MASTER INSTRUMENT CORPORATION
SINGLE-PHASE BRIDGE RECTIFIER
W005MF THRU W10MF
FEATURES
l
Low cost
l
This series is UL recognized under component
index,file number E127707
l
High forward surge current capability
l
Ideal for printed circuit board
l
High temperature soldering guaranteed:
260
o
C/10 second, at 5 lbs. (2.3kg) tension.
MECHANICAL DATA
l
Case: Molded plastic body
l
Terminal: Lead solderable per MIL-STD-202E
method 208C.
l
Polarity: Polarity symbols molded on case
l
Mounting position: Any
l
Weight:0.042ounce,1.2grams
VOLTAGE RANGE
CURRENT
50 to 1000 Volts
1.5 Amperes
.366(9.3)
.350(8.9)
.220(5.6)
.200(5.1)
1.1
(27.9)
MIN
1.0
(25.4)
MIN
POS
LEAD
~
+
.032(0.8)DIA
.028(0.7)TYP
-
~
.220(5.6)
.180(4.6)
.220(5.6)
.180(4.6)
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load derate current by 20%.
SYMBOLS W005MF W01MF W02MF W04MF W06MF
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward
Rectified Output Current, at T
A
=25℃(Note1)
Peak Forward Surge Current 8.3ms single half sine-wave
superimposed on rated load (JEDEC Method)
Ratings for Fusing (t<8.3ms)
Maximum Instantaneous Forward Voltage at 1.0A
Maximum DC Reverse Current at rated
DC blocking voltage per element
Typical Junction Capacitance(Note2)
Maximum reverse recovery time (Note 3) T
J
=25℃
Operating Temperature Range
Storage Temperature Range
T
A
=25℃
T
A
=100℃
C
J
T
RR
T
J
T
STG
150
-55 to +150
-55 to +150
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
I
2
T
V
F
I
R
5.0
0.5
25
250
50
35
50
100
70
100
200
140
200
400
280
400
1.5
50
10
1.3
600
420
600
W08MF W10MF
800
560
800
1000
700
1000
UNITS
Volts
Volts
Volts
Amps
Amps
A
2
S
Volts
10
µAmps
mAmps
P
F
500
nS
℃
℃
NOTES:
1.
Unit mounted on P.C. board with 0.22”×0.22”(5.5×5.5mm)copper pads,0.375”(9.5mm)lead length.
2.
Measured at 1.0MHz and applied reverse voltage of 4.0 volts.
3.
Reverse recovery test conditions: I
F
=0.5A, I
R
=1.0A, I
RR
=0.25A
E-mail:
sales@cnmic.com
Web Site: www.cnmic.com
1/2
