PDM-30-150 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wireless rf/communication> Radio frequency and microwave> PDM-30-150

PDM-30-150: Description0 POWER DIVIDERS / COMBINERS; CategoryWireless rf/communication Radio frequency and microwave; File Size141KB，2 Pages; ManufacturerMerrimac Industries（Crane）; Websitehttp://www.craneae.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

PDM-30-150 Overview

0 POWER DIVIDERS / COMBINERS

PDM-30-150 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Merrimac Industries（Crane）
Reach Compliance Code	unknow
Other features	HIGH RELIABILITY
Characteristic impedance	50 Ω
Maximum input power (CW)	30 dBm
Maximum insertion loss	1.2 dB
Maximum operating frequency	300 MHz
Minimum operating frequency	1 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
RF/Microwave Device Types	SPLITTER AND COMBINER
Maximum voltage standing wave ratio	1.5
Base Number Matches	1

Preview

Download Datasheet

View All

PDM-30 Series

0 POWER DIVIDERS / COMBINERS

1 to 2000 MHz / 3-Way / Wide Bandwidth / Low Insertion Loss

/ Lumped Element Design / SMA

PRINCIPAL SPECIFICATIONS

Model

Number

PDM-30-50

PDM-30-150

Freq.

Frequency

Isolation, Insertion

Range, Performance,

dB,

Loss, dB,

MHz

Min. Typ. Max. Typ.

1 - 100

1 - 300

0.6

1.0

1.2

1.0

2.0

1.2

2.2

0.3

0.6

0.8

0.6

1.5

0.8

1.5

Phase

Amplitude

Balance,

Bal., dB,

Max. Typ. Max. Typ.

2°

3°

4°

6°

8°

5°

10°

1°

2°

3°

4°

3°

5°

0.2

0.3

0.4

0.5

0.8

0.5

0.7

0.1

0.4

0.3

0.5

0.3

0.5

VSWR

(In/Output)

Max. Typ.

1.3:1

1.5:1

1.3:1

1.6:1

1.4:1

1.5:1

1.25:1

1.2:1

1.3:1

1.2:1

1.4:1

1.25:1

1.3:1

1 - 100

2 - 200

1 - 300

PDM-30-525 50 - 1000 100 - 500

50 - 1000

PDM-30-1050 700 - 1400 700 - 1400

PDM-30-1100 100 - 2000 100 - 2000

Typical PDM-30-150 Performance

GENERAL SPECIFICATIONS

Coupling:

-- 4.8 dB nom.

Impedance:

Ω

nom.

Internal Load Dissipation: 250 mW max.

CW Power Input:

1 W max.

(When used as divider with 1.2:1 VSWR

out

)

Connectors, SMA Female:to meet interface

requirements of

MIL-C-39012

Weight, nominal:

2 oz. (57 g)

Operating Temperature: -- 55° to +85°C

General Notes:

1. The PDM-30 series of 3-way In-Phase, Power

Dividers/Combiners covers 1 to 2,000 MHz, us-

ing a special lumped element design to reduce

size.

2. Similar units are available with up to sixteen

output ports and with power capacity up to sev-

eral kilowatts.

19Feb96

For further information contact

MERRIMAC / 41 Fairfield Pl., West Caldwell, NJ, 07006 / 973-575-1300 / FA973-575-0531
