LF100ES
Series
Lowest Cost, Single Output
1W Ultra-Miniature SMT
DC/DC Converters
Electrical Specifications
Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Key Features:
•
1W Output Power
•
Ultra-Miniature SMT Case
•
UL Approved
(File E245422)
•
Single Output
•
Low 0.246” Profile
•
1,000 VDC Isolation
•
>3.5 MHour MTBF
•
3.3V, 5V, & 12V Inputs
•
LOWEST COST!
Input
Parameter
Input Voltage Range
Reverse Polarity Input Current
Input Filter
Capacitor
Conditions
For Vin Change of 1%
For Vin Change of 1%
See Model Selection Guide
50
Momentary (0.5 Sec.)
Conditions
60 Seconds
500 VDC
100 kHz, 1V
Min.
1,000
1,000
70
100
Conditions
Ambient
Min.
-40
-55
Free Air Convection
RH, Non-condensing
95
%
Typ.
+25
Max.
+85
+125
Typ.
Max.
Units
VDC
MΩ
pF
kHz
Units
ºC
ºC
100
±0.03
mV P - P
%/ºC
Min.
Typ.
±3.0
±1.5
±1.2
Max.
Units
%
%
%
Conditions
3.3 VDC Input
5 VDC Input
12 VDC Input
Min.
3.0
4.5
10.8
Typ.
3.3
5.0
12.0
Max.
3.6
5.5
13.2
1.0
A
VDC
Units
Output
Parameter
Output Voltage Accuracy
Line Regulation, 3.3V Output
Line Regulation, All Other Outputs
Load Regulation
Ripple & Noise (20 MHz)
Temperature Coefficient
Output Short Circuit
General
Parameter
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Switching Frequency
Environmental
Parameter
Operating Temperature Range
Storage Temperature Range
Cooling
Humidity
Physical
MicroPower Direct
292 Page Street
Suite D
Stoughton, MA 02072
USA
Case Size
Case Material
Weight
0.50 x 0.29 x 0.24 Inches (12.7 x 7.5 x 6.0 mm)
Non-Conductive Black Plastic (UL94-V0)
0.05 Oz (1.5g)
Conditions
MIL HDBK 217F, 25ºC, Gnd Benign
Min.
3.5
Typ.
Max.
Units
MHours
Reliability Specifications
Parameter
T:
(781) 344-8226
MTBF
F:
(781) 344-8481
Safety Standards
E:
sales@micropowerdirect.com
W:
www.micropowerdirect.com Safety Approvals
UL 1950, EN 60950, IEC 60950
UL, cUL; File No. E245422
Conditions
3.3 VDC Input
5 VDC Input
12 VDC Input
1.5 mm From Case For 10 Sec
All Models
Min.
-0.7
-0.7
-0.7
Typ.
Max.
7.0
7.0
15.0
260.0
450
ºC
mW
VDC
Units
Absolute Maximum Ratings
Parameter
Input Voltage Surge (1 Sec)
Lead Temperature
Internal Power Dissipation
Caution:
Exceeding Absolute Maximum Ratings may damage the module. These are not continuous operating ratings.
Model Selection Guide
Model
Number
LF101ES
LF102ES
LF103ES
LF104ES
LF109ES
LF111ES
LF112ES
LF113ES
LF114ES
LF151ES
LF152ES
LF153ES
LF159ES
Input
Voltage (VDC)
Nominal
Range
5
4.5 - 5.5
5
4.5 - 5.5
5
4.5 - 5.5
5
4.5 - 5.5
5
4.5 - 5.5
12
10.8 - 13.2
12
10.8 - 13.2
12
10.8 - 13.2
12
10.8 - 13.2
3.3
3.0 - 3.6
3.3
3.0 - 3.6
3.3
3.0 - 3.6
3.3
3.0 - 3.6
Output
Load
Current (mA)
Voltage Current
Current Regulation
Full-Load No-Load (VDC) (mA, Max) (mA, Min) (%, Max)
260
30
5.0
200.0
20.0
15.0
263
30
9.0
111.0
23.0
9.0
253
30
12.0
84.0
17.0
7.5
256
30
15.0
67.0
13.0
7.0
277
30
3.3
300.0
30.0
15.0
121
15
5.0
200.0
20.0
15.0
114
15
9.0
111.0
23.0
9.0
114
15
12.0
84.0
17.0
7.5
113
15
15.0
67.0
13.0
7.0
409
55
5.0
200.0
20.0
15.0
446
55
9.0
111.0
23.0
9.0
433
55
12.0
84.0
17.0
7.5
415
55
3.3
300.0
30.0
15.0
Efficiency
(%, Typ)
77
76
79
78
72
69
73
73
74
74
68
70
73
Fuse Rating
Slow-Blow
(mA)
500
500
500
500
500
200
200
200
200
750
750
750
750
Other input/output combinations are available (i.e. 24 VDC Input).
Contact the factory for details at:
sales@micropowerdirect.com
Notes:
1. Output load regulation is specified for a load change of 10% to 100%.
2. When measuring output ripple, it is recommended that an external 0.33
µF
ceramic
capacitor be placed from the +Vout pin to the -Vout pin.
3. During operation, care must be taken not to exceed the specified input range of the unit
or to allow the output load to drop below the specified minimum (10% of full load).
Operating the unit under either of these conditions could cause damage to the unit.
4. These converters are specified for operation without external components. However,
in some applications the addition of input/output capacitors will enhance stability and
reduce output ripple. Recommended capacitor values are:
Vin
3.3 VDC
5 VDC
12 VDC
Input
Capacitor
4.7
µF
4.7
µF
2.2
µF
Vout
3.3 VDC
5 VDC
9 VDC
12 VDC
15 VDC
Output
Capacitor
10.0
µF
10.0
µF
4.7
µF
2.2
µF
1.0
µF
Derating Curve
Pin Connections
Pin Description
1
-Vin
2
+Vin
3
NC
4
-Vout
NC = No Connection
Pin
5
6
7
8
Description
+Vout
NC
NC
NC
Recommended Solder Profile
For applications requiring very low output noise levels,
a simple LC filter should be effective.
5. It is recommended that a fuse be used on the input of
a power supply for protection. See the Model Selection
table above for the correct rating.
Mechanical Dimensions
Board Layout
MicroPower Direct
www.micropowerdirect.com
•
Notes:
•
All dimensions are typical in inches (mm)
•
Tolerance x.xx =
±
0.01 (
±
0.25)
•
Pin 1 is marked by a “dot” or indentation on the unit
292 Page Street Ste D Stoughton, MA 02072
TEL: (781) 344-8226
•
FAX: (781) 344-8481
•
E-Mail: sales@micropowerdirect.com
