F-215
TSSH–115–01–L–D
TSSH–120–01–L–DH
(2,54 mm) .100"
TSSH SERIES
SHROUDED .025" SQ POST HEADERS
Mates with:
SSW, SSQ, SSM, SMSD
Important Note:
This Series will only mate
with SSW, SSQ, SSM &
SMSD Series
TSSH
1
NO. PINS
PER ROW
01
PLATING
OPTION
ROW
OPTION
OTHER
OPTION
SPECIFICATIONS
For complete specifications
and recommended PCB layouts
see www.samtec.com?TSSH
Insulator Material:
Black Liquid Crystal
Polymer
Terminal Material:
Phosphor Bronze
Plating:
Au or Sn over
50µ" (1,27 µm) Ni
Operating Temp Range:
-55°C to +105°C with Tin;
-55°C to +125°C with Gold
RoHS Compliant:
Yes
–A
05, 10, 15, 20,
25, 30, 34
(–D–RA, –DH)
= Alignment Pin (N/A
with -LC)
–L
= 10µ" (0,25 µm) Gold on post,
Matte Tin on tail
(3,17)
.125
05, 10, 15, 20,
25, 30, 35, 36
(–D, –DV)
–T
= Matte Tin
(1,58)
.062
–LC
–D–RA
= Double Row Right Angle Pin
Through-hole
02
–DH
= Double Row Horizontal Pin
Surface Mount
= Locking Clip
(–DV only)
(N/A with -A)
(Manual placement
required)
Processing:
Lead–Free Solderable:
Yes
SMT Lead Coplanarity (–DV):
(0,10 mm) .004" max (05-10)
(0,15 mm) .006" max (15-20)
(0,20 mm) .008" max (25-36)
SMT Lead Coplanarity (–DH):
(0,15 mm) .006" max
(No. of positions + 2) x (2,54) .100
(2,54) .100
(2,54)
.100
01
(2,29)
.090
(No. of positions x
(2,54) .100) + (1,02) .040
(0,64) .025 SQ
(5,84)
.230
(1,42)
.056
x
(0,25)
.010
(3,43)
.135
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
(1,52)
.060
(9,65)
.380
–M
= Metal Pick
& Place Pad
(–DV only)
(N/A with -T plating)
(7,62)
.300
(5,71)
.225
x
(4,16)
.164
APPLICATIONS
–D–RA
SSM TSSH
(2,54)
.100
(2,54)
.100
(3,94)
.155
(1,27)
.050
–DH
–D
HORIZONTAL
= Double Row Vertical Pin
Through-hole
No. of positions x
(2,54) .100 + (5,08) .200
(2,54) .100
72
02
–DV
= Double Row Vertical Pin
Surface Mount
–P
= Plastic Pick
& Place Pad
(–DH only) 5 pos. min
ALSO AVAILABLE
(MOQ Required)
• Other platings
Contact Samtec.
(6,10)
.240
(8,89)
.350
01
(2,54) (6,35)
.100 .250
No. of positions x
71
(2,54) .100 + (1,27) .050
(0,64) .025 SQ
(6,10)
.240
(2,54)
.100
(10,03)
.395
(6,86)
.270
x
(8,26)
.325
(8,89)
.350
(8,89)
.350
(8,89)
.350
(2,69)
.106
Note:
Some lengths,
styles and options are
non-standard, non-returnable.
(1,91)
.075
–D
–DV
= Tape & Reel
5 to 25 positions
(–DH & –DV only)
–TR
WWW.SAMTEC.COM
Due to technical progress, all designs, specifications and components are subject to change without notice.
