RP153L SERIES
150mA DUAL LDO REGULATOR WITH 2 INPUT PINS
NO. EA-201-111020
OUTLINE
The RP153L Series are CMOS-based voltage regulator ICs with high output voltage accuracy, low supply
current, low dropout, and high ripple rejection. Each of these voltage regulator ICs consists of a voltage
reference unit, an error amplifier, resistors for setting output voltage, a current limit circuit, and a chip enable
circuit.
These ICs perform with low dropout voltage due to built-in transistor with low ON resistance, and a chip
enable function prolongs the battery life of each system. The line transient response and load transient
response of the RP153L Series are excellent, thus these ICs are very suitable for the power supply for
hand-held communication equipment.
The output voltage of these ICs is internally fixed with high accuracy. Since the package for these ICs are
DFN1216-8, dual LDO regulators are included in each package are high density mounting of the ICs on boards
is possible.
In RP153L, the power supply of each circuit can be individually supplied. The transient response
characteristic of D and E Version is improved.
FEATURES
•
•
•
•
•
•
•
•
•
•
•
•
•
Supply Current ..................................................................... Typ. 40μA×2 (VR1&VR2)
Supply Current (D/E Version)............................................... Typ. 85μA×2 (VR1&VR2)
Standby Current ................................................................... Typ. 0.1μA×2 (VR1&VR2)
Ripple Rejection ................................................................... Typ. 70dB (f=1kHz)
Input Voltage Range............................................................. 1.4V to 5.25V
Output Voltage Range.......................................................... 0.8V to 3.6V (0.1V steps)
(
For details, please refer to MARK INFORMATIONS.)
Output Voltage Accuracy......................................................±1.0% (V
OUT
>2.0V, T
opt
=25°C)
Temperature-Drift Coefficient of Output Voltage .................. Typ.
±80ppm/°C
Dropout Voltage.................................................................... Typ. 0.22V (I
OUT
=150mA,
V
OUT
=2.8V)
Line Regulation .................................................................... Typ. 0.02%/V
Packages ............................................................................ DFN1216-8
Built-in Fold Back Protection Circuit..................................... Typ. 40mA (Current at short mode)
Ceramic capacitors are recommended to be used with this IC .... 0.22μF or more
APPLICATIONS
•
Power source for portable communication equipment.
•
Power source for electrical appliances such as cameras, VCRs and camcorders.
•
Power source for battery-powered equipment.
1
RP153L
SELECTION GUIDE
The output voltage, auto discharge function, package, and the taping type, etc. for the ICs can be selected at
the user’s request.
Product Name
RP153Lxxx∗-E2
Package
DFN1216-8
Quantity per Reel
5,000 pcs
Pb Free
Yes
Halogen Free
Yes
xxx: The combination of output voltage for each channel can be designated by serial numbers. (from 001)
The output voltage for each channel can be set in the range from 0.8V to 3.6V in 0.1V steps.
(For details, please refer to MARK INFORMATIONS.)
∗
: Designation of Mask Option:
(A) without auto-discharge function at off state
(B) with auto-discharge function at off state
(D) without auto-discharge function at off state, (the transient response improved type)
(E) with auto-discharge function at off state, (the transient response improved type)
PIN CONFIGURATIONS
•
DFN1216-8
Top View
8
7
6
5
Bottom View
5
6
7
8
∗
1
2
3
4
4
3
2
1
PIN DESCRIPTIONS
•
DFN1216-8
Pin No.
1
2
3
4
5
6
7
8
Symbol
GND
V
OUT1
V
OUT2
GND
CE2
V
DD2
V
DD1
CE1
Ground Pin
Output Pin 1
Output Pin 2
Ground Pin
Chip Enable Pin 2 ("H" Active)
Input Pin 2
Input Pin 1
Chip Enable Pin 1 ("H" Active)
Description
∗)
Tab is GND level. (They are connected to the reverse side of this IC.)
The tab is better to be connected to the GND, but leaving it open is also acceptable.
