GS82582D20GE-400I datasheet, PDF

Datasheet> All Categories > semiconductor> Memory IC> Static random access memory> GS82582D20GE-400I

GS82582D20GE-400I: DescriptionStatic random access memory 1.5/1.8V 16M x 18 288M; Categorysemiconductor Memory IC Static random access memory; File Size314KB，28 Pages; ManufacturerGSI Technology; Websitehttp://www.gsitechnology.com/; Environmental Compliance

Download Datasheet Parametric View All

GS82582D20GE-400I Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	GS82582D20GE-400I	-	-	View	Buy Now

GS82582D20GE-400I Overview

Static random access memory 1.5/1.8V 16M x 18 288M

GS82582D20GE-400I Parametric

Parameter Name	Attribute value
Maker	GSI Technology
Product Category	static random access memory
storage	288 Mbit
organize	16 M x 18
maximum clock frequency	400 MHz
Interface Type	Parallel
Supply voltage - max.	1.9 V
Supply voltage - min.	1.7 V
Supply current—max.	920 mA
Minimum operating temperature	- 40 C
Maximum operating temperature	+ 85 C
Installation style	SMD/SMT
Package/box	BGA-165
Encapsulation	Tray
storage type	QDR-II
series	GS82582D20GE
type	SigmaQuad-II+
Factory packaging quantity	10

Preview

Download Datasheet

View All

GS82582D20/38GE-550/500/450/400

165-Bump BGA

Commercial Temp

Industrial Temp

Features

• 2.5 Clock Latency

• Simultaneous Read and Write SigmaQuad™ Interface

• JEDEC-standard pinout and package

• Dual Double Data Rate interface

• Byte Write controls sampled at data-in time

• Burst of 4 Read and Write

• On-Die Termination (ODT) on Data (D), Byte Write (BW),

and Clock (K, K) intputs

• 1.8 V +100/–100 mV core power supply

• 1.5 V or 1.8 V HSTL Interface

• Pipelined read operation

• Fully coherent read and write pipelines

• ZQ pin for programmable output drive strength

• Data Valid Pin (QVLD) Support

• IEEE 1149.1 JTAG-compliant Boundary Scan

• RoHS-compliant 165-bump BGA package

288Mb SigmaQuad-II+

Burst of 4 SRAM

550 MHz–400 MHz

1.8 V V

1.8 V or 1.5 V I/O

one element in a family of low power, low voltage HSTL I/O

SRAMs designed to operate at the speeds needed to implement

economical high performance networking systems.

Clocking and Addressing Schemes

The GS82582D20/38GE SigmaQuad-II+ SRAMs are

synchronous devices. They employ two input register clock

inputs, K and K. K and K are independent single-ended clock

inputs, not differential inputs to a single differential clock input

buffer.

Each internal read and write operation in a SigmaQuad-II+ B4

RAM is four times wider than the device I/O bus. An input

data bus de-multiplexer is used to accumulate incoming data

before it is simultaneously written to the memory array. An

output data multiplexer is used to capture the data produced

from a single memory array read and then route it to the

appropriate output drivers as needed. Therefore the address

field of a SigmaQuad-II+ B4 RAM is always two address pins

less than the advertised index depth (e.g., the 16M x 18 has a

4M addressable index).

SigmaQuad™ Family Overview

The GS82582D20/38GE are built in compliance with the

SigmaQuad-II+ SRAM pinout standard for Separate I/O

synchronous SRAMs. They are 301,989,888-bit (288Mb)

SRAMs. The GS82582D20/38GE SigmaQuad SRAMs are just

Parameter Synopsis

-550

tKHKH

tKHQV

1.81 ns

0.45 ns

-500

2.0 ns

0.45 ns

-450

2.2 ns

0.45 ns

-400

2.5 ns

0.45 ns

Rev: 1.04b 11/2017

1/28

Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
