MICRO SWITCH™ V15 Series
Standard Basic Switches
Honeywell’s MICRO SWITCH™ V-Basic Standard Switch, V15 Series is an electromechanical switch designed to
provide outstanding value in a reliable global package. This switch is often ideal for “low-cost-of-failure” applications,
where the cost is minimal to replace or service any failure related to the switch. With a wide variety of operating forces,
and amperage ratings, the V15 is designed for numerous types of applications.
Available in both pin plunger and levered styles, the V15 Series also offers a multitude of termination styles to fit almost
any application.
What makes our switches better?
Wide choice of electrical ratings: 0.1 A, 5 A, 10 A, 16 A,
22 A, 26 A
Certified for global use: UL/cUL, ENEC, CQC
Available with pin plungers or integral levers to meet multiple
application and equipment requirements
Features
and Benefits
BROAD RANGE OF ELECTRICAL LOADS
Honeywell’s MICRO SWITCH™ V15 Series offers a broad range of electrical
loads (0.1
A, 5 A, 10 A, 16 A, 22 A, 26 A)
while maintaining precision operation
and application versatility. V15 Series has a long service life of over
one million
mechanical actuations.
Six load ratings! 13 terminations!
APPLICATION FLEXIBILITY
V15 Series switches perform a variety of functions as well as offering a choice of
actuation, termination, and operating characteristics that can allow for flexibility in
numerous types of applications.
SAVES TIME
With a broad current capacity, one switch package can control a wide range
of electrical loads. As requirements vary for applications, a standardized switch
package with multiple choice of actuators may help minimize costs and may
streamline the assembly process by allowing for increased flexibility within some
applications. Gold contacts are also available for controlling logic level/low energy
circuits.
BROAD RANGE OF ELECTRICAL LOADS
RELIABLE • GLOBAL ACCEPTANCE
2
sensing.honeywell.com
Potential Applications
VENDING MACHINESI
Serves as a snack dispenser limit switch, a snack selection switch, and/or a drink
machine valve motor cam switch
GAMING MACHINE
Often used for slot machine lever position, pinball lever switch, or in determing an
arcade joystick lever position
APPLIANCES
Used in water conditioner timer mechanisms, a control panel cover lock out, and
signals valve position that softener regeneration is in progress. May also be used to
indicate water pressure, float level, and door position in commercial appliances
ICE MAKERS
Indicates ice cube tray position, controls the water inlet valve, and used as a cycle
complete switch. May also be used in the ice cube or water dispenser mechanism
FURNACES
May be used in a furnace’s pressure switch to prevent overpressure in the
combustion chamber or backpressure in the exhaust line from an obstruction
POWER WASHERS
Often used to prevent seal blowout due to overpressure in water pumps
sensing.honeywell.com
3
V15 Series
V15S05 PRODUCT NOMENCLATURE
V15
Switch Type
S
Temperature
Grade
05
Electrical
Rating
—
C
Terminal
Type
1
Housing
Type
Basic
(blank)
Z
Circuit
Code
200
(at pin plunger max)
A
Lever
Position
Pin plunger,
no lever
(blank)
06
Lever
Type
No Lever
(blank)
—
K
Mounting
Holes
Metric
Ø 3,1 mm
(blank)
A
Special
Designator
A special designator
letter is used only
when there is a
special modification
to the switch.
Review Product
Specification to
determine the exact
differences. Below
is an example.
