Series
Ganged version of our L series filtered jacks.
Available in RJ11 models with block inductors in
gangs of 2, 4, or 6. Retrofits existing unfiltered
ganged jack footprints.
L
-Ganged
Specifications
Contacts
Material:
Plating:
Barrier underplating:
Resistance:
Initial:
After durability testing
(500 mating cycles):
Ferrites
Type:
Sleeves:
Block:
Phosphor bronze
50 microinches gold
100 microinches nickel
20 milliohms maximum
IMPEDANCE IN OHMS
30 milliohms maximum
Typical Impedance in Ohms
150
140
130
120
110
100
90
80
70
60
50
40
30
20
10
0
1
25
100
200
500
High resistivity, nickel zinc ceramic
Single-aperature cylinders
Multi-aperature rectangular prism
Shield Material
Solder-plated copper alloy
Housing Material
Glass-filled polyester (UL94V-O)
Dielectric Withstanding Voltage
Line-to-line and line-to-ground
Printed Circuit Board Retention
Before soldering:
After soldering:
1000 VAC for
60 seconds
1 lb. minimum
20 lb. minimum
Frequency MHz
Pricing
Consult your local Corcom sales representative for pricing.
Part No.
Part No.
6RJ11-6L-B
Model Dimensions and PC Board Layout
Metric shown in italics.
A
.050
1.27
.470
11.94
2RJ11-6L-B
4RJ11-6L-B
.810
20.57
.086
2.18
.040
1.02
.590
14.99
.195
4.95
B
C
.050
1.27
.325
8.25
.410
10.41
.165
4.19
Ports
.100
2.54
A
.99
25.15
1.93
49.02
2.87
72.9
B
.87
22.1
1.81
45.97
2.75
69.85
C
.795
20.19
1.735
44.07
2.675
67.95
D
.87
22.1
1.81
45.97
2.75
69.85
2
L-
Ganged
125
Ø .030
+ .008
- .003
.350
8.89
4
250
6.35
.128± .003
DIA.
6
D
Libertyville, IL (847) 680-7400
