PL-500SM-Z SERIES
Metal
Shell Auto-Coupling
Connectors
®
14 pole
capacity miniature circular connector
PL-500SM-Z FEATURES
Compact and secure, the
Pulse-Lok
500SM-Z Series connectors are Amphenol
Alden’s ideal solution for hand-held equipment and harsh environmental situations.
The
Pulse-Lok
®
500SM-Z durable metal shell will support your harshest of
interconnector requirements.
Overview (intuitive, compact, configurable)
Pulse-Lok
®
auto-latch / mating confirmation
Miniature 0.520” diameter metal circular shell
Up to 14 contact positions
Multiple and proprietary keying options available
3 various pad print color options
Up to 14 Contact
Positions
AF
TABLE A:
Number of Poles
14
10
8
7
6
5
4
3
2
1
1
Contact Size Pin
Max Wire Gauge
Ø
(mm)
0.5
0.5
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
1.5
26
26
22
22
22
22
22
22
22
22
16
Operating
Voltage Max
300 V RMS
300 V RMS
300 V RMS
300 V RMS
300 V RMS
300 V RMS
300 V RMS
300 V RMS
300 V RMS
300 V RMS
300 V RMS
2.5
2.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
5.0
0.52
Ø
Material
Connector Housing: Zinc Alloy, Nickel Plated
Molded Core Insulator: LCP
Contacts: Brass/Phosphor Bronze
30µ” Gold over 50µ” Nickel
Flammability Rating
Molded Contact Insulator (core): UL94 V-0
Mechanical
Mating Cycles: 5,000
Mating Force:
Mate: 5 lbs. Max
Un-mate:
1.5 lbs. Max
Unintended Extraction: 35 lbs. Min.
Backshell withdrawal: 4 lbs. Min.***
R
Cable Mount Receptacle Assembly
2.05
Shown with optional backshell
Mounts from
back of panel
to achieve an
IP-67 Seal
Rear Panel-Mount
Receptacle Assembly
D
Cable Mount Receptacle Kit
1.43
Select this component from Table B
2.0
0.63φ
0.63
Panel thickness range = 0.063 to 0.125
Select this component from Table B
*All dimensions shown in inches except where indicated
Standard color is a red pad print. See our online configurator for color options at :
www.amphenolalden.com/configurator
For additional information about this or any other Amphenol Alden product, please contact
an Amphenol Alden specialist today, www.AmphenolAlden.com.
T
SPECIFICATIONS
Environmental
Operating Temp: -20C to +105C**
Moisture Resistance: to IP-67 (mated)
Sterilizable: gamma & EtO**
Chem. Resistance: common OR cleaning solvents
**Dependent on overmold material
***Backshell sold separately
STANDARD CONTACT CONFIGURATIONS & SPECIFICATIONS
Operating
Current Max (A)*
Custom contact inserts are available. Consult factory.
*30C Heat Rise Limit
Order as a full cable assembly (Consult Factory)
Single or double ended
Customize your cable bundle
Overmolded strain relief
Add components to fulfill design requirements
Mated Contact
Resistance
(mΩ)
<50
<50
<50
<50
<50
<50
<50
<50
<50
<50
<50
STANDARD HOUSING OPTIONS
0.52
Ø
Cable Mount Plug Assembly
2.05
Shown with optional backshell
0.32 typ
Cable Mount Plug Kit
1.35
Select this component from Table B
Phone: 1(508)427-7000
E-mail: Info@AmphenolAlden.com
www.AmphenolAlden.com
1
Metal
Shell Auto-Coupling
Connectors
14 pole
capacity miniature circular connector
TABLE B:
Number of Poles
14
10
8
7
6
5
4
3
2
1 (22 AWG)
1 (16 AWG)
Cable Mount Receptacle
Solder Cup
326087
326084
326081
326078
326075
326072
326069
326066
326063
326060
326187
PL-500SM-Z SERIES
STANDARD PART NUMBERS
Cable Mount Plug
Solder Cup
325027
325024
325021
325018
325015
325012
325009
325006
325003
325060
325000
Note: Part numbers cover black housings in Key 1 configuration. For other color and housing options utilize the Amphenol Alden connector configurator located at
www.amphenolalden.com/configurator
Options Include:
Indicator Color Options
Mating Key Options
Panel-Mount Thickness Options
Red (Std.), White, Black
2 Standard Keys, Proprietary Keys Available
Up to .125 Standard
PCB (Panel-Mount Receptacles only)
AF
Receptacles & Cable Mount Plug
Solder Cup (Available for All)
0.50
Ø
Tiered solder cups provide easy access to center positions.
Canted cups facilitate quick and easy wire positioning.
Standard on 2-14 pole configurations
0.45
Request sales drawing for PCB
Mounting Templates
Receptacle Dust Cover
Backshell
R
P/N
107976
P/N
108194-02
(For 0.20” Cable Diameter)
Note: Black (std.) Gray (optional) & accessories sold separately
D
2.0
Cable Mount Receptacle Instructions:
AI-PL500SMZ-IR01 (1Pole, 16AWG)
AI-PL500SMZ-IR02 (1-14 Pole, 22/26AWG)
Panel-Mount Receptacle Instructions:
AI-PL500SMZ-PMR01 (1Pole, 16AWG)
AI-PL500SMZ-PMR02 (1-14 Pole, 22/26AWG)
For additional information about this, or any other Amphenol Alden product, please contact
an Amphenol Alden specialist today, www.AmphenolAlden.com.
T
Panel-Mount, Cut-Out Template
0.63
Ø
Mounting
Ring
Footprint
Rear Panel-Mount Receptacle
Solder Cup
PCB
326027
326147
326024
326144
326021
326141
326018
326138
326015
326135
326012
326132
326009
326129
326006
326126
326003
326123
326000
326120
326181
CONTACT TERMINATION OPTIONS
ACCESSORIES
Plug Soaking Cap
P/N
112058-01
ASSEMBLY INSTRUCTIONS
Cable Mount Plug Instructions:
AI-PL500SMZ-P01 (1Pole, 16AWG)
AI-PL500SMZ-P02 (1-14 Pole, 22/26AWG)
Note: recommended tooling included in assembly instructions
Phone: 1(508)427-7000
E-mail: Info@AmphenolAlden.com
www.AmphenolAlden.com
2