Operating Force
15 gf; 0,15 N
25 gf; 0,25 N
50 gf; 0,49 N
100 gf; 0,96 N
200 gf; 1,96 N
V15
Series
Standard
Basic
Switch
S
85 °C [185 °F]
(for “05” and “11”
ratings only)
05
11
0.1 A 48 Vdc/
125 Vac/250 Vac
5 A 125 Vac/250 Vac
C
D
E
F
U
Quick connect
6,30 mm x 0,80 mm
[0.250 in x 0.032 in]
Quick connect
4,70 mm x 0,80 mm
[0.187 in x 0.032 in]
Quick connect
4,70 mm x 0,50 mm
[0.187 in x 0.020 in]
Screw terminal
w/ pressure plate
Push-in terminal
(used only in combination
with “S11”)
Z
P
C
SPDT
SPST-NO
SPST-NC
015
025
050
100
200
*
11 A 125 Vac/250 Vac
1
2
Flat
Fully
flat
A
B
Far from
pin plunger
Near pin
plunger
01
02
03
04
05
06
**
Short
straight lever
Standard
straight lever
Long
straight lever
Simulated
roller lever
Roller lever
Long
roller lever
Special
K
USA
Ø 2,9 mm
A
Contact
gold-plated
* only available with U terminal type and 200 gf operating force.
** Additional code assigned for specials
V15T10 PRODUCT NOMENCLATURE
V15
Switch Type
T
Temperature
Grade
10
Electrical
Rating
—
C
Terminal
Type
1
Housing
Type
Basic
(blank)
Z
Circuit
Code
200
(at pin plunger max)
A
Lever
Position
Pin plunger,
no lever
(blank)
06
Lever
Type
No Lever
(blank)
—
K
Mounting
Holes
Metric
Ø 3,1 mm
(blank)
A
Special
Designator
A special designator
letter is used only
when there is a
special modification
to the switch.
Review Product
Specification to
determine the exact
differences. Below
is an example.
Operating Force
50 gf; 0,49 N
V15
Series
Standard
Basic
Switch
T
125 °C [257 °F]
10
0.5 A 125 Vdc
0.25 A 250 Vdc
4 A 125 Vac
(lamp load)
10 A 125 Vac/250 Vac
C
D
E
F
Quick connect
6,30 mm x 0,80 mm
[0.250 in x 0.032 in]
Quick connect
4,70 mm x 0,80 mm
[0.187 in x 0.032 in]
Quick connect
4,70 mm x 0,50 mm
[0.187 in x 0.020 in]
Screw terminal
w/ pressure plate
Z
P
C
SPDT
SPST-NO
SPST-NC
050
100
200
1
2
Flat
Fully
flat
100 gf; 0,96 N
200 gf; 1,96 N
A
B
Far from
pin plunger
Near pin
plunger
01
02
03
04
05
06
**
Short
straight lever
Standard
straight lever
Long
straight lever
Simulated
roller lever
Roller lever
Long
roller lever
Special
K
USA
Ø 2,9 mm
A
Contact
gold-plated
V15H16/T16/T22/H22/T26 PRODUCT NOMENCLATURE
V15
Switch Type
** Additional code assigned for specials
H
Temperature
Grade
16
Electrical
Rating
—
C
Terminal
Type
1
Housing
Type
(blank)
Z
Circuit
Code
200
(at pin plunger max)
A
Lever
Position
Pin plunger,
no lever
(blank)
06
Lever
Type
No Lever
(blank)
—
K
Mounting
Holes
(blank)
A
Special
Designator
A special designator
letter is used only
when there is a
special modification
to the switch.
Review Product
Specification to
determine the exact
differences. Below
is an example.
