CHIP COIL
LPC 9040
SPEER ELECTRONICS, INC.
WIRE WOUND SMT CHOKE COIL
CHIP COIL
- Small size allows for High Mounting Density
- Suitable for Reflow Solder
- Large DC Current capability with Low DC resistance
- Embossed Carrier Tape available
- Polarity Identification available
- E - 6 Series of Values (customs available)
CHIP
INDUCTORS
DIMENSIONS
DIMENSIONS
mm
in
L
10.2
.36
W
9.0±0.1
.35
H
4.9 max
.19
STANDARD APPLICATIONS
ORDERING
CODE
LPC9040TED100M
LPC9040TED150K
LPC9040TED220K
LPC9040TED330K
LPC9040TED470K
LPC9040TED680K
LPC9040TED101K
LPC9040TED151K
LPC9040TED221K
LPC9040TED331K
LPC9040TED471K
LPC9040TED681K
INDUCTANCE
(µH)
10
15
22
33
47
68
100
150
220
330
470
680
10
10
INDUCTANCE
TOLERANCE
(%)
20
QUALITY
FACTOR
(MIN)
40
30
20
SELF
RESONANCE
(MIN) (MHz)
25.0
21.0
15.0
13.5
11.5
10.0
8.0
7.0
5.0
3.3
2.8
1.2
DC RES.
(MAX)
(OHMS)
0.06
0.07
0.09
0.12
0.17
0.23
0.35
0.47
0.70
1.61
1.80
2.30
ALLOWABLE
(Amps)
1.55
1.40
1.25
1.10
0.99
0.91
0.70
0.60
0.50
0.29
0.22
0.14
1000
MEASURING
(Hz)
DC CURRENT FREQUENCY
TED: Embossed Plastic Tape
ORDERING & SPECIFYING INFORMATION*
LPC
Type
9040
Size Code
9.0 x 4.8
(mm)
TED
Packaging
TED: Embossed
Taping
No Suffix: Bulk
221
Nominal Inductance
2 Significant Figures
& 1 Multiplier
R Indicates Decimal
on Values < 10
K
Tolerance
K:
±10%
M:
±20%
*Please Note: KSE’s Part Numbers Do Not Contain any Spaces or Hyphens.
TELEPHONE:
814-362-5536
51
FAX:
814-362-8883