3
RP153L
ABSOLUTE MAXIMUM RATINGS
Symbol
V
IN
V
CE
V
OUT1
, V
OUT2
I
OUT1
, I
OUT2
P
D
T
opt
T
stg
Input Voltage
Input Voltage (CE Pin)
Output Voltage
Output Current
Power Dissipation (DFN1216-8)
Operating Temperature Range
Storage Temperature Range
∗
Item
Rating
6.0
−0.3
to 6.0
−0.3
to V
IN
+0.3
180
625
−40
to 85
−55
to 125
Unit
V
V
V
mA
mW
°C
°C
∗)
For Power Dissipation, please refer to PACKAGE INFORMATION.
ABSOLUTE MAXIMUM RATINGS
Electronic and mechanical stress momentarily exceeded absolute maximum ratings may cause the
permanent damages and may degrade the life time and safety for both device and system using the device
in the field. The functional operation at or over these absolute maximum ratings is not assured.
4
RP153L
ELECTRICAL CHARACTERISTICS
•
RP153L
V
IN
=Set
V
OUT
+1.0V
(V
OUT
>1.5V),
V
IN
=2.5V
(V
OUT
≤1.5V),
I
OUT
=1mA,
C
IN
=C
OUT
=0.22μF,
unless otherwise noted.
The specification in
is checked and guaranteed by design engineering at
−40°C ≤
T
opt
≤
85°C.
VR1/VR2
Symbol
Item
T
opt
=25°C
V
OUT
Output Voltage
−40°C ≤
T
opt
≤
85°C
I
OUT
ΔV
OUT
/
ΔI
OUT
Output Current
0.8V
≤
V
OUT
<
1.1V
Load Regulation
1mA
≤
I
OUT
≤
150mA
1.1V
≤
V
OUT
<
1.6V
1.6V
≤
V
OUT
<
2.0V
2.0V
≤
V
OUT
≤
3.6V
V
DIF
I
SS
I
standby
ΔV
OUT
/
ΔV
IN
RR
V
IN
ΔV
OUT
/
ΔT
opt
I
SC
I
PD
V
CEH
V
CEL
en
R
LOW
Dropout Voltage
Supply Current
Standby Current
Line Regulation
Ripple Rejection
Input Voltage
∗
Topt=25°C
Conditions
V
OUT
> 2.0V
V
OUT
≤
2.0V
V
OUT
> 2.0V
V
OUT
≤
2.0V
Min.
×0.99
−20
×0.97
−60
150
Typ.
Max.
×1.01
+20
×1.03
+60
Unit
V
mV
V
mV
mA
10
15
15
15
40
50
55
60
mV
Refer to the following table.
I
OUT
=0mA
V
CE
=0V
Set V
OUT
+0.5V ≤
V
IN
≤
5.0V
f=1kHz, Ripple 0.2Vp-p
V
IN
=Set
V
OUT
+1V,
I
OUT
=30mA
(In case that V
OUT
≤
2.0V, V
IN
=3V)
1.40
±80
40
0.3
1.0
0.4
BW=10Hz to 100kHz
V
IN
=4.0V,
V
CE
=0V
60
50
RP153LxxxA/B
RP153LxxxD/E
40
85
0.1
0.02
70
60
120
1.0
0.10
μA
μA
%/V
dB
5.25
V
ppm
/°C
mA
μA
V
V
μVrms
Ω
Output Voltage
−40°C ≤
T
opt
≤
85°C
Temperature Coefficient
Short Current Limit
CE Pull-down Current
CE Input Voltage "H"
CE Input Voltage "L"
Output Noise
Low Output Nch Tr.
ON Resistance
(of B/E Version)
V
OUT
=0V
All of units are tested and specified under load conditions such that Tj≈T
opt
=25°C
except for Output Noise,
Ripple Rejection, Output Voltage Temperature Coefficient.
∗)
The maximum Input Voltage of the ELECTRICAL CHARACTERISTICS is 5.25V. In case of exceeding this
specification, the IC must be operated on condition that the Input Voltage is up to 5.5V and the total
operating time is within 500hrs.
5
