ADG222KN

Description
QUAD 1-CHANNEL, SGL POLE SGL THROW SWITCH, PDIP16, PLASTIC, DIP-16
CategoryAnalog mixed-signal IC    The signal circuit
File Size912KB,7 Pages
ManufacturerRochester Electronics
Websitehttps://www.rocelec.com/
Related ProductsFound14parts with similar functions to ADG222KN
Download Datasheet Parametric View All

ADG222KN Overview

QUAD 1-CHANNEL, SGL POLE SGL THROW SWITCH, PDIP16, PLASTIC, DIP-16

ADG222KN Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
MakerRochester Electronics
Parts packaging codeDIP
package instructionPLASTIC, DIP-16
Contacts16
Reach Compliance Codeunknown
Is SamacsysN
Analog Integrated Circuits - Other TypesSPST
JESD-30 codeR-PDIP-T16
JESD-609 codee0
length19.055 mm
Humidity sensitivity levelNOT APPLICABLE
Nominal Negative Supply Voltage (Vsup)-15 V
Number of channels1
Number of functions4
Number of terminals16
Nominal off-state isolation80 dB
On-state resistance matching specifications5 Ω
Maximum on-state resistance (Ron)90 Ω
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
encapsulated codeDIP
Package shapeRECTANGULAR
Package formIN-LINE
Peak Reflow Temperature (Celsius)NOT APPLICABLE
Certification statusCOMMERCIAL
Maximum seat height4.32 mm
Nominal supply voltage (Vsup)15 V
surface mountNO
Maximum disconnect time250 ns
Maximum connection time300 ns
technologyCMOS
Temperature levelINDUSTRIAL
Terminal surfaceTIN LEAD
Terminal formTHROUGH-HOLE
Terminal pitch2.54 mm
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT APPLICABLE
width7.62 mm
Base Number Matches1
