F-214 (27MAY14)
SFM–110–02–L–D–A
SFML–125–T2–L–D–LC
™
SFML–115–T2–L–D–LC
SYSTEM
(1,27 mm) .050"
SFM–125–02–L–SH
SMT & THROUGH-HOLE TIGER EYE SOCKET
™
™
Low insertion force
Tiger Eye
™
contacts available
(1,27 mm x 1,27 mm)
.050" x .050" micro pitch
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?SFM or
www.samtec.com?SFML
Insulator Material:
Black Liquid Crystal Polymer
Plating:
Au or Sn over 50µ" (1,27 µm) Ni
Current Rating (SFM/TFM):
3.2 A per pin
(1 pin powered per row)
Voltage Rating:
250 VAC mated with TFM
Operating Temp Range:
-55°C to +125°C
Contact Resistance:
15 mΩ
Insertion Depth:
(3,05 mm) .120" to
(4,06 mm) .160"
Wiping Distance:
(0,38 mm) .015"
Normal Force:
Standard= 132 g (1,29 N) avg.;
LIF= 90 g (0,88 N) avg.
Insertion Force (SFM):
(Single contact only)
Standard= 2.5 oz (0,69 N) avg.;
LITE= 2.0 oz (0,56 N) avg.;
LIF= 1.4 oz (0,39 N) avg.
Withdrawal Force (SFM):
(Single contact only)
Standard= 2.0 oz (0,56 N) avg.;
LITE= 1.5 oz (0,42 N) avg.;
LIF= 1.0 oz (0,28 N) avg.
Max Cycles:
10,000 with 30µ" (0,76 µm) Au
(Call Samtec for E.L.P.
™
plating option)
RoHS Compliant:
Yes
SFM Mates with:
TFM, TFSD, TFSS
SFML Mates with:
TFML
• Passes 10 Year MFG
Locking feature
increases unmating
force (SFML)
Choice of SMT or
through-hole tails
• Locking option
• Locking clip option
• Screw Down option
TYPE
STRIP
1
NO. PINS
PER ROW
LEAD STYLE
03, 04, 06, 08
SFM
= Standard
(SFM only)
(Surface Mount)
(Through-hole)
–02
= Tiger Eye
™
Contact
(BeCu)
–01, –03
= Tiger Eye
™
Contact
(BeCu)
Processing:
SFML
= Locking
05, 07, 10, 15, 20,
25, 30, 35, 40, 45, 50
(Standard sizes)
(1,27) .050 x No. of Positions + (0,38) .015
02
–L2
(1,78)
.070
–L1, –L3
= Low Insertion Force
Tiger Eye
™
Contact
(BeCu)
Lead-Free Solderable:
Yes
SMT Lead Coplanarity:
(0,10 mm) .004" max (05-25)
(0,15 mm) .006" max (30-50)
= Low Insertion Force
Tiger Eye
™
Contact
(BeCu)
(2,41)
.095
01
–T2
SINGLE ROW
(1,27) .050 x No. of Positions + (3,94) .155
except for alignment pin option:
(1,27) .050 x No. of Positions + (3,17) .125
(2,03) .080
02
(1,27)
.050 TYP
–T1
= Tiger Eye
™
LITE Contact
(Phosphor Bronze)
(9,78) .385
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
= Tiger Eye
™
LITE Contact
(Phosphor Bronze)
(1,27)
.050
(3,05)
.120
(3,37)
.133
(3,12)
.123
(2,26)
.089
FILE NO: 090871_0_000
(3,68)
.145
(1,27) .050 TYP
(2,41)
.095
(4,70)
.185
(3,18)
.125
(0,51)
.020
01
–SH
(–02 only)
(9,78) .385
DOUBLE ROW
(0,58)
.023
(3,68)
.145
(0,13)
.005
TYP
(4,19)
.165
(4,39)
.173
(2,79)
.110
(4,64)
.183
(2,26)
.089
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
–DH
(–02 only)
WWW.SAMTEC.COM
SFM–120–L3–L–D
SFM–110–01–L–D–A
SFM–110–02–L–D–DS
SFML–115–T1–L–D–LC
SFM–105–L3–L–D
SFM–115–02–L–DH
SFM, SFML SERIES
Mates with TFM
for coplanar and
perpendicular mating
High reliability
Tiger Eye
™
contacts
Screw down
option
Surface mount or
Through-hole tails
ALSO AVAILABLE
(1,27 mm x 1,27 mm)
.050" x .050" micro pitch
(MOQ Required)
• Solder nail option
• Other sizes
• Other platings
Contact Samtec.
OTHER SOLUTIONS
• Lower cost plating options.
See SFC Series.
PLATING OPTION
ROW
OPTION
OPTION
–L
= 10µ" (0,25 µm) Gold on contact, Matte Tin on tail
(Call Samtec for E.L.P.™ plating option)
LEAD STYLE
A
B
–01, –L1, –T1
(3,05) .120 (0,51) .020
(1,91) .075 (0,41) .016
–03, –L3
(1,27) .050 x No. of Positions + (0,38) .015
(1,78)
.070
–S
= Single Row
(SFM only)
Specify only –A, –LC or –DS
(Not available with –DH, –SH)
–A
= Alignment Pin
(Available with all Lead Styles)
Specify only
–K or –P
(Lead styles –02,
–L2, –T2 only)
–D
= Double Row
–K
= Polyimide film
Pick & Place Pad
(Not available
with –DH, –SH)
–SH
= Single Horizontal
(05 thru 30 positions only)
(SFM only)
(Lead style –02 only)
–LC
= Locking Clip
(Available with all lead styles)
(Manual placement required)
–P
= Plastic Pick &
Place Pad
(Not available
with –DH, –SH)
Specify –TR last
(Lead styles –02,
–L2, –T2 only)
(2,41)
.095
01
–DS
= Dual Screw Down for
(1,60 mm) .062" PCB
(05 thru 40 positions only)
(Lead styles –01, –02 & –03 only)
(Requires –D row option)
(Not available with SFML)
(Mates with TFM-DS option)
(Not available with –A,
–LC, –K, –P, –TR)
(1,65)
.065
(3,68)
.145
SINGLE ROW
(1,27)
.050 TYP
–DH
= Double Horizontal
(05 thru 30 positions only)
(SFM only)
(Lead style –02 only)
(1,27)
.050
(3,05)
.120
(1,27) .050 x No. of Positions + (3,94) .155
except for alignment pin option:
(1,27) .050 x No. of Positions + (3,17) .125
(2,03) .080
02
–TR
= Tape & Reel
(Required callout
for –DH, –SH)
(3,68)
.145
(1,27)
.050 TYP
(2,41)
.095
(4,57)
.180
(0,13)
.005
TYP
01
DOUBLE ROW
(3,68)
.145
(2,79)
.110
–LC
A
(1,27) .050 DIA
B
(1,59) .063
–A
(1,27)
.050
(1,41)
.056
x
(0,25)
.010
(1,78)
.070
(8,50)
.335
–DS
(–D, –01 –02 & –03)
WWW.SAMTEC.COM
