P6LU

Description
4KV ISOLATED 1W UNREGULATED DUAL OUTPUT SIP7
File Size151KB，2 Pages
ManufacturerPEAK electronics
Websitehttp://www.peak-electronics.de/
Download Datasheet Compare View All

P6LU Overview

4KV ISOLATED 1W UNREGULATED DUAL OUTPUT SIP7

Preview

Download Datasheet
Telefon: +49 (0) 6135 931069
Telefax: +49 (0) 6135 931070
www.peak-electronics.de
info@peak-electronics.de
M1 SERIES
P6LU-XXXXZH40 4KV ISOLATED 1W UNREGULATED DUAL OUTPUT SIP7
Available Inputs:
5, 12, and 24 VDC
Available Outputs:
(+/-) 3.3, 5, 7.2, 12, 15 and 18 VDC
Other specifications please enquire.
Electrical Specifications
(Typical at + 25° C, nominal input voltage, rated output current unless otherwise specified)
Input Specifications
Voltage range
Filter
Isolation Specifications
Rated voltage
Leakage current
Resistance
Capacitance
Output Specifications
Voltage accuracy
Ripple and noise (at 20 MHz BW)
Short circuit protection
Line voltage regulation
Load voltage regulation
Temperature coefficient
General Specifications
Efficiency
Switching frequency
Environmental Specifications
Operating temperature (ambient)
Storage temperature
Derating
Humidity
Cooling
Physical Characteristics
Dimensions SIP
Weight
Case material
+/- 10 %
Capacitors
4000 VDC
1 mA
10
9
Ohm
60 pF typ.
+/- 5 %, max.
75 mV p-p, max.
Momentary
+/- 1,2 % / 1,0 % of Vin
+/- 8 %, load = 20 ~ 100 %
+/- 0,02 % / °C
70 % to 80 %
125 KHz, typ.
- 40° C to + 85° C
- 55 °C to + 125 °C
See graph
Up to 90 %, non condensing
Free air convection
19,50 x 6,00 x 9,50 mm
0,76 x 0,24 x 0,37 inches
2 g, 3 g for the 48 VDC variants
Non conductive black plastic
Examples for Partnumbers
PART
NO.
INPUT
VOLTAGE
(VDC)
INPUT
CURRENT
NO LOAD
INPUT
CURRENT
FULL
LOAD
OUTPUT
VOLTAGE
(VDC)
OUTPUT
CURRENT
(max. mA)
EFFICIENCY FULL LOAD
(% TYP.)
P6LU-0505ZH40
P6LU-0512ZH40
P6LU-0515ZH40
P6LU-1205ZH40
P6LU-1212ZH40
P6LU-1215ZH40
P6LU-243R3ZH40
P6LU-2405ZH40
P6LU-2412ZH40
5
5
5
12
12
12
24
24
24
16
18
20
11
10
15
5
6
8
281
253
250
119
104
107
56
55
55
+/- 5
+/- 12
+/- 15
+/- 5
+/ - 12
+/- 15
+/- 3,3
+/- 5
+/- 12
+/- 100
+/- 42
+/- 34
+/- 100
+/- 42
+/- 34
+/- 150
+/- 100
+/ 42
71
79
80
70
80
78
74
76
76
