MCP1404-E/P Overview

Gate Driver 4.5A Dual MOSFET

MCP1404-E/P Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Microchip
Parts packaging code	DIP
package instruction	DIP, DIP8,.3
Contacts	8
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	12 weeks
Samacsys Description	Microchip MCP1404-E/P, Dual MOSFET Power Driver 4.5A, 4.5 → 18 V, Non-Inverting, 8-Pin PDIP
high side driver	NO
Interface integrated circuit type	BUFFER OR INVERTER BASED MOSFET DRIVER
JESD-30 code	R-PDIP-T8
JESD-609 code	e3
length	9.271 mm
Number of functions	1
Number of terminals	8
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Nominal output peak current	4.5 A
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Encapsulate equivalent code	DIP8,.3
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT APPLICABLE
power supply	4.5/18 V
Certification status	Not Qualified
Maximum seat height	5.334 mm
Maximum supply voltage	18 V
Minimum supply voltage	4.5 V
surface mount	NO
technology	CMOS
Temperature level	AUTOMOTIVE
Terminal surface	Matte Tin (Sn)
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT APPLICABLE
Disconnect time	0.065 µs
connection time	0.065 µs
width	6.35 mm

User Manual

Preview

Download Datasheet

View All

MCP1403/4/5

4.5A Dual High-Speed Power MOSFET Drivers

Features

• High Peak Output Current: 4.5A (typ.)

• Low Shoot-Through/Cross-Conduction Current in

Output Stage

• Wide Input Supply Voltage Operating Range:

- 4.5V to 18V

• High Capacitive Load Drive Capability:

- 2200 pF in 15 ns

- 5600 pF in 34 ns

• Short Delay Times: 40 ns (typ.)

• Low Supply Current:

- With Logic ‘1’ Input – 1.0 mA (typ.)

- With Logic ‘0’ Input – 150 µA (typ.)

• Latch-Up Protected: Will Withstand 1.5A Reverse

Current

• Logic Input Will Withstand Negative Swing

Up To 5V

• Packages: 8-Pin SOIC, PDIP, 8-Pin 6x5 DFN,

and 16-Pin SOIC

General Description

The MCP1403/4/5 are a family of dual-inverting, dual-

non-inverting, or complimentary output drivers. They

can delivery high peak currents of 4.5A typically into

capacitive loads. These devices also feature low shoot-

through current, matched rise/fall times and

propagation delays.

The MCP1403/4/5 drivers operate from a 4.5V to 18V

single power supply and can easily charge and

discharge 2200 pF gate capacitance in under 15 ns

(typ). They provide low enough impedances in both the

on and off states to ensure the MOSFETs intended

state will not be affected, even by large transients. The

input to the MCP1403/4/5 may be driven directly from

either TTL or CMOS (3V to 18V).

The MCP1403/4/5 dual-output 4.5A driver family is

offered in both surface-mount and pin-through-hole

packages with a -40

C to +125

C temperature rating.

The low thermal resistance of the thermally enhanced

DFN package allows for greater power dissipation

capability for driving heavier capacitive or resistive

loads.

These devices are highly latch-up resistant under any

conditions within their power and voltage ratings. They

are not subject to damage when up to 5V of noise

spiking (of either polarity) occurs on the ground pin. All

terminals are fully protect against Electrostatic

Discharge (ESD) up to 4 kV.

Applications

•

Switch Mode Power Supplies

Pulse Transformer Drive

Line Drivers

Motor and Solenoid Drive

Package Types

MCP1404

8-Pin

MCP1405

MCP1403

PDIP/SOIC

IN A

GND

IN B

16-Pin SOIC

IN A

GND

IN B

MCP1404

MCP1403

MCP1405

OUT A

OUT B

OUT A

OUT B

OUT A

OUT B

OUT A

OUT B

OUT A

OUT B

OUT A

OUT B

8-Pin DFN

(2)

IN A

GND

IN B

MCP1404

MCP1403

MCP1405

OUT A

OUT B

OUT A

OUT B

OUT A

OUT B

Note 1:

Duplicate pins must both be connected for

proper operation.

Exposed pad of the DFN package is electrically

isolated.

2006 Microchip Technology Inc.

DS22022A-page 1