Operating Force
1
V15
Series
Standard
Basic
Switch
T
H
∆
125 °C [257 °F]
150 °C [302 °F]
10
16
22
26
1 A 30 Vdc
10 A 1/2 HP 125/250 Vac
(H temperature grade only)
C
D
E
F
H
K
L
M
N
P
R
S
T
**
Quick connect
6,30 mm x 0,80 mm
[0.250 in x 0.032 in]
Quick connect
4,70 mm x 0,80 mm
[0.187 in x 0.032 in]
Quick connect
4,70 mm x 0,50 mm
[0.187 in x 0.020 in]
Screw terminal
w/ pressure plate
RAST-5 250#
connector
Slot hole,
solder terminal
Left side,
PCB terminal
Short sholder
terminal
RAST-7 250#
connector
Straight
PCB terminal
Right side,
PCB terminal
Solder
terminal
Screw
terminal
Special
terminal
∆
1
Basic
Z
P
C
SPDT
SPST-NO
SPST-NC
100
100 gf; 0,96 N
200 gf; 1,96 N
300 gf; 2,84 N
400 gf; 3,92 N
Metric
Ø 3,1 mm
USA
Ø 2,9 mm
16 A 125 Vac/250 Vac
22 A 125 Vac/250 Vac
0.02 A 250 Vac
26 A 250 Vac
1
2
Flat
Fully
flat
200
300
400
A
B
Far from
pin plunger
Near pin
plunger
01
02
03
04
05
06
**
Short
straight lever
Standard
straight lever
Long
straight lever
Simulated
roller lever
Roller lever
Long
roller lever
Special
K
A
Contact
gold-plated
“H” temperature grade not allowed with “26” electrical rating
“100” gf not allowed with “26” electrical rating
** Additional code assigned for specials
4
sensing.honeywell.com
MICRO SWITCH™ Standard Basic Switches
Table 1. Specifications
Characteristic
Circuitry
Operating force
Parameter
SPDT, SPNO, SPNC
0,15 N to 3,92 N [15g to 400 g]
quick connect; 6,35 mm x 0,80 mm [0.250 in x 0.032 in]
quick connect 4,80 mm x 0,80 mm [ 0.187 in x 0.032 in]
quick connect 4,80 mm x 0,50 mm [0.187 in x 0.020 in]
push-in terminals; RAST-5 250#; RAST-7 250#; short solder; slot-hole solder; solder;
right side PCB; left side PCB; straight PCB; screw; oblique screw
pin plunger, integral lever options
ENEC, CQC, UL, cUL
code S: -25 °C to 85 °C [-13 °F to 185 °F]
code T: -25 °C to 125 °C [-13 °F to 257 °F]
code H: -25 °C to 150 °C [-13 °F to 302 °F]
1 million cycles (except for 200g versions of V15S05 and V15T10 which are 500,000 cycles)
silver, gold-plated
PBT thermoplastic polyester
Termination
Actuators
Agency certification
Operating temperature
(manufacturer specified)
Mechanical life (cycles)
Contact material
Housing material
Table 2. Electrical Ratings
Rating/Nomenclature Code
UL/cUL (CUL 61058-1, File 12252)
Americas
5 GPA 125/250 Vac; 0.1 GPA 125/250 Vac
1/10 HP 125/250 Vac
0.1 RA 48 Vdc
10,000 cycles
10 GPA 125/250 Vac
1/2 HP 125/250 Vac
1.0 RA 30 Vdc
100,000 cycles
11 GPA 125/250 Vac
1/3 HP 125/250 Vac
0.5 RA 125 Vdc
0.25 RA 250 Vdc
10,000 cycles
11 (3) 125/250 Vac
50,000 cycles
16 GPA 125/250 Vac
1/2 HP 125/250 Vac
10,000 cycles
22 GPA 125/250 Vac
1 HP 125/250 Vac
10,000 cycles
n/a
• RA = Resistive Amps (Resistive Load)
• GPA = General Purpose Amps (Inductive Load,
75 % to 80 % power factor)
• VL = Lamp Load
ENEC (IEC 61058-1) Europe
CQC (GB15092-1) Asia-Pacific
0.1 A 125/250 Vac; 0.1 A 48 Vdc
5 (2.5) A 125/250 Vac
50,000 cycles
05
H10
n/a
T10
0.5 A 125 Vdc; 0.25 A 250 Vdc
10 (3) A 125/250 Vac
50,000 cycles
11 (3) 125/250 Vac
50,000 cycles
16 (4) A 250 Vac
50,000 cycles
22 (8) A 250 Vac
25,000 cycles
0.02 A 250 Vac
26 (10) A 250 Vac
50,000 cycles
• XX (Y) = XX max. resistive value (Amps) and (Y) max.
inductive value (Amps)
S11
16
22
26
sensing.honeywell.com
5
