334K250RA4-FA datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> capacitor> Film capacitor> 334K250RA4-FA

334K250RA4-FA: DescriptionFilm Capacitor 0.33uF 250V Metalized Polyester; CategoryPassive components capacitor Film capacitor; File Size190KB，5 Pages; ManufacturerCornell Dubilier; Environmental Compliance

Download Datasheet Parametric Compare View All

334K250RA4-FA Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	334K250RA4-FA	-	-	View	Buy Now

334K250RA4-FA Overview

Film Capacitor 0.33uF 250V Metalized Polyester

334K250RA4-FA Parametric

Parameter Name	Attribute value
Maker	Cornell Dubilier
Product Category	Film capacitor
Shipping restrictions	Mouser does not currently sell this product.
series	RA
capacitance	0.33 uF
Encapsulation	Bulk
Capacitance-nF	330 nF
Capacitance-pF	330000 pF
Factory packaging quantity	400

Preview

Download Datasheet

View All

Type RA Angstor® Radial PET Film Capacitors

The RA style capacitor is constructed in an eﬃcient rugged self-

encased size. The non-inductive multilayer metallized polyester flm

capacitor features a small size, high dv/dt capability, very low ESR

at high frequency and a self-healing capability. RA type capacitors

are ideal for use in high frequency switching power supplies, noise

suppression, EMI reduction and long-life applications.

Highlights

Specifcations

Capacitance Range (at 1 kHz)

Capacitance Tolerance

Rated Voltage

Operating Temperature Range

Dissipation Factor (at 1 kHZ/25 ºC)

Insulation Resistance

- Eﬃcient size

- Self healing

- Low ESR/ESL

- High dv/dt

- Wave solderable

0.1 to 10 µF

Standard Tolerance ±10% (K), Optional ±5% (J) or ±20% (M)

100, 250, 400, 500 Vdc

–55 ºC to 125 ºC

≤1.0%

≥1,000 MΩ x µF - Need not exceed 1,000 MΩ

Test Voltage for 100 Vdc rating: 10 Vdc

Test Voltage for >100 Vdc rating : 100 Vdc

Dielectric Strength

Self Inductance (typical)

Temperature Range

1.6 x rated VDC for 2 seconds max.

Bold P.N.: 1.3 x rated VDC for 2 seconds max.

2 to 6 nh

-55° to +125°C at Rated DC Voltage

Bold P.N.: -55° to +125°C

(derate voltage 1.25% / °C above +85°C)

Life Test:

Apply 1.25 x the rated DC voltage for 1000 hours at +85°C.

After the test, the capacitance, DF, and IR should meet the following:

Capacitance change: ≤ 5.0%

DF will meet the initial specifcation

Insulation Resistance will meet the initial specifcation

Moisture Test:

Subject the capacitor to +85°C / 85% RH for 21 days without voltage.

After the test, the capacitance, DF, and IR should meet the following:

Capacitance change: ≤ 7.0%

DF will meet the initial specifcation

Insulation Resistance ≥ 30% of the initial limit

Long Term Stability :

Vibration

Solder Resistance

After 2 years of storage in a standard environment.

Capacitance change: ≤2.0%

Mil Std 202 Method 204D

260°C, 5 sec.

Capacitance change: ≤ 2.0%

Outline Drawing

CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830

Notice and Disclaimer:

All product drawings, descriptions, specifcations, statements, information and data

(collectively, the “Information”) in this datasheet or other publication are subject to change. The customer

is responsible for checking, confrming and verifying the extent to which the Information contained in this

datasheet or other publication is applicable to an order at the time the order is placed. All Information given

herein is believed to be accurate and reliable, but it is presented without any guarantee, warranty, representation

or responsibility of any kind, expressed or implied. Statements of suitability for certain applications are based

on the knowledge that the Cornell Dubilier company providing such statements (“Cornell Dubilier”) has

of operating conditions that such Cornell Dubilier company regards as typical for such applications, but

are not intended to constitute any guarantee, warranty or representation regarding any such matter – and

Cornell Dubilier specifcally and expressly disclaims any guarantee, warranty or representation concerning

the suitability for a specifc customer application, use, storage, transportation, or operating environment.

The Information is intended for use only by customers who have the requisite experience and capability to

determine the correct products for their application. Any technical advice inferred from this Information or

otherwise provided by Cornell Dubilier with reference to the use of any Cornell Dubilier products is given

gratis (unless otherwise specifed by Cornell Dubilier), and Cornell Dubilier assumes no obligation or liability

for the advice given or results obtained. Although Cornell Dubilier strives to apply the most stringent quality

and safety standards regarding the design and manufacturing of its products, in light of the current state

of the art, isolated component failures may still occur. Accordingly, customer applications which require a

high degree of reliability or safety should employ suitable designs or other safeguards (such as installation

of protective circuitry or redundancies or other appropriate protective measures) in order to ensure that the

failure of an electrical component does not result in a risk of personal injury or property damage. Although

all product-related warnings, cautions and notes must be observed, the customer should not assume that all

safety measures are indicated in such warnings, cautions and notes, or that other safety measures may not be

required.
