IFT COILS < Pin Type: M -10Series>
Type: M-10B
◆
Product Description
・11.0×11.0mm
Max.(L×W),14.0mm Max. Height.
・Inductance:
20mH Max.
・Operating
frequency:500kHz Max.
・In
addition to the standard versions of parameters shown here,
custom designs are available to meet your exact requirements.
◆
Feature
・High
inductance variable shielded type.
・Can
be used as DC-DC converter transformer.
・RoHS
Compliance
◆
Dimensions (mm)
1.5±0.3
4.0 ±0.5
φ0.7±0.1
7.0±0.2
14. 0 MAX.
+1.0
3.5-0.5
10.5±0.5
＊
Dimension does not include solder used on coil.
＊
Pin pitch should be measured at the root of terminal.
◆
Connection (Bottom View)
③
②
S ①
④
⑥
“S”is
winding start.
Please refer to the sales offices on our website for a representative near you
www.sumida.com
10.5±0.5
7.0±0.2
1/1
IFT COILS < Pin Type: M -10Series>
Type: M-10B
◆
Specification
Part No.
M1ØBNP-1Ø2
M1ØBNP-122
M1ØBNP-152
M1ØBNP-182
M1ØBNP-222
M1ØBNP-272
M1ØBNP-332
M1ØBNP-392
M1ØBNP-472
M1ØBNP-562
M1ØBNP-682
M1ØBNP-822
M1ØBNP-1Ø3
M1ØBNP-123
M1ØBNP-153
M1ØBNP-183
M1ØBNP-223
M1ØBNP-273
M1ØBNP-333
Stamp
102
122
152
182
222
272
332
392
472
562
682
822
103
123
153
183
223
273
333
Inductance
［Variable½
※１
1.0mH ± 6%
1.2mH ± 6%
1.5mH ± 6%
1.8mH ± 6%
2.2mH ± 6%
2.7mH ± 6%
3.3mH ± 6%
3.9mH ± 6%
4.7mH ± 6%
5.6mH ± 6%
6.8mH ± 6%
8.2mH ± 6%
10mH ± 6%
12mH ± 6%
15mH ± 6%
18mH ± 6%
22mH ± 6%
27mH ± 6%
33mH ± 6%
Unloaded Q
[Min.]
※１
70
70
70
70
75
No.
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
D.C.R.(Ω)
[Max.]
(at 20℃）
2.8
3.7
4.5
4.8
6.9
8.4
11.1
12.7
15.3
16.9
19.5
28.3
31.6
46.6
53.3
59.7
81.3
87.7
105.4
Rated
Current
(mA) [Ref.]
※２
70
65
63
60
55
53
47
42
38
35
32
31
28
20
17
10
8
7
5
75
75
75
75
80
80
80
80
75
75
75
70
70
70
※1Measuring
frequency: Inductance at 1 kHz ; Unloaded Q: at 100 kHz
※２Rated
current: The D.C. current at which the inductance decreases to 95% of it’s initial value
or when
△t=40℃,
whichever is lower(Ta=20℃).
Please refer to the sales offices on our website for a representative near you
www.sumida.com
2/2
