CMD / CMA24 Series
•
Ratings from 25A to 125A @ 24-280 VAC
•
SCR output for heavy industrial loads
•
AC or DC control
•
LED input status indicator
•
Zero-crossing (resistive loads) or random-fire (inductive loads) output
•
IP20 touch-safe housing
•
Standard box-clamp connections
Panel Mount
PRODUCT SELECTION
Control Voltage
3-32 VDC
90-140 VAC
18-36 VAC
25A
CMD2425
CMA2425
CMA2425E
50A
CMD2450
CMA2450
CMA2450E
75A
CMD2475
CMA2475
CMA2475E
90A
CMD2490
CMA2490
CMA2490
110A
CMD24110
CMA24110
CMA24110E
CMD24125
CMA24125
CMA24125E
125A
AVAILABLE OPTIONS
Series
Control Voltage
A:
AC (90-140V)
D:
DC (4-32V)
Load Current
25:
5 Amps
50:
10 Amps
75:
75 Amps
90:
90 Amps
110:
110 Amps
125:
125 Amps
Blank:
No Internal Overvoltage Protection
P:
Internal Overvoltage Protection
CM
A
24
25
E
P
-10
Switching Mode
Blank:
Zero cross Turn-on
-10:
Random Turn-On
Required for valid part number
For options only and not required for valid part number
Operating Voltage
24:
24-280 VAC
Input Range
Blank:
Standard Input
E:
18-36 VAC
OUTPUT SPECIFICATIONS
(1)
Description
Operating Voltage (47-63Hz) [Vrms]
Transient Overvoltage [Vpk]
Maximum Off-State Leakage Current @ Rated Voltage [mA]
Minimum Off-State dv/dt @ Maximum Rated Voltage [V/ sec]
(2)
Maximum Load Current [Arms]
(3)
Minimum Load Current [Arms]
Maximum Surge Current (50/60Hz, 1 Cycle) [Apk]
Maximum On-State Voltage Drop @ Rated Current [Vpk]
Thermal Resistance Junction to Case (Rjc) [°C/W]
Maximum I² t for Fusing (50/60Hz, 1/2 cycle) [A² sec]
Minimum Power Factor (with Maximum Load)
25A
24-280
600
10
500
25
0.15
239/250
1.6
1.02
285/259
0.5
50A
24-280
600
10
500
50
0.15
597/625
1.6
0.63
1779/1621
0.5
75A
24-280
600
10
500
75
0.25
954/1000
1.6
0.31
4555/4150
0.5
90A
24-280
600
10
500
90
0.25
1145/1200
1.6
0.28
6560/5976
0.5
110A
24-280
600
10
500
110
0.25
1432/1500
1.6
0.25
10249/9338
0.5
125A
24-280
600
10
500
125
0.025
1670/1750
1.6
0.22
13950/12709
0.5
FDE-07-01 REV. A
Do not forget to visit us at:
www.crydom.com
Copyright © 2017 Crydom Inc. Specifications subject to change without notice.
DataSheet
INPUT SPECIFICATIONS
(1)
Description
Control Voltage Range
Maximum Reverse Voltage
Maximum Turn-On Voltage
Minimum Turn-Off Voltage
Typical Input Current @ max turn-on voltage
Nominal Input Impedance [Ohms]
Maximum Turn-On Time [msec]
(4)
Maximum Turn-Off Time [msec]
Panel Mount
CMA
90-140 Vrms
-
90 Vrms
10 Vrms
-
15 mA @ 120 Vrms
10
40
CMD
3-32 VDC
32 VDC
3.0 VDC
1.0 VDC
30 mA
17 mA @ 5 VDC
1/2 Cycle
1/2 Cycle
GENERAL SPECIFICATIONS
Description
Dielectric Strength, Input/Output (50/60Hz)
Minimum Insulation Resistance (@ 500 V DC)
Maximum Capacitance, Input/Output
Ambient Operating Temperature Range
Ambient Storage Temperature Range
Status Indicating Display
Weight (typical)
Encapsulation
Terminals
Maximum Wire Size-Output:
Maximum Wire Size-Input:
Recommended Terminal Screw Torque Range:
Parameters
4000 Vrms
10
9
Ohms
8 pF
-40ºC to 80ºC
-40ºC to 125ºC
Green LED
3.0 oz (86.5 g)
Thermally conductive Epoxy
Cage type
AWG 8 (3.8mm)
AWG 12 (2.5mm)
Output: 10-15 in lb (1.1-1.7 Nm)
Input: 5-6 in lb (0.6-0.7 Nm)
1)
All parameters at 25°C unless otherwise specified.
2)
Off-State dv/dt test method per EIA/NARM standard RS-443, paragraph 13.11.1
3)
HEAT SINKING REQUIRED, FOR DERATING curves see page 2.
4)
Turn-on time for DC control random turn-on versions is 0.02msec
5)
Input circuitry incorporates active current limiter.
GENERAL NOTES
Do not forget to visit us at:
www.crydom.com
Copyright © 2017 Crydom Inc. Specifications subject to change without notice.
DataSheet
THERMAL DERATE INFORMATION
25A
30
1°C/W
3°C/W
2°C/W
Panel Mount
75A
CURRENT DERATING CURVES
50A
60
90
95
Power Dissipation
Power Dissipation
1.5°C/W
Power Dissipation
100
Base Plate Temp [°C]
25
20
15
10
5
0
5
10
15
20
25
Base Plate Temp [°C]
.5°C/W .3°C/W
40
3°C/W
100
110
60
100
110
1°C/W
110
20
NO HEATSINK
30
120
0
15
30
45
60
75
20
40
60
80
NO HEATSINK
120
60
80
120
60
80
0
20
40
10
20
30
40
50
20
40
Load Currect [Arms]
Max Ambient Temp. [°C]
Load Currect [Arms]
Max Ambient Temp. [°C]
Load Currect [Arms]
Max Ambient Temp. [°C]
90A
120
110A
Base Plate Temp [°C]
Base Plate Temp [°C]
.5°C/W
.2°C/W
.4°C/W
125A
Base Plate Temp [°C]
Power Dissipation
.4°C/W
90
160
90
.2°C/W
160
.4°C/W
90
.2°C/W
Power Dissipation
Power Dissipation
80
1°C/W
100
110
120
80
40
.5°C/W
120
80
.5°C/W
100
1°C/W
100
1°C/W
40
120
0
20
40
60
80
0
20
40
60
80
110
110
120
40
0
120
0
30
60
90
120
0
20
40
60
80
30
60
90
120
0
20
40
60
80
Load Currect [Arms]
Max Ambient Temp. [°C]
Load Currect [Arms]
Max Ambient Temp. [°C]
Load Currect [Arms]
Max Ambient Temp. [°C]
MECHANICAL SPECIFICATIONS
Tolerances: ±0.02 in / 0.5 mm
All dimensions are in: inches [millimeters]
AGENCY APPROVALS
Agency Approvals
Designed in accordance with the requirements of IEC 62314
E116949
E116950
LR 81689
REG.-Nr. 12691 (exept 110, 125A models)
Rev. 081017
ECN 20296
Do not forget to visit us at:
www.crydom.com
Copyright © 2017 Crydom Inc. Specifications subject to change without notice.
Base Plate Temp [°C]
1°C/W
.5°C/W
90
95
DataSheet
