1423155-9: DescriptionPOWER/SIGNAL RELAY, SPDT, MOMENTARY, 125VDC (COIL), 10A (CONTACT), 48VDC (CONTACT), SOCKET MOUNT; CategoryMechanical and electronic products relay; File Size98KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

1423155-9 Overview

POWER/SIGNAL RELAY, SPDT, MOMENTARY, 125VDC (COIL), 10A (CONTACT), 48VDC (CONTACT), SOCKET MOUNT

1423155-9 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Reach Compliance Code	compliant
ECCN code	EAR99
Is Samacsys	N
body width	45 mm
body height	109 mm
Body length or diameter	45 mm
Maximum coil voltage (DC)	125 V
Contact (AC) maximum rated R load	10A@220VAC
Maximum contact current (AC)	10 A
Maximum contact current (DC)	10 A
Contact (DC) maximum rated R load	10A@48VDC
Maximum contact voltage (AC)	220 V
Maximum contact voltage (DC)	48 V
Contact/Output Power Type	AC/DC
Manufacturer's serial number	1423155
Installation features	SOCKET MOUNT
Maximum operating temperature	60 °C
Minimum operating temperature
physical size	45mm x 45mm x 109mm
Guideline	CSA; UL
Relay action	MOMENTARY
Relay function	SPDT
Relay type	POWER/SIGNAL RELAY
surface mount	NO
Termination type	SNAP-ON
Base Number Matches	1
