PA3017-N20-R Overview

1.9 W, 2 CHANNEL, AUDIO AMPLIFIER, PDSO20

PA3017-N20-R Parametric

Parameter Name	Attribute value
Parts packaging code	TSSOP
package instruction	HTSSOP-20
Contacts	20
Reach Compliance Code	compli
ECCN code	EAR99
Nominal bandwidth	20 kHz
Commercial integrated circuit types	AUDIO AMPLIFIER
harmonic distortion	1%
JESD-30 code	R-PDSO-G20
Number of channels	2
Number of functions	1
Number of terminals	20
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Nominal output power	1.9 W
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal location	DUAL
Base Number Matches	1

Preview

Download Datasheet

View All

UNISONIC TECHNOLOGIES CO., LTD

PA3017

2W STEREO AUDIO AMPLIFIER

DESCRIPTION

As a stereo audio speaker which is operating on a single 5V

supply, the UTC

PA3017

is capable of delivering 2W of output

power per channel into 3Ω loads with less than 1% THD+N. Way of

two terminals (GAIN0 and GAIN1) can configured and control the

amplifier gain. It also provide gain settings of 6 dB, 10 dB, 15.6 dB,

and 21.6 dB (inverting). Other features include internal gain control

which requires few external components, an active-low shutdown

mode input and thermal shutdown protection.

CMOS IC

FEATURES

* 2W Output power into 3Ω load from 5V supply each channel

* Gain control internally

* Differential input fully

* Depop circuitry

* Shutdown protection thermally

*Pb-free plating product number: PA3017L

ORDERING INFORMATION

Ordering Number

Normal

Lead Free Plating

PA3017-N20-R

PA3017L-N20-R

PA3017-N20-T

PA3017L-N20-T

Package

HTSSOP-20

Packing

Tape Reel

Tube

www.unisonic.com.tw

1 of 10

QW-R502-184.A

PA3017-N20-R Related Products

	PA3017-N20-R	PA3017	PA3017-N20-T
Description	1.9 W, 2 CHANNEL, AUDIO AMPLIFIER, PDSO20	1.9 W, 2 CHANNEL, AUDIO AMPLIFIER, PDSO20	1.9 W, 2 CHANNEL, AUDIO AMPLIFIER, PDSO20
Number of channels	2	2	2
Number of functions	1	1	1
Number of terminals	20	20	20
Maximum operating temperature	85 °C	85 Cel	85 Cel
Minimum operating temperature	-40 °C	-40 Cel	-40 Cel
surface mount	YES	Yes	Yes
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal form	GULL WING	GULL WING	GULL WING
Terminal location	DUAL	pair	pair
Maximum supply/operating voltage	-	5.5 V	5.5 V
Minimum supply/operating voltage	-	4.5 V	4.5 V
Rated bandwidth	-	20 kHz	20 kHz
Rated output power	-	1.9 dBm	1.9 dBm
Processing package description	-	HTSSOP-20	HTSSOP-20
state	-	ACTIVE	ACTIVE
Craftsmanship	-	CMOS	CMOS
packaging shape	-	Rectangle	Rectangle
Package Size	-	SMALL OUTLINE	SMALL OUTLINE
Packaging Materials	-	Plastic/Epoxy	Plastic/Epoxy
Consumer IC Type	-	audio amplifier	audio amplifier
