AN1F4Z-K

Description
Small Signal Bipolar Transistor, 0.1A I(C), 50V V(BR)CEO, 1-Element, PNP, Silicon, TO-92, SC-43B, 3 PIN
CategoryDiscrete semiconductor    The transistor
File Size82KB,4 Pages
ManufacturerNEC Electronics
Download Datasheet Parametric Compare View All

AN1F4Z-K Overview

Small Signal Bipolar Transistor, 0.1A I(C), 50V V(BR)CEO, 1-Element, PNP, Silicon, TO-92, SC-43B, 3 PIN

AN1F4Z-K Parametric

Parameter NameAttribute value
Parts packaging codeTO-92
package instructionCYLINDRICAL, O-PBCY-T3
Contacts3
Reach Compliance Codeunknown
ECCN codeEAR99
Maximum collector current (IC)0.1 A
Collector-emitter maximum voltage50 V
ConfigurationSINGLE WITH BUILT-IN RESISTOR
Minimum DC current gain (hFE)300
JEDEC-95 codeTO-92
JESD-30 codeO-PBCY-T3
Number of components1
Number of terminals3
Package body materialPLASTIC/EPOXY
Package shapeROUND
Package formCYLINDRICAL
Polarity/channel typePNP
Certification statusNot Qualified
surface mountNO
Terminal formTHROUGH-HOLE
Terminal locationBOTTOM
transistor applicationsSWITCHING
Transistor component materialsSILICON
Maximum off time (toff)6000 ns
Maximum opening time (tons)200 ns
Base Number Matches1
DATA SHEET
COMPOUND TRANSISTOR
AN1F4Z
on-chip resistor PNP silicon epitaxial transistor
For mid-speed switching
FEATURES
• On-chip bias resistor
(R
1
= 22 kΩ)
• Complementary transistor with AA1A4Z
PACKAGE DRAWING (UNIT: mm)
ABSOLUTE MAXIMUM RATINGS (Ta = 25°C)
°
Parameter
Collector to base voltage
Collector to emitter voltage
Emitter to base voltage
Collector current (DC)
Collector current (Pulse)
Total power dissipation
Junction temperature
Storage temperature
Symbol
V
CBO
V
CEO
V
EBO
I
C(DC)
I
C(pulse)
*
P
T
T
j
T
stg
Ratings
−60
−50
−5
−100
−200
250
150
−55
to +150
Unit
V
V
V
mA
mA
mW
°C
°C
* PW
10 ms, duty cycle
50 %
ELECTRICAL CHARACTERISTICS (Ta = 25°C)
°
Parameter
Collector cutoff current
DC current gain
DC current gain
Collector saturation voltage
Low level input voltage
High level input voltage
Input resistance
Turn-on time
Storage time
Turn-off time
Symbol
I
CBO
h
FE1
**
h
FE2
**
V
CE(sat)
**
V
IL
**
V
IH
**
R
1
t
on
t
stg
t
off
V
CC
=
−5.0
V, R
L
= 1.0 kΩ
V
I
=
−5.0
V, PW = 2.0
µ
s
duty cycle≤2 %
Conditions
V
CB
=
−50
V, I
E
= 0
V
CE
=
−5.0
V, I
C
=
−5.0
mA
V
CE
=
−5.0
V, I
C
=
−50
mA
I
C
=
−5.0
mA, I
B
=
−0.25
mA
V
CE
=
−5.0
V, I
C
=
−100
µ
A
V
CE
=
−0.2
V, I
C
=
−5.0
mA
−3.0
15.4
135
100
280
200
−0.06
−0.57
−1.1
22
28.6
0.2
5.0
6.0
−0.2
−0.5
MIN.
TYP.
MAX.
−100
600
Unit
nA
V
V
V
kΩ
µ
s
µ
s
µ
s
** Pulse test PW
350
µ
s, duty cycle
2 %
h
FE
CLASSIFICATION
Marking
h
FE1
Q
135 to 270
P
200 to 400
K
300 to 600
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. D16167EJ1V0DS00 (1st edition)
Date Published April 2002 N CP(K)
Printed in Japan
©
2002
1998
