RoHS
Power Shielded Inductors
Dimensions:
Inches
(mm)
PS10
Allied
Part
Number
PS10-1R0M-RC
PS10-1R5M-RC
PS10-1R8M-RC
PS10-2R7M-RC
PS10-3R9M-RC
PS10-4R7M-RC
PS10-5R6M-RC
PS10-6R8M-RC
PS10-100M-RC
PS10-150M-RC
PS10-220M-RC
PS10-330M-RC
PS10-390M-RC
PS10-470M-RC
PS10-680M-RC
PS10-820M-RC
PS10-101M-RC
PS10-121M-RC
PS10-151M-RC
PS10-221M-RC
PS10-331M-RC
PS10-471M-RC
PS10-561M-RC
PS10-681M-RC
PS10-821M-RC
PS10-102M-RC
Inductance Tolerance
(µh)
(%)
1.0
1.5
1.8
2.7
3.9
4.7
5.6
6.8
10
15
22
33
39
47
68
82
100
120
150
220
330
470
560
680
820
1000
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
Q
Min. @
1Mhz
26
26
28
30
30
30
30
30
30
30
33
33
33
33
33
33
33
33
33
33
33
33
33
33
23
20
L Test
Freq.
(Mhz)
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
0.1/1
SRF
Typ.
(Mhz)
344
260
225
185
172
157
150
150
110
95
75
30
21
18
15
12
10
8.0
8.0
5.8
5.5
3.8
3.1
2.8
2.0
1.5
DCR
(Ω)
Max.
0.05
0.08
0.09
0.14
0.29
0.35
0.39
0.58
0.75
1.15
1.40
1.61
1.85
2.20
3.80
4.30
4.80
5.00
6.50
12.0
17.0
19.0
18.4
24.0
26.0
29.2
IDC
(A)
3.0
2.8
2.1
1.5
1.2
1.1
1.1
.90
.82
.70
.65
.52
.46
.43
.33
.32
.31
.25
.24
.22
.20
.16
.13
.12
.10
.10
Features
• Shielded Power Inductor
• Only 2.94mm tall
• Specially designed ferrite shield
• Provides extremely low DCR and
high current rating
Electrical
Inductance Range:
1µH to 1000µH
Tolerance:
20% over entire range,
tighter tolerances available
LQ Test:
OSC @ 100mV
Operating Temp:
-25ºC ~ +85ºC
IDC:
Current at which inductance
drops by 10% of intial value
Resistance to Soldering Heat
Pre-Heat 150ºC, 1 minute.
Solder Composition:
Sn/Ag3.0/Cu0.5
Solder Temp:
245ºC ± 5ºC for 10 sec. ± 1 sec.
Test Time:
6 minutes
Test Equipment
(L/Q):
HP4285A / HP4291
(RDC):
Chen Hwa 502BC
(SRF):
HP4291A
(IDC):
Chen Hwa 1061 + 301A
All specifications subject to change without notice.
Physical
Packaging:
750 pieces per 7 inch reel.
Marking:
None
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
REVISED 7/9/09
www.alliedcomponents.com
