PR36MF11NSZ Overview

Trigger Output SSR, 1-Channel, 4000V Isolation, PLASTIC, DIP-8

PR36MF11NSZ Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	SHARP
package instruction	PLASTIC, DIP-8
Reach Compliance Code	unknown
Other features	UL RECOGNIZED, HIGH RELIABILITY
Configuration	SINGLE
Maximum forward current	0.05 A
Maximum insulation voltage	4000 V
JESD-609 code	e0
Number of components	1
Maximum on-state current	0.6 A
Maximum operating temperature	85 °C
Minimum operating temperature	-25 °C
Optoelectronic device types	TRIGGER OUTPUT SSR
Terminal surface	Tin/Lead (Sn/Pb)
Base Number Matches	1

Preview

Download Datasheet

View All

PR26MF1xNSZ Series

PR36MF1xNSZ Series

PR26MF1xNSZ Series

PR36MF1xNSZ Series

Zero cross type is also available. (PR26MF21NSZ

Series/

PR36MF2xNSZ Series)

∗

(rms)≤0.6A, Non-Zero Cross type

DIP 8pin

Triac output SSR

■

Description

PR26MF1xNSZ Series

and

PR36MF1xNSZ Series

Solid State Relays (SSR) are an integration of an

infrared emitting diode (IRED), a Phototriac Detector

and a main output Triac. These devices are ideally

suited for controlling high voltage AC loads with solid

state reliability while providing 4.0kV isolation

iso

(rms)) from input to output.

■

Agency approvals/Compliance

1. Recognized by UL508, file No. E94758 (as model No.

R26MF1/R36MF1)

2. Approved by CSA 22.2 No.14, file No. LR63705 (as

model No.

R26MF1/R36MF1)

3. Optionary available VDE approved

(∗)

(DIN EN 60747-5-

2), file No. 40008898 (only for

PR36MF1xNSZ Series

as model No.

R36MF1)

4. Package resin : UL flammability grade (94V-0)

(∗)

■

Features

1. Output current, I

(rms)≤0.6A

2. Non-zero crossing functionary

3. 8 pin DIP package (SMT gullwing also available)

4. High repetitive peak off-state voltage

DRM

: 600V,

PR36MF1xNSZ Series)

DRM

: 400V,

PR26MF1xNSZ Series)

5. I

ranks available (see Model Line-up in this

datasheet)

6. Superior noise immunity (dV/dt : MIN. 100V/µs)

7. Response time, t

: MAX. 100µs

8. Lead-free terminal components are also available

(see Model Line-up section in this datasheet)

9. High isolation voltage between input and output

iso

(rms) : 4.0kV)

DIN EN60747-5-2 : successor standard of DIN VDE0884.

Up to Date code "RD" (December 2003), approval of DIN

VDE0884.

From Date code "S1" (January 2004), approval of DIN

EN60747-5-2.

■

Applications

1. Isolated interface between high voltage AC devices

and lower voltage DC control circuitry.

2. Switching motors, fans, heaters, solenoids, and

valves.

3. Phase or power control in applications such as

lighting and temperature control equipment.

Notice The content of data sheet is subject to change without prior notice.

In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment using any SHARP

devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.

Sheet No.: D4-A00401EN

Date Mar. 31. 2004
