C9PASH-156.250EL

Description
IC,CRYSTAL OSCILLATOR,1-CHANNEL,750KHZ-800MHZ,LLCC,6PIN,CERAMIC
CategoryPassive components    oscillator
File Size56KB,3 Pages
ManufacturerRaltron
Websitehttp://www.raltron.com/
Environmental Compliance
Download Datasheet Parametric View All

C9PASH-156.250EL Overview

IC,CRYSTAL OSCILLATOR,1-CHANNEL,750KHZ-800MHZ,LLCC,6PIN,CERAMIC

C9PASH-156.250EL Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
package instructionDILCC6,.2
Reach Compliance Codecompliant
JESD-609 codee3
Installation featuresSURFACE MOUNT
Number of terminals6
Maximum operating frequency800 MHz
Minimum operating frequency0.75 MHz
Nominal operating frequency156.25 MHz
Maximum operating temperature70 °C
Minimum operating temperature
Package body materialCERAMIC
Encapsulate equivalent codeDILCC6,.2
power supply3.3 V
Certification statusCOMMERCIAL
Maximum slew rate100 mA
Nominal supply voltage3.3 V
surface mountYES
Terminal surfaceMATTE TIN
Base Number Matches1
CLOCK
Page 1 of 3
C9P: PLL LVPECL SERIES: ULTRA HF CLOCK OSCILLATOR, LVPECL, +3.3 VDC
DESCRIPTION: A crystal controlled, high frequency, highly stable oscillator, adhering to Low Voltage Differential Signaling
(LVPECL) Standards. The output can be Tri-stated to facilitate testing or combined multiple clocks. The device is contained in
a sub-miniature, very low profile, leadless ceramic SMD package with 6 gold contact pads. This miniature oscillator is ideal for
today's automated assembly environments.
APPLICATIONS AND FEATURES:
"
"
"
"
"
"
Infiniband; Fiber Channel; SATA; 10GbE; Network Processors; SOHO Routing; Switches;
Common Frequencies: 150 MHz; 156.25 MHz; 155.52 MHz; 161.1328 MHz; 212.5MHz; 312.5MHz
+3.3 VDC LVPECL
Frequency Range from 750KHz to 800 MHz
PLL multiplication (F>25MHz)
Miniature Ceramic SMD Package Available on Tape and Reel
Lead Free and ROHS Compliant
SYMBOL
Ta
T(stg)
Vcc
Vi
Vo
VALUE
-40…+85
-55…+90
+4.6
Vss-0.5…Vcc+0.5
Vss-0.5…Vcc+0.5
UNIT
°C
°C
VDC
VDC
VDC
$
"
ABSOLUTE MAXIMUM RATINGS:
PARAMETER
Operating temperature range
Storage temperature range
Supply voltage
Maximum Input Voltage
Maximum Output Voltage
$
ELECTRICAL PARAMETERS:
PARAMETER
SYMBOL
fo
Vcc
Is
Connected between each output and Vcc – 2.0 VDC
min
max
Measured at 50% of Vcc
Measured at 20/80% and 80/20% Vcc Levels
Integrated Phase tji RMS,
Fo=155.52MHz
Fj = 12 kHz…20 MHz
5
Fo=622.08MHz
Fo=155.52MHz.
Random period Jitter Rj using
wavecrest analyzer
4
Fo=622.08MHz
Fo=155.52MHz.
Acumm. Peak to Peak Jitter Tp-p
using wavecrest analyzer
*4
Fo=622.08MHz
∆f=10
Hz
∆f=100
Hz
∆f=1
KHz
∆f=10
KHz
typ. @155.52MHz
6
∆f=100
KHz
∆f=1M
Hz
∆f=10M
Hz
∆f>20M
Hz
Op. Temp., Aging, Load, Supply and Cal. Variations
High Voltage or No Connect
Ground
High Voltage
Ground or No Connect
TEST CONDITIONS
*1
VALUE
0.75~ 800.00**
+3.3
±5%
100.0 MAX
LVPECL
Voh
Vol
DC
tr / tf
50
Vcc-1.025
Vcc-1.620
40/60 to 60/40 or 45/55 to 55/45
0.7 TYP 1.0 MAX
*2
2.6 TYP**
2.5 TYP**
4 TYP **
6 TYP **
30 TYP**
40 TYP**
-60
-90
-120
-125
-121
-121
-140
-145
±20, ±25, ±50,
or
±100
MAX
*3
0.7•Vcc MIN
0.3•Vcc MAX
0.7•Vcc MIN
0.3•Vcc MAX
VDC
VDC
%
ns
ps
ps
ps
UNIT
MHz
VDC
mA
Nominal Frequency
Supply Voltage
Supply Current
Output Logic Type
Load
Output Voltage Levels
Duty Cycle
Rise / Fall Time
Jitter
J
Phase Noise
£(∆f)
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
ppm
VDC
VDC
VDC
VDC
Overall Frequency Stability
Enable High Option;
Pin 1
Output Enabled
Output Disabled
Enable Low Option;
Pin 1
Output Disabled
Output Enabled
∆f/fc
En
Dis
Dis
En
RALTRON ELECTRONICS CORP.
!
10651 N.W . 19
th
St
!
Miami, Florida 33172
!
U.S.A.
phone: (305) 593-6033
!
fax: (305) 594-3973
!
e-mail: sales@raltron.com
!
WEB: http://www.raltron.com
