S1PB, S1PD, S1PG, S1PJ, S1PK, S1PM
www.vishay.com
Vishay General Semiconductor
High Current Density Surface Mount
Glass Passivated Rectifiers
eSMP
®
Series
FEATURES
• Very low profile - typical height of 1.0 mm
• Ideal for automated placement
• Glass passivated pellet chip junction
• Low forward voltage drop
• Low thermal resistance
• Meets MSL level 1, per
LF maximum peak of 260 °C
• AEC-Q101 qualified
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
J-STD-020,
Available
SMP
(DO-220AA)
Cathode
Anode
TYPICAL APPLICATIONS
DESIGN SUPPORT TOOLS
Models
Available
click logo to get started
General purpose, polarity protection, and rail-to-rail
protection in both consumer and automotive applications.
MECHANICAL DATA
Case:
SMP (DO-220AA)
Molding compound meets UL 94 V-0 flammability rating
Base P/N-M3 - halogen-free, RoHS-compliant, and
commercial grade
Base P/NHM3 - halogen-free, RoHS-compliant, and
automotive grade
Terminals:
Matte tin plated leads, solderable per
J-STD-002 and JESD 22-B102
M3 suffix meets JESD 201 class 1A whisker test, HM3 suffix
meets JESD 201 class 2 whisker test
Polarity:
Color band denotes the cathode end
PRIMARY CHARACTERISTICS
I
F(AV)
V
RRM
I
R
V
F
T
J
max.
Package
Circuit configuration
1.0 A
100 V, 200 V, 400 V, 600 V,
800 V, 1000 V
1 μA
0.95 V
150 °C
SMP (DO-220AA)
Single
MAXIMUM RATINGS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Device marking code
Max. repetitive peak reverse voltage
Max. RMS voltage
Max. DC blocking voltage
Average forward current
Peak forward surge current 10 ms single half
sine-wave superimposed on rated load
Operating junction and storage temperature range
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
T
J
, T
STG
SYMBOL
S1PB
SB
100
70
100
S1PD
SD
200
140
200
S1PG
SG
400
280
400
1.0
30
-55 to +150
S1PJ
SJ
600
420
600
S1PK
SK
800
560
800
S1PM
SM
1000
700
1000
V
V
V
A
A
°C
UNIT
Revision: 13-Aug-2018
Document Number: 88917
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
S1PB, S1PD, S1PG, S1PJ, S1PK, S1PM
www.vishay.com
Vishay General Semiconductor
ELECTRICAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Max. instantaneous
forward voltage
Max. reverse current
Typical reverse recovery time
Typical junction capacitance time
TEST CONDITIONS
I
F
= 1.0 A
I
F
= 1.0 A
Rated V
R
T
J
= 25 °C
T
J
= 125 °C
T
J
= 25 °C
T
J
= 125 °C
SYMBOL
V
F (1)
I
R (2)
t
rr
C
J
1.0
50
1.8
6.0
S1PB
S1PD
S1PG
1.1
0.95
1.0
100
S1PJ
S1PK
S1PM
UNIT
V
μA
μA
μs
pF
I
F
= 0.5 A, I
R
= 1.0 A,
I
rr
= 0.25 A
4.0 V, 1 MHz
Notes
(1)
Pulse test: 300 μs pulse width, 1 % duty cycle
(2)
Pulse test: Pulse width
40 ms
THERMAL CHARACTERISTICS
(T
A
= 25 °c unless otherwise noted)
PARAMETER
Typical thermal resistance
Note
(1)
SYMBOL
R
JA
(1)
R
JL
R
JC
(1)
(1)
S1PB
S1PD
S1PG
105
15
20
S1PJ
S1PK
S1PM
UNIT
°C/W
Th
