Product Bulletin OPB760T
June 1996
Photologic
®
Reflective Object Sensors
Types OPB760T, OPB761T, OPB762T, OPB763T
Features
•
Choice of mounting configurations
•
Choice of output configurations
Description
The OPB760T series of reflective
assemblies feature Photologic
®
output. This electrical output can be
specified as either TTL Totem Pole or
TTL Open Collector. Either may be
supplied with inverter or buffer output
polarity. All have the added stability of a
built-in hysteresis amplifier.
Absolute Maximum Ratings
(T
A
= 25
o
C unless otherwise noted)
Supply Voltage, V
CC
(Not to exceed 3 sec.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 V
Storage Temperature Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40
o
C to +85
o
C
Operating Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40
o
C to +70
o
C
Lead Soldering Temperature [1/16 inch (1.6 mm) from case for 5 sec. with soldering
iron] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240
o
C
(1)
Input Diode Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 mW
(2)
Output Photologic
®
Power Dissipation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 mW
(3)
Total Device Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300 mW
(4)
Voltage at Output Lead (Open Collector Output) . . . . . . . . . . . . . . . . . . . . . . . . . . 35 V
Diode Forward D.C. Current. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 mA
Diode Reverse D.C. Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 V
Notes:
(1)
(2)
(3)
(4)
(5)
RMA flux is recommended. Duration can be extended to 10 sec. max. when flow soldering.
Derate linearly 2.22 mW/
o
C above 25
o
C.
Derate linearly 4.44 mW/
o
C above 25
o
C.
Derate linearly 6.66 mW/
o
C above 25
o
C.
The OPB760T thru OPB763T series are terminated with .020" square leads designed for
printed circuit board mounting.
(6) Normal application would be with light source blocked, simulated by I
F
= 0mA.
(7) Tested at d = 0.080" from a 90% diffuse white test surface.
(8) Tested at d = 0.080", 0.150" and 0.220" from a 90% diffuse white test surface. Reference:
Eastman Kodak, Catalog #1257795.
(9) Tested at d = 0.080", 0.150" and 0.220" from a 5% diffuse black test surface.
(10) All parameters tested using pulse technique.
Mounting Options
OPB760N series PC board mount,
without mounting tabs
OPB760T series PC board mount, with
two mounting tabs
OPB770N series wire leads with
connector, without mounting tabs
OPB770T series wire leads with
connector, with two mounting tabs
Optek Technology, Inc.
1215 W. Crosby Road
Carrollton, Texas 75006
11-54
(972) 323-2200
Fax (972) 323-2396
Types OPB760T, OPB761T, OPB762T, OPB763T
Electrical Characteristics
(T
A
= -40
o
C to +70
o
C unless otherwise noted)
SYMBOL
Input Diode
V
F
I
R
V
CC
PARAMETER
MIN TYP MAX UNITS
1.8
100
4.75
5.25
10
10
V
µA
V
mA
mA
TEST CONDITIONS
I
F
= 40 mA, T
A
= 25
o
C
V
R
= 2 V, T
A
= 25
o
C
Forward Voltage
Reverse Current
Operating D.C. Supply Voltage
Low Level Supply Current:
Buffered Totem-Pole Output
Buffered Open-Collector Output
Inverted Totem-Pole Output
Inverted Open-Collector Output
High Level Supply Current:
Buffered Totem-Pole Output
Buffered Open-Collector Output
Inverted Totem-Pole Output
Inverted Open-Collector Output
High Level Output Voltage:
Buffered Open-Collector Output
Output Photologic
®
Sensor
I
CCL
V
CC
= 5.25 V, I
F
= 0 mA
(6)(7)
Output Open
V
CC
= 5.25 V, I
F
= 25 mA
(7)
Output Open
V
CC
= 5.25 V, I
F
= 25 mA
(7)
Output Open
V
CC
= 5.25 V, I
F
= 0 mA
(6)(7)
Output Open
V
CC
= 4.75 V, V
OH
= 30 V
I
F
= 25 mA, T
A
= 25
o
C
V
CC
= 4.75 V, V
OH
= 30 V,
I
F
= 0 mA, T
A
= 25
o
C
V
CC
= 5 V, T
A
= 25
o
C
(8)
V
CC
= 5 V
(8)
I
CCH
10
10
mA
mA
100
100
25
µA
µA
mA
I
OH
Inverted Open-Collector Output
LED Positive-Going Threshold Current
Hysteresis
Short Circuit Output Current:
Buffered Totem-Pole Output
Low Level Output Voltage:
Buffered Totem-Pole Output
Buffered Open-Collector Output
Inverted Totem-Pole Output
Inverted Open-Collector Output
-15
I
F
(+)
I
F
(+)/I
F
(-)
I
OS
-100
mA
V
CC
= 5.25 V, I
F
= 25 mA
(7)
Output = GND
V
CC
= 4.75 V, I
OL
= 12.8 mA
I
F
= 0 mA
(6)(7)
V
CC
= 4.75 V, I
OL
= 12.8 mA
I
F
= 25 mA
(6)(7)
V
CC
= 4.75 V, I
OL
= 12.8 mA
I
F
= 30 mA
(9)
V
CC
= 4.75 V, I
OH
= -800
µA
I
F
= 25 mA
(7)
V
CC
= 4.75 V, I
OH
= -800
µA
I
F
= 0 mA
(6)(7)
V
CC
= 4.75 V, I
OH
= -800
µA
I
F
= 30 mA
(9)
V
OL
0.4
0.4
V
V
V
OL
Low Level Output Voltage:
Buffered Totem-Pole Output
Buffered Open-Collector Output
High Level Output Voltage:
Buffered Totem-Pole Output
0.4
V
2.4
2.4
V
V
V
OH
Inverted Totem-Pole Output
High Level Output Voltage:
Inverted Totem-Pole Output
Inverted Open-Collector
V
OH
2.4
V
Optek reserves the right to make changes at any time in order to improve design and to supply the best product possible.
Optek Technology, Inc.
1215 W. Crosby Road
Carrollton, Texas 75006
(972) 323-2200
Fax (972) 323-2396
11-55
