LABORATORY
SM 700 Series
6 0 0 - 7 0 0 W A T T S P R O G R A M M A B L E D C S U P P LY
Features
•
•
•
•
•
•
•
Constant voltage and constant current operation
Parallel operation master/slave
EMC standard EN61204-3
Excellent response to load change
CE marked
Optional ethernet, RS232, IEEE 488 programming
Natural convectional cooling
Specifications
INPUT
Input voltage
Frequency
Inrush current
Insulation
90-132/185-265VAC
48Hz–62Hz
6.5A @ 230Vac, 30A @ 110Vac.
Input – Output: 3750V rms (8mm creepage)
Input – Case: 2500V rms
Output – Case: 600VDC
OPERATING
Efficiency
Switching frequency
Thermal protection
Programming
Programming speed
Master/Slave operation
See table
0%–100%
See table
0%–100%
0.03% voltage and current control with 10 turn
potentiometers.
SM1540-D: 0-17V, SM7020-D: 0-80V,
SM3004-D: 0-350V.
Yes
Yes
CV: 5x10
-5
per °C, CC: 1x10
-4
per °C.
0%–100% load see table.
Line ±10% – see table.
See table.
CV: 3x10
-4,
CC: 1x10
-3
SM1540: <40mΩ, SM7020: <60mΩ,
SM3004: < 700mΩ.
(50%–100% load step): 100µS; 150µS for SM
7020.
2V max. per lead compensation.
Storage temperature
Cooling
Metering
Indicators
MTBF
87%–89% .
100kHz
Yes
Analogue Programming of voltage and current by
0-5V.
See table
Parallel and series operation with equal current
and voltage sharing. In this way two or more SM-
units can together be used as one high power unit.
Voltage and current of the units is controlled by the
master (by potentiometers or by programming).
Series operation up to 600V
Digital meters standard
CV/CC mode, OVP triggered LEDs
500,000hrs
OUTPUT
Output voltage
Output voltage adjustment
Output current
Output current adjustment
Resolution
Overvoltage protection
Overload protection
Short circuit protection
Temperature coefficient
Load regulation
Line regulation
Ripple & Noise
Stability
Output impedance
(0-100kHz)
Recovery time
Remote sense
BATTERY CHARGING
The CV/CC regulated power supplies are suitable for battery charging.
Ask for the special datasheet “BATTERY CHARGING WITH SM-series POWER
SUPPLIES”. This datasheet contains information about protective measures
against accidental battery reversing.
ENVIRONMENTAL
Operating temperature
Humidity
-20°C to 50°C
95% RH max, non condensing, up to 40 °C.
75% RH max, non condensing, up to 50 °C.
-40°C to 85°C
Natural convection
STANDARDS AND APPROVALS
Safety standards
EMC standards
EMI standards
EN60950 / EN61010
EN61204-3, EN61000-6-2
EN61000-6-3 (EN55022B)
MECHANICAL
Mounting
Bench or 19" rack mounting
464
LABORATORY
SM 700 Series
6 0 0 - 7 0 0 W A T T S P R O G R A M M A B L E D C S U P P LY
Selection Table
MODEL
NUMBER
SM 1540D
SM 7020D
OUTPUT
VOLTAGE
(0V TO)
15V
35V
70V
OUTPUT
CURRENT
(0A TO)
40A
20A
10A
4A
2A
RIPPLE & NOISE
CV
CC
10mV pk-pk
15mV pk-pk
25mA pk-pk
15mA pk-pk
PROGRAMMING
SPEED
(0V TO V MAX.)
18mS
12mS(0-35V)
40mS(0-70V)
LOAD REG.
0%–100%
CV
CC
5mV
5mV
25mA
12mA
LINE REG.
200-264VAC
CV
CC
5mV
5mV
25mA
12mA
SM 3004D
150V
300V
50mV pk-pk
3mA pk-pk
14mS(0-150V)
60mS(0-300V)
20mV
3mA
20mV
3mA
OPTIONS
Screwdriver adjustment - option P001
Master / slave operation
Battery charging SM7020-D: P021, SM3004-D: P022.
Increased max. output voltage / current - option P069
Enforced secondary isolation 1000V - option P089
Power sink for 2 quadrant operation - option P140 / 141
External ISO AMP for isolated analog programming - ISO AMP Module
External ethernet power supply controller - option PSC ETH EXT
External RS232 power suply controller - option PSC 232 EXT
External IEEE488 power supply controller - PSC 488 EXT
Technical Illustrations
