Document M104-1
Chip Inductors – M1206CS Series (3216)
The M1206CS inductors feature high SRF and excel-
lent Q values. Their ceramic cores make 1% tolerances
practical and economical and ensure the utmost in
thermal stability, predictability and consistency.
This robust version of Coilcraft’s standard 1206CS series
features a high temperature encapsulant that allows op-
eration in ambient temperatures up to 155°C and a leach-
resistant base metalization with 63/37 tin-lead terminations
that ensures the best possible board adhesion.
SRF min
4
(MHz)
6200
5500
4000
3200
3200
2800
2200
1800
1800
1800
1500
1450
1200
1200
1100
1100
950
900
760
730
650
600
550
470
470
450
440
420
410
400
380
Part
number
1
Inductance
2
(nH)
3.3 @ 100 MHz
6.8 @ 100 MHz
10 @ 100 MHz
12 @ 100 MHz
15 @ 100 MHz
18 @ 100 MHz
22 @ 100 MHz
27 @ 100 MHz
33 @ 100 MHz
39 @ 100 MHz
47 @ 100 MHz
56 @ 100 MHz
68 @ 100 MHz
82 @ 100 MHz
100 @ 100 MHz
120 @ 100 MHz
150 @ 100 MHz
180 @ 50 MHz
220 @ 50 MHz
270 @ 50 MHz
330 @ 50 MHz
390 @ 50 MHz
470 @ 50 MHz
560 @ 35 MHz
620 @ 35 MHz
680 @ 35 MHz
750 @ 35 MHz
820 @ 35 MHz
910 @ 35 MHz
1000 @ 35 MHz
1200 @ 35 MHz
Percent
tolerance
5
5
5
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
Q
min
3
DCR max
5
(Ohms)
0.050
0.070
0.080
0.080
0.100
0.100
0.100
0.110
0.110
0.120
0.130
0.140
0.260
0.210
0.260
0.260
0.310
0.430
0.500
0.560
0.620
0.750
1.30
1.34
1.58
1.58
2.25
1.82
2.95
2.80
3.20
Irms
6
(mA)
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
900
900
850
800
750
700
670
630
590
530
490
460
460
430
320
400
310
320
300
M1206CS-030X_
M1206CS-060X_
M1206CS-100X_
M1206CS-120X_
M1206CS-150X_
M1206CS-180X_
M1206CS-220X_
M1206CS-270X_
M1206CS-330X_
M1206CS-390X_
M1206CS-470X_
M1206CS-560X_
M1206CS-680X_
M1206CS-820X_
M1206CS-101X_
M1206CS-121X_
M1206CS-151X_
M1206CS-181X_
M1206CS-221X_
M1206CS-271X_
M1206CS-331X_
M1206CS-391X_
M1206CS-471X_
M1206CS-561X_
M1206CS-621X_
M1206CS-681X_
M1206CS-751X_
M1206CS-821X_
M1206CS-911X_
M1206CS-102X_
M1206CS-122X_
30 @ 300 MHz
30 @ 300 MHz
40 @ 300 MHz
40 @ 300 MHz
40 @ 300 MHz
50 @ 300 MHz
50 @ 300 MHz
50 @ 300 MHz
55 @ 300 MHz
55 @ 300 MHz
55 @ 300 MHz
55 @ 300 MHz
55 @ 300 MHz
55 @ 300 MHz
55 @ 300 MHz
60 @ 300 MHz
60 @ 300 MHz
60 @ 300 MHz
60 @ 300 MHz
55 @ 300 MHz
45 @ 150 MHz
45 @ 150 MHz
45 @ 150 MHz
45 @ 150 MHz
45 @ 150 MHz
45 @ 150 MHz
45 @ 150 MHz
45 @ 150 MHz
45 @ 150 MHz
45 @ 150 MHz
45 @ 150 MHz
1. When ordering, please specify
tolerance
code:
M1206CS-122XJ
Tolerance:
F
= 1%
G
= 2%
J
= 5%
2. Inductance measured using a Coilcraft SMD-A fixture in an Agilent/HP 4286A impedance analyzer with Coilcraft-provided correlation pieces.
3. Q measured using an Agilent/HP 4291A with an Agilent/HP 16193 test fixture.
4. SRF measured using an Agilent/HP 8720D network analyzer and a Coilcraft SMD-D test fixture.
5. DCR measured on a Cambridge Technology Micro-ohmmeter and a Coilcraft CCF840 fixture.
6. Current that causes a 15°C temperature rise from 25°C ambient.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
®
These parts are preproduction products for electrical evaluation only.
Specification subject to change without notice.
Document M104-1 Revised 04/10/08
Critical Products
© Coilcraft, Inc. 2007
1102 Silver Lake Road
Cary IL 60013
Phone
800-981-0363
Fax
847-639-1508
E-mail
cp@coilcraft.com
Web
www.coilcraft.com/cp
Document M104-2
M1206CS Series (3216)
Typical Q vs Frequency
120
110
100
90
15 nH
3.3 nH
Typical L vs Frequency
10000
33 nH
1200 nH
1000
560 nH
150 nH
100
47 nH
150 nH
70
680 nH
60
50
40
30
20
10
0
10
100
1000
10000
330 nH
Inductance (nH)
80
Q Factor
18 nH
10
3.3 nH
1
1
10
100
1000
Frequency (MHz)
Core material
Ceramic
Terminations
Tin-lead over silver-palladium-platinum-glass frit.
Ambient temperature
–55°C to +140°C with
Irms
current, +140°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Packaging: –55°C to +80°C
Frequency (MHz)
Irms Derating
120
110
100
Percent of rated
I
rms
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+25 to +125 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced Crush-Resitant Packaging
2000 per 7″ reel
Plastic tape: 8 mm wide, 0.3 mm thick, 4 mm pocket spacing,
1.6 mm pocket depth
90
80
70
60
50
40
30
20
B
overall
C
D
H
I
J
I
10
0
-40
-20
0
20
40
60
80
100
120
140 160
F
A
Ambient temperature (°C)
G
F
E
terminal
A max B max C max
0.140
3,56
0.085
2,16
0.060
1,52
Terminal wraparound:
approx 0.015/0,38 both ends
Recommended
Land Pattern
D ref
0.020
0,51
E
0.056
1,42
F
G
H
I
J
0.020 0.080
0,51
2,03
0.076 0.040 0.070
1,93
1,02
1,78
®
These parts are preproduction products for electrical evaluation only.
Specification subject to change without notice.
Document M104-2 Revised 04/10/08
Critical Products
© Coilcraft, Inc. 2007
1102 Silver Lake Road
Cary IL 60013
Phone
800-981-0363
Fax
847-639-1508
25°C
E-mail
cp@coilcraft.com
Web
www.coilcraft.com/cp
