Power Chip Low Profile Inductors
Dimensions:
Inches
(mm)
PCLP05
XXX
Allied
Part
Number
PCLP05-1R2M-RC
PCLP05-1R5M-RC
PCLP05-2R2M-RC
PCLP05-3R3M-RC
PCLP05-4R7M-RC
PCLP05-6R8M-RC
PCLP05-100M-RC
PCLP05-150M-RC
PCLP05-220M-RC
PCLP05-330M-RC
PCLP05-470M-RC
PCLP05-680M-RC
PCLP05-101M-RC
PCLP05-151M-RC
PCLP05-221M-RC
PCLP05-331M-RC
Inductance
(µh)
Tolerance
(%)
Test
Freq.
KHz, 0.1V
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR
Max.
(Ω)
0.08
0.10
0.12
0.16
0.20
0.32
0.41
0.55
0.85
1.30
1.80
2.50
3.50
5.00
7.00
15.0
Isat
(A)
Irms
(A)
Features
•
•
•
•
•
High Energy Storage SMD low cost design
Low profile, 1mm nominal
Designed for very low resistance
Small size and high performance
Excellent for use in step up and step down
coverters
• DC-DC conversion
Electrical
1.2
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
2.1
1.9
1.6
1.3
1.1
0.9
0.8
.65
0.5
0.4
.35
.30
.25
.18
.16
.13
3.6
2.8
2.4
2.0
1.7
1.2
1.1
0.9
.83
Inductance Range:
1.2µh to 330µh
Tolerance:
20% over entire range
Also available in tighter tolerances
Test Frequency:
(L/Q) as specified
Operating Temp:
-40ºC ~ +85ºC
Isat:
Current at which Inductance drops 10%
of original value
Irms:
∆
T=
40ºC rise typical at Irms.
Resistance to Soldering Heat
.62
.52
.35
.27
.24
.23
.13
Test Method:
Reflow solder the devise onto
PCB using 96.5 Sn/Ag3.0/Cu0.5 Solder paste.
The solder process shall be 230ºC for 20 ± 2 sec.
and 260ºC for 5 ± 2 seconds.
Inductance shall remain within 10% of inital value.
Test Equipment
(L & Q):
HP4192A / HP4285A
(DCR):
Chen Hwa 502BC
(IDC):
HP4284A with HP42841A or
CH1061 with CH301A
Physical
All specifications subject to change without notice.
Packaging:
3500 pieces per 13 inch reel.
Marking:
EIA Inductance Code.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
REVISED 12/11/08
www.alliedcomponents.com
