Cannon Trident Connectors
Machined
Crimp Contacts
•
13 A current rating.
•
Separate contact and retention spring.
•
Up to 500 mating cycles.
•
Variety of plating options.
•
Full support tooling available,
see pages 74-75.
Size 16 AWG,
No Insulation Grip
Pin
T3P Contacts
Socket
Size 20 to 26 AWG,
Insulation Grip
Wire Range
mm
2
0,08 - 0,23
0,08 - 0,23
0,20 - 0,24
0,20 - 0,24
0,25 - 0,50
0,25 - 0,50
0,44 - 0,64
0,44 - 0,64
0,60 - 1,51
0,60 - 1,51
Wire
Size
26 AWG
26 AWG
24 AWG
24 AWG
22 AWG
22 AWG
20 AWG
20 AWG
16 AWG
16 AWG
Part Number (Pack of 100)
Contact Gold Plating
(X)
Gold Plating
(Y)
Tin Plating
Pin
192991-0101 192991-0100 192991-0102
Socket
192991-0054 192991-0042 192991-0048
Pin
192991-0093 192991-0092 192991-0094
Socket
192991-0055 192991-0043 192991-0049
Pin
192991-0097 192991-0096 192991-0098
Socket
192991-0056 192991-0044 192991-0050
Pin
192991-0089 192991-0088 192991-0090
Socket
192991-0058 192991-0046 192991-0052
Pin
192991-0085 192991-0084 192991-0086
Socket
192991-0059
192991-0047 192991-0053
Insulation
Diameter
0,90 (.035) - 1,40 (.055)
0,90 (.035) - 1,40 (.055)
1,05 (.041) - 1,60 (.062)
1,05 (.041) - 1,60 (.062)
1,60 (.062) - 2,15 (.084)
1,60 (.062) - 2,15 (.084)
1,60 (.062) - 2,10 (.082)
1,60 (.062) - 2,10 (.082)
Without insulation support
Without insulation support
Strip Length
Color Band
5,08 (.200)±0,25 (.009)
Black
5,08 (.200)±0,25 (.009)
Black
5,08 (.200)±0,25 (.009)
Blue
5,08 (.200)±0,25 (.009)
Blue
5,08 (.200)±0,25 (.009)
Red
5,08 (.200)±0,25 (.009)
Red
5,08 (.200)±0,25 (.009) Green
5,08 (.200)±0,25 (.009) Green
7,11 (.279)±0,25 (.009)
Black
7,11 (.279)±0,25 (.009)
Black
(Y) Gold plating Pin: 0,4 µ m (16 µ in.). Gold plating Socket: 0,75 µ m (30 µ in.).
(X) Gold plating Pin & Socket: 3 µ m (120 µ in.).
Machined
Earth (First Mate/Last
Break) Contacts
•
13 A current rating.
•
Separate contact and retention spring.
•
Up to 500 mating cycles.
•
Variety of plating options.
•
Full support tooling available,
see pages 74-75.
Size 16 AWG,
No Insulation Grip
Pin
Socket
Size 20 AWG,
Insulation Grip
Part Number (Pack of 100)
Insulation
Diameter
1,60 (.062) - 2,10 (.082)
1,60 (.062) - 2,10 (.082)
Without insulation support
Without insulation support
Color
Band
Green
Green
Black
Black
Wire Range
mm
2
0,44 - 0,64
0,44 - 0,64
0,60 - 1,51
0,60 - 1,51
Wire
Size
20 AWG
20 AWG
16 AWG
16 AWG
Contact Gold Plating
(Y)
Pin
192991-0164
Socket
192991-0207
Pin
192991-0160
Socket
192991-0208
Description
T3P20ME1LY
T3P20FE1LY
T3P16ME1LY
T3P16FE1LY
5,08
5,08
7,11
7,11
Strip Length
(.200)±0,25 (.009)
(.200)±0,25 (.009)
(.279)±0,25 (.009)
(.279)±0,25 (.009)
(Y) Gold plating Pin: 0,4 µ m (16 µ in.). Gold plating Socket: 0,75 µ m (30 µ in.).
For Gold Flash Plating, please consult the factory.
Dimensions shown in mm (inch)
Specifications and dimensions subject to change
www.ittcannon.com
