 3.3 V 3.3 V
surface mount NO YES
technology CMOS CMOS
Temperature level MILITARY MILITARY
Terminal surface TIN LEAD Gold (Au)
Terminal form THROUGH-HOLE FLAT
Terminal pitch 2.54 mm 1.27 mm
Terminal location DUAL DUAL
Maximum time at peak reflow temperature NOT SPECIFIED NOT SPECIFIED
total dose 300k Rad(Si) V 300k Rad(Si) V
width 7.62 mm 6.73 mm
Base Number Matches 1 1
