Qualified to AEC-Q101 Standards for High Reliability
PPAP Capable (Note 4)
Part Number
DDTC113ZCA
DDTC123YCA
DDTC123JCA
DDTC143XCA
DDTC143FCA
DDTC143ZCA
DDTC114YCA
DDTC114WCA
DDTC124XCA
DDTC144VCA
DDTC144WCA
R1 (NOM)
1KΩ
2.2KΩ
2.2KΩ
4.7KΩ
4.7KΩ
4.7KΩ
10KΩ
10KΩ
22KΩ
47KΩ
47KΩ
SOT23
B
R1
Mechanical Data
Case: SOT23
Case Material: Molded Plastic, “Green” Molding Compound
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Finish – Matte Tin Plated Leads, Solderable per
MIL-STD-202, Method 208
Weight: 0.008 grams (approximate)
R2 (NOM)
10KΩ
10KΩ
47KΩ
10KΩ
22KΩ
47KΩ
47KΩ
4.7KΩ
47KΩ
10KΩ
22KΩ
OUT
3
C
IN B
R2
1
3
C OUT
E
1
IN
2
GND(0)
GND (0)
Top View
Device Schematic
Equivalent Inverter Circuit
Ordering Information
(Notes 3 & 4)
Product
DDTC113ZCA-7-F
DDTC123YCA-7-F
DDTC123JCA-7-F
DDTC143XCA-7-F
DDTC143FCA-7-F
DDTC143ZCA-7-F
DDTC143ZCAQ-7-F
DDTC143ZCAQ-13-F
DDTC114YCA-7-F
DDTC114YCAQ-7-F
DDTC114YCAQ-13-F
DDTC114WCA-7-F
DDTC124XCA-7-F
DDTC144VCA-7-F
DDTC144WCA-7-F
Notes:
Compliance
AEC-Q101
AEC-Q101
AEC-Q101
AEC-Q101
AEC-Q101
AEC-Q101
Automotive
Automotive
AEC-Q101
Automotive
Automotive
AEC-Q101
AEC-Q101
AEC-Q101
AEC-Q101
Marking
N02
N05
N06
N09
N10
N11
N11
N11
N14
N14
N14
N15
N18
N21
N22
Reel size (inches)
7
7
7
7
7
7
7
13
7
7
13
7
7
7
7
Tape width (mm)
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
2
E
Quantity per reel
3,000
3,000
3,000
3,000
3,000
3,000
3,000
10,000
3,000
3,000
10,000
3,000
3,000
3,000
3,000
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. Automotive products are AEC-Q101 qualified and are PPAP capable. Automotive, AEC-Q101 and standard products are electrically and thermally the
same, except where specified. For more information, please refer to http://www.diodes.com/quality/product_compliance_definitions/.
5. For packaging details, go to our website at http://www.diodes.com/products/packages.html.