ermal resistance from junction to ambient and junction to lead mounted on PCB with 5.0 mm x 5.0 mm copper pad areas. R
JL
is
measured at the terminal of cathode band. R
JC
is measured at the top center of the body
ORDERING INFORMATION
(Example)
PREFERRED P/N
S1PJ-M3/84A
S1PJ-M3/85A
S1PJHM3/84A
(1)
S1PJHM3/85A
(1)
(1)
UNIT WEIGHT (g)
0.024
0.024
0.024
0.024
PREFERRED PACKAGE CODE
84A
85A
84A
85A
BASE QUANTITY
3000
10 000
3000
10 000
DELIVERY MODE
7" diameter plastic tape and reel
13" diameter plastic tape and reel
7" diameter plastic tape and reel
13" diameter plastic tape and reel
Note
Automotive grade
RATINGS AND CHARACTERISTICS CURVES
(T
A
= 25
C
unless otherwise noted)
1.2
1.2
D = 0.5
1.0
1.0
D = 0.3
D = 0.2
0.8
D = 0.1
D = 1.0
D = 0.8
Average Forward Rectified Current (A)
0.8
0.6
Average Power Loss (W)
0.6
T
0.4
0.4
T
L
Measured
at the Cathode Band Terminal
0.2
0.2
D = t
p
/T
t
p
0
80
90
100
110
120
130
140
150
0
0
0.2
0.4
0.6
0.8
1.0
1.2
Lead Temperature (°C)
Average Forward Current
Fig. 1 - Max. Forward Current Derating Curve
Fig. 2 - Forward Power Loss Characteristics
Revision: 13-Aug-2018
Document Number: 88917
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
S1PB, S1PD, S1PG, S1PJ, S1PK, S1PM
www.vishay.com
Vishay General Semiconductor
100
30
Peak Forward
Surge
Current (A)
20
Junction Capacitance (pF)
1
10
100
25
15
10
10
5
0
1
0.1
1
10
100
Number of Cycles at 50 Hz
Reverse Voltage (V)
Fig. 3 - Max. Non-Repetitive Peak Forward Surge Current
Fig. 6 - Typical Junction Capacitance
100
1000
10
T
J
= 150 °C
Transient Thermal Impedance (°C/W)
1.6
1.8
2.0
Instantaneous Forward Current (A)
100
1
T
J
= 25 °C
0.1
10
T
J
= 125 °C
0.01
0.4
0.6
0.8
1.0
1.2
1.4
1
0.01
0.1
1
10
100
Instantaneous Forward Voltage (V)
t - Pulse Duration (s)
Fig. 4 - Typical Instantaneous Forward Characteristics
Fig. 7 - Typical Transient Thermal Impedance
100
Instantaneous Reverse Current (μA)
T
J
= 150 °C
10
T
J
= 125 °C
1
0.1
T
J
= 25 °C
0.01
10
20
30
40
50
60
70
80
90
100
Percent of Rated Peak Reverse Voltage (%)
Fig. 5 - Typical Reverse Leakage Characteristics
Revision: 13-Aug-2018
Document Number: 88917
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
S1PB, S1PD, S1PG, S1PJ, S1PK, S1PM
www.vishay.com
PACKAGE OUTLINE DIMENSIONS
in inches (millimeters)
SMP
(DO-220AA)
Cathode Band
0.012 (0.30) REF.
Vishay General Semiconductor
0.086 (2.18)
0.074 (1.88)
0.053 (1.35)
0.041 (1.05)
0.036 (0.91)
0.024 (0.61)
0.142 (3.61)
0.126 (3.19)
0.158 (4.00)
0.146 (3.70)
0.103 (2.60)
0.087 (2.20)
0.032 (0.80)
0.016 (0.40)
0.105
(2.67)
0.013 (0.35)
0.004 (0.10)
0.045 (1.15)
0.033 (0.85)
0.012 (0.30) 0.018 (0.45)
0.000 (0.00) 0.006 (0.15)
0.100
(2.54)
0.025 0.030
(0.635) (0.762)
0.050
(1.27)
Revision: 13-Aug-2018
Document Number: 88917
4
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
