Datasheet> All Categories > Discrete semiconductor> diode> BAT54S-TP-HF

BAT54S-TP-HF: DescriptionRectifier Diode, Schottky, 2 Element, 0.2A, 30V V(RRM), Silicon,; CategoryDiscrete semiconductor diode; File Size252KB，3 Pages; ManufacturerMicro Commercial Components (MCC); Environmental Compliance

Download Datasheet Parametric Compare View All

BAT54S-TP-HF Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BAT54S-TP-HF	-	-	View	Buy Now

BAT54S-TP-HF Overview

Rectifier Diode, Schottky, 2 Element, 0.2A, 30V V(RRM), Silicon,

BAT54S-TP-HF Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Reach Compliance Code	compliant
ECCN code	EAR99
Configuration	SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JESD-30 code	R-PDSO-G3
Humidity sensitivity level	1
Number of components	2
Number of terminals	3
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Maximum output current	0.2 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Maximum power dissipation	0.2 W
Maximum repetitive peak reverse voltage	30 V
Maximum reverse recovery time	0.005 µs
surface mount	YES
technology	SCHOTTKY
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	10
Base Number Matches	1

Preview

Download Datasheet

View All

MCC

Micro Commercial Components

omponents

20736 Marilla

Street Chatsworth

!"#

$ % !"#

BAT54

THRU

BAT54S

•

Features

Lead Free Finish/Rohs Compliant ("P"Suffix designates

RoHS Compliant. See ordering information)

Low Forward Voltage

Surface Mount device

Epoxy meets UL 94 V-0 flammability rating

Moisture Sensitivity Level 1

Halogen

free available upon request by adding suffix "-HF"

MCC Catalog

Number

Device Marking

KL1

KL2

KL3

KL4

L42

L43

L44

Type

Single

Dual

Configuration

See page 3

Figure 1

Figure

Figure 3

Figure 4

•

200mWatt, 30Volt

Schottky Barrier Diode

SOT-23

BAT54

BAT54A

BAT54C

BAT54S

Maximum Ratings

Continuos Reverse Voltage

Forward ContinuousCurrent

Non-Repetitive Peak Forward Current t<1s

Total Power Dissipation @ T

= 25°C

Storage Temperature Range

Operating Junction Temperature Range

Soldering temperature during 10s

FSM

stg

30V

200mA

0.6A

200mW

-55°C to 150°C

-55°C to 125°C

260°C

DIMENSIONS

Electrical Characteristics @ 25

°C

Unless Otherwise Specified

Characteristics

Forward Voltage at

= 0.1mA

= 1mA

= 10mA

= 30mA

= 100mA

Reverse Current

Symbol

Max.

Notes

240mV

320mV

400mV

500mV

1000mV

2.0 uA

DIM

INCHES

MIN

.110

.083

.047

.035

.070

.018

.0005

.035

.003

.015

MAX

.120

.104

.055

.041

.081

.024

.0039

.044

.007

.020

MIN

2.80

2.10

1.20

.89

1.78

.45

.013

.89

.085

.37

MAX

3.04

2.64

1.40

1.03

2.05

.60

.100

1.12

.180

.51

NOTE

Suggested Solder

Pad Layout

= 25V

.035

.900

.031

.800

Capacitance

10pF

Reverse Recovery

Time

Thermal Resistance,

Junction to Ambient

θJA

5nS

500

°C/W

Measured at

1.0MHz, V

=1.0V

=10mA;

(REC)

= 1mA

.037

.950

.037

.950

.079

2.000

ches

Revision:

www.mccsemi.com

1 of 3

2013/01/01
