F-209-1
SEAF–20–05.0–S–10–2–A–K–TR
TM
EXTENDED LIFE PRODUCT
10 Year Mixed Flowing Gas (MFG)
Call Samtec for maximum cycles mated with SEAM
SEAF–30–05.0–S–08–2–A–K–TR
SEAF–30–06.5–S–08–2–A–K–TR
OPEN PIN FIELD ARRAY
SEAF SERIES
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?SEAF
Insulator Material:
Black LCP
Contact Material:
Copper Alloy
Operating Temp Range:
-55°C to +125°C
Plating:
Au over 50µ" (1,27µm) Ni
Contact Resistance:
5.5 mΩ
Working Voltage:
240 VAC
RoHS Compliant:
Yes
Mates with:
SEAM, SADL,
SEAC (Requires –LP)
Up to
500 Pins
5, 8 and 10 row footprint
compatible with SamArray
®
.
Samples recommended.
Lead-Free Solder
ChargeTerminations
(Tin/Lead also available)
CURRENT RATING
®
Processing:
Max Processing Temp:
230°C for 60 seconds, or
260°C for 20 seconds 3x
Lead-Free Solderable:
Yes
Low Insertion/
Extraction Forces
7mm Stack Height
Rated @ -3dB Insertion Loss
Single-Ended Signaling
9.5 GHz / 19 Gbps
Differential Pair Signaling
10.5 GHz / 21 Gbps
Performance data for other stack heights
available at www.samtec.com?SEAF
fina
l
i
nch.com
ry
dust ds
In
ar
tand
S
ols
otoc ted
Pr or
Supp
nel
Fibre Chan
Rapid I/O
®
s
PCI Expres
SATA
Infiniband
PISMO 2
VITA 47
VITA 57
AMBIENT
SEAM/SEAF
TEMP
2.3A
20°C
2A
40°C
1.75A
60°C
1.14A
95°C
30 ADJACENT
POSITIONS POWERED
SEAF
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
NO. OF
ROWS
2
A
OPTION
K
TR
–L
= 10µ"
(0,25µm)
Gold on
contact area,
Matte Tin on
solder tail
– 04
=Four
Rows
–15, – 20,
– 30, –40, –50
LEAD
STYLE
–05.0
–06.0
–06.5
A
(5,05)
.199
(6,05)
.238
(6,55)
.258
–2
= Lead-Free
Tin Alloy
95.5%
Sn/3.8%
Ag/0.7% Cu
Solder Charge
– LP
=Latch Post
(–LP required
for SEAC mate only)
– 05
=Five
Rows
–S
= 30µ"
(0,76µm)
Gold on
contact area,
Matte Tin on
solder tail
08
– 06
=Six
Rows
notes at
Download app ppnote
om/a
www.samtec.c mtec.com
@ sa
Contact SIG n protocols
o
for questions
MATED HEIGHTS*
SEAM
SEAF LEAD STYLE
LEAD
–06.5
STYLE –05.0 –06.0
7mm
8mm
8.5mm
8mm
9mm
9.5mm
8.5mm 9.5mm
10mm
11.5mm 12.5mm
13mm
12mm
13mm
13.5mm
14mm
15mm
15.5mm
16mm
17mm
17.5mm
*Processing conditions will affect
mated height.
– 08
=Eight
Rows
APPLICATION
SPECIFIC OPTION
–07.5 lead style for 30x4 available.
Call Samtec.
No. of positions x
(1,27) .050 + (5,82) .229
No. of
rows
x
(1,27)
.050
+
(0,53)
.021
(1,27) .050
01
(1,27)
.050
– 10
=Ten
Rows
DIFFERENTIAL
(1,27) .050
(1,27)
.050
–02.0
–03.0
–03.5
–06.5
–07.0
–09.0
–11.0
(15,49)
.610
(1,27)
.050
(1,78)
.070
A
(1,12) .044 DIA
No. of positions x
(1,27) .050 + (3,58) .141
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
(0,20)
.008
–LP
PAIR
ARRAY COUNT
125
50x10
100
50x8
100
40x10
PAIR
ARRAY COUNT
80
40x8
60
40x6
75
30x10
60
30x8
45
30x6
50
20x10
40
20x8
25
20x10
WWW.SAMTEC.COM
