REVISION D
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MINIMUM PUSHOUT FORCE: 4.45N[1.000lb.].
3. MAXIMUM ALLOWABLE BOW: 0.05 MM/MM [.002] AFTER ASSEMBLY.
4. POST HEIGHT VARIATION BETWEEN ANY TWO PINS: 0.13[.005] MAXIMUM.
5. FOR LOCKING CLIPS: 3.336 N[.75lb.] MIN RETENTION.
6. MEASURE AT BEND
7. MAX PIN ROTATION IN BODY TO BE 2°.
DESIGNED & DIMENSIONED
IN MILLIMETERS[INCHES]
TLMM-1XX-01-X-D-XX-XX
No. OF POSITIONS
-02 THRU -25
(PER ROW)
LEAD STYLE
PLATING SPECIFICATION
-L: LIGHT SELECTIVE (USE T-1S13-XX-L-2)
-F: FLASH GOLD SELECTIVE
(USE T-1S13-XX-F-2)
OPTION
-LC: LOCKING CLIP
(USE LC-05-TM FOR THROUGH HOLE STYLES, SEE FIG.1)
(USE LC-07-TM FOR -SM STYLE, SEE FIG. 3, SHT. 3)
NOT AVAILABLE FOR -RA STYLE
-TR: TAPE & REEL (FOR -SM OPTION ONLY)
-K: POLYIMIDE FILE PAD (USE K-500-300, SEE FIG. 4, SHT. 4)
(ONLY AVAILABLE ON -SM)
-XX: PIN No. TO BE OMITTED (POLARIZED OPTION)
BODY HEIGHT
-TH: THROUGH HOLE (SEE FIG. 1, SHT. 1)
-RA: RIGHT ANGLE (SEE FIG. 2, SHT. 2)
-SM: SURFACE MOUNT (SEE FIG. 3, SHT. 3)
ROW SPECIFICATION
-D: DOUBLE
DO NOT
SCALE FROM
THIS PRINT
(TLMM-110-01-X-D-TH-LC SHOWN)
FIG. 1
0.51 .020 REF
(No. OF POS. x 2.000[.0787]) + 7.369[.2901] REF
2.000 .0787
C
(TYP)
C
L
"A"
02
04
0.94 .037 REF
C
2.000 .0787
C
L
4.57 .180 REF
6.60 .260 REF
01
03
"A"
(No. OF POS. x 2.000[.0787]) + 5.591[.2201] REF
(No. OF POS. - 1) x 2.000[.0787]±0.13[.0051]
C
1.42 .056 REF
DETAIL 'B'
SCALE 6 : 1
FIRST POSITION
INDICATOR
CONTACT AREA
2.67 .105 REF
2 MAX SWAY
(TYP)
TLMM-XX-D-LC
6.99 .275 REF
3.30 .130 REF
2.29 .090 REF
1.91 .075
'B'
2 MAX SWAY
(TYP)
(No. OF POS. x 2.000[.0787]) + 6.480[.2551]±0.051[.0020]
(No. OF POS. - 1) x 2.000[.0787]±0.130[.0051]
C
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN MILLIMETERS.
TOLERANCES ARE:
DECIMALS
C
0.25 .010 REF
(TYP)
C
C
L
0.50 .020 SQ. REF
(TYP)
0.38 .015 REF
8.20 .323 REF
C
2 MAX TOE
(TYP)
4.27 .168
LC-05-TM
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
T-1S13-20-X-2
X.X: 0.3 [.01]
2
X.XX: 0.13 [.005]
X.XXX: 0.051 [.0020]
MATERIAL:
ANGLES
SECTION "A"-"A"
5.33 .210 REF
INSULATOR: ZYTEL HTNFR52G30NH, COLOR: BLACK
TERMINAL: PHOS BRONZE
DO NOT SCALE DRAWING
SHEET SCALE: 3:1
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
fromparent+e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
2MM SHROUDED TERMINAL STRIP
F:\DWG\MISC\MKTG\TLMM-1XX-01-X-D-XX-XX-MKT.SLDDRW
BY:
T. NEWTON 01/04/2007
TLMM-1XX-01-X-D-XX-XX
SHEET
1
OF
4
REVISION D
C
4.27 .168
4.27 .168
C
11.58 .456 REF
15.60 .614 REF
T-1S13-13-X-2
T-1S13-13-X-2
T-1S13-14-X-2
IN PROCESS 1
(FOR -RA ONLY)
IN PROCESS 2
(FOR -RA ONLY)
(TLMM-110-01-X-D-RA SHOWN)
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG.1)
90°
(TYP)
2 MAX SWAY
(TYP)
"C"
C
C
C
FIG. 2
C
(No. OF POS. -1) x 2.000[.0787]±0.130[.0051]
2.000±0.127 .0787±.0050
1.27 .050
2.000 .0787
(TYP)
2.05 .081 REF
02
04
T-1S13-14-X-2
01
03
"C"
C
4.27 .168
T-1S13-13-X-2
CONTACT AREA
SECTION "C"-"C
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
fromparent+e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 3:1
2MM SHROUDED TERMINAL STRIP
TLMM-1XX-01-X-D-XX-XX
SHEET
2
OF
4
F:\DWG\MISC\MKTG\TLMM-1XX-01-X-D-XX-XX-MKT.SLDDRW
BY:
T. NEWTON 01/04/2007
REVISION D
T-1S13-02-X-2
(TLMM-110-01-X-D-SM-LC SHOWN)
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG. 1
FIG. 3
C
3.63 .143
02
9.58 .377 REF
04
"E"
1.42 .056 REF
DETAIL 'D'
SCALE 6 : 1
IN PROCESS 1
(FOR -SM ONLY)
01
03
2.000 .0787
(TYP)
C
"E"
2 MAX SWAY
(TYP)
(No. OF POS. - 1) x 2.000[.0787]±0.130[.0051]
CONTACT AREA
C
T-1S13-02-X-2
1.90 .075
IN PROCESS 2
(FOR -SM ONLY)
C
2.67 .105
7.75 .305
REF
90°
(TYP)
'D'
0.10
C
8.26 .325
C
(SEE NOTE 6)
C
L
LC-07-TM
4.27 .168
C
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
T-1S13-02-X-2
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
fromparent+e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 3:1
2MM SHROUDED TERMINAL STRIP
SECTION "E"-"E"
F:\DWG\MISC\MKTG\TLMM-1XX-01-X-D-XX-XX-MKT.SLDDRW
BY:
T. NEWTON 01/04/2007
TLMM-1XX-01-X-D-XX-XX
SHEET
3
OF
4
REVISION D
7.501[.2953] .127[.0050]
(TLMM-110-01-X-D-SM-K SHOWN)
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG. 1)
8.38 .330
C
FIG. 4
"S"
(SEE NOTE)
NOTE: "R" = USED MEASURED DIMENSION (REF)
"S" = {("R" - 7.501[.2953])/2} 0.51[.0200]
ALL PARTS ARE LOADED WITH POSITIONS 1
TOWARDS ARROW
0.70 .028
"R"
(SEE NOTE)
PACKAGING
PT-1-24-01-103
PT-1-24-01-69
PT-1-24-01-70
NOTE: ALL POSITIONS ARE TO BE TUBED.
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
fromparent+e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 3:1
2MM SHROUDED TERMINAL STRIP
F:\DWG\MISC\MKTG\TLMM-1XX-01-X-D-XX-XX-MKT.SLDDRW
BY:
T. NEWTON 01/04/2007
TLMM-1XX-01-X-D-XX-XX
SHEET
4
OF
4
