BAT48
Small-Signal Diode
Schottky Diode
Features
For general purpose applications.
These diodes feature very low turn-on voltage and fast
switching. These devices are protected by a PN junction guard
ring against excessive voltage, such as electrostatic dis-
charges
This diode is also available in the MiniMELF case with type
designation LL48.
Mechanical Data
Case: DO-35 Glass Case
Weight: approx. 0.13g
Maximum Ratings and Thermal Characteristics
(Ratings at 25
o
C ambient temperature unless otherwise specified.)
Parameter
Repetitive peak reverse voltage
Forward continuous current at T
amb
=25
o
C
Repetitive peak forward current
at t
p
<1s,
δ<
0.5, T
amb
=25
o
C
Surge forward current at t
p
<10ms, T
amb
=25
o
C
Power dissipation
(1)
at T
amb
=65
o
C
Thermal resistance junction to ambient air
Junction temperature
Ambient operating temperature range
Storage temperature range
Notes:
Symbol
V
RRM
I
F
I
FRM
I
FSM
P
tot
R
θ
JA
T
j
T
amb
T
S
Value
40
350
1.0
7.5
330
300
(1)
Unit
Volts
mA
Amp
Amps
mW
o
(1)
(1)
(1)
(1)
C/W
o
125
-65 to +125
-65 to +150
C
C
C
o
o
1. Valid provided that leads at a distance of 4mm from case are kept at ambient temperature.
683
Electrical Characteristics
Ratings at 25
o
C ambient temperature unless otherwise specified.
Parameter
Reverse breakdown voltage
tested with 100
u
A pulses
Leakage current
pulse test t
p
<300
u
s,
δ
<2%
at V
R
=10V
at V
R
=10V, T
j
=60
O
C
at V
R
=20V
at V
R
=20V, T
j
=60
O
C
at V
R
=40V
at V
R
=40V, T
j
=60
O
C
Forward voltage
pulse test t
p
<300
u
s,
δ
<2%
at I
F
=0.1mA
at I
F
=1.0mA
at I
F
=10mA
at I
F
=50mA
at I
F
=200mA
at I
F
=500mA
Capacitance
at V
R
=1V, f=1MHz
Notes:
Symbol
V
(BR)R
Min.
40
Typ.
-
Max.
-
Unit
Volts
I
R
-
-
-
-
-
-
-
-
-
-
-
-
2
15
5
25
25
50
uA
V
F
-
-
-
-
-
-
-
-
-
-
-
-
-
12
0.25
0.30
0.40
0.50
0.75
0.90
-
Volt
C
tot
pF
1. Valid provided that leads at a distance of 4mm from case are kept at ambient temperature(DO-35)
684
