P6LU-2405Z: Description3KV ISOLATED 1W UNREGULATED DUAL OUTPUT SIP7; CategoryAnalog mixed-signal IC The signal circuit; File Size150KB，2 Pages; ManufacturerPEAK electronics; Websitehttp://www.peak-electronics.de/

Download Datasheet Parametric Compare View All

P6LU-2405Z Overview

3KV ISOLATED 1W UNREGULATED DUAL OUTPUT SIP7

P6LU-2405Z Parametric

Parameter Name	Attribute value
Maker	PEAK electronics
package instruction	,
Reach Compliance Code	unknow

Preview

Download Datasheet

View All

Telefon: +49 (0) 6135 931069

Telefax: +49 (0) 6135 931070

www.peak-electronics.de

info@peak-electronics.de

M1 SERIES

P6LU-XXXXZ 3KV ISOLATED 1W UNREGULATED DUAL OUTPUT SIP7

Available Inputs:

5, 12 and 24 VDC

Available Outputs:

(+/-) 3.3, 5, 7.2, 12, 15 and 18 VDC

Other specifications please enquire.

Electrical Specifications

(Typical at + 25° C, nominal input voltage, rated output current unless otherwise specified)

Input Specifications

Voltage range

Filter

Isolation Specifications

Rated voltage

Leakage current

Resistance

Capacitance

Output Specifications

Voltage accuracy

Ripple and noise (at 20 MHz BW)

Short circuit protection

Line voltage regulation

Load voltage regulation

Temperature coefficient

General Specifications

Efficiency

Switching frequency

Environmental Specifications

Operating temperature (ambient)

Storage temperature

Derating

Humidity

Cooling

Physical Characteristics

Dimensions SIP

Weight

Case material

+/- 10 %

Capacitors

3000 VDC

1 mA

Ohm

60 pF typ.

+/- 5 %, max.

75 mV p-p, max.

Momentary

+/- 1,2 % / 1,0 % of Vin

+/- 8 %, load = 20 ~ 100 %

+/- 0,02 % / °C

70 % to 85 %

125 KHz, typ.

- 40° C to + 85° C

- 55 °C to + 125 °C

See graph

Up to 90 %, non condensing

Free air convection

19,50 x 6,00 x 9,50 mm

0,76 x 0,24 x 0,37 inches

2 g, 3 g for the 48 VDC variants

Non conductive black plastic

Examples of Partnumbers

PART

NO.

INPUT

VOLTAGE

(VDC)

INPUT

CURRENT

NO LOAD

INPUT

CURRENT

FULL

LOAD

OUTPUT

VOLTAGE

(VDC)

OUTPUT

CURRENT

(max. mA)

EFFICIENCY FULL LOAD

(% TYP.)

P6LU-053R3Z

P6LU-0505Z

P6LU-1205Z

P6LU-1212Z

P6LU-1215Z

P6LU-2405Z

P6LU-247R2Z

P6LU-2412Z

285

281

119

104

107

+/- 3,3

+/- 5

+/ - 12

+/- 15

+/- 5

+/- 7,2

+/- 12

+/- 150

+/- 100

+/- 42

+/- 34

+/- 100

+/- 69

+/ 42
