1437590-1

Description
DIP Switch, SLIDE DIP SWITCH-2SWITCHES, SPST, LATCHED,0.02A, 20VDC, THROUGH HOLE-STRAIGHT
File Size102KB，1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric Compare View All

1437590-1 Overview

DIP Switch, SLIDE DIP SWITCH-2SWITCHES, SPST, LATCHED,0.02A, 20VDC, THROUGH HOLE-STRAIGHT

1437590-1 Parametric

Parameter NameAttribute value
Brand NameAlcoswitch
Objectid1807798242
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresLOW PROFILE
body width6.04 mm
body height4.3 mm
Body length or diameter6.04 mm
Maximum contact current (DC)0.02 A
Contact (DC) maximum rated R load.02A@20VDC
Maximum contact voltage (DC)20 V
Electrical life1000 Cycle(s)
JESD-609 codee0
Installation featuresTHROUGH HOLE-STRAIGHT
Number of switching segments2
Maximum operating temperature85 °C
Minimum operating temperature-30 °C
sealTAPE SEALED
surface mountNO
Switch actionLATCHED
switch functionSPST
Switch typeSLIDE DIP SWITCH
Terminal surfaceTIN LEAD
Termination typeSOLDER

Preview

Download Datasheet
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Switches
>
Product Feature Selector
> Product Details
GDB02 Product Details
Live Product Chat
Product Photo
DIP, Rotary DIP, SIP Switches and DIP Shunts - Standard
Not EU R oHS or ELV C om plia nt
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
GDB02
(1437590-1)
T E I nternal N umber: 1 4 3 7 5 9 0 - 1
Product Highlights:
l
DIP Switch
l
PC B Mount Style = Through Hole
l
Single Pole - Single Throw C onfiguration (Pole-Throw)
l
Actuator Style = Flush, Rocker (Top Actuated)
l
Sealed
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
ALC OSWITC H PRODUC TS
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = DIP Switch
l
PC B Mount Style = Through Hole
l
C onfiguration (Pole-Throw)
= Single Pole - Single Throw
l
Actuator Style
= Flush, Rocker (Top Actuated)
l
Sealed = Yes
l
Number of Switches
= 2
Termination Related Features:
l
Seal Type = Tape
Body Related Features:
l
Series = GD
l
C enterline (mm [in]) = 2.54 [0.100]
l
Length (mm [in]) = 6.04 [0.238]
Contact Related Features:
l
Auto-Insertable = Yes
l
C ontact Base Material = C opper Alloy
l
C ontact Mating Area Plating Material = Gold
Housing Related Features:
l
Housing C olor = Black
l
Housing Material = PPS
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C
Other:
l
Brand = Alcoswitch
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Provide Website Feedback
|
Need Help?
Home
|
C ustomer Support
|
Suppliers
|
Site Map
|
Privacy Policy
|
Browser Support
©
2009 Tyco Electronics C orporation All Rights Reserved

1437590-1 Related Products

1437590-1 GDB02
Description DIP Switch, SLIDE DIP SWITCH-2SWITCHES, SPST, LATCHED,0.02A, 20VDC, THROUGH HOLE-STRAIGHT ROCKER SWITCH,STRAIGHT,SPDT,PC TAIL TERMINAL,ROCKER
Brand Name Alcoswitch Alcoswitch
Reach Compliance Code unknown unknow
Body length or diameter 6.04 mm 6.04 mm
Installation features THROUGH HOLE-STRAIGHT THROUGH HOLE-STRAIGHT
Number of switching segments 2 2
seal TAPE SEALED TAPE SEALED
surface mount NO NO
Switch action LATCHED LATCHED
switch function SPST SPST
Switch type SLIDE DIP SWITCH SLIDE DIP SWITCH
Termination type SOLDER SOLDER
