New Product Announcement!
High Power Directional Coupler
50Ω
10dB
380 to 3600 MHz
Click
here for
data sheet
ZGDC10-362HP+
The Big Deal
• High Power Handling: 250W
• Low Insertion Loss: 0.11 dB*
• Rugged IP67 Weatherproof case
CASE STYLE: HT1398
Pricing:
$169.95
(QTY 1-9)
Product Overview
The Mini-Circuits ZGDC10-362HP+ broadband high power directional coupler offers excellent performance across a wide
range of popular frequency bands. Built using low loss suspended substrate construction, the ZGDC10-362HP+ can pass up
to 3A of DC current from input to output and handle up to 250W CW. The rugged sealed construction makes this coupler ideal
for use in field applications or remote monitoring sites; however, it is also ideal for high power lab testing.
Key Features
Feature
Excellent Insertion Loss , 0.11 dB Typ*
Advantages
With extremely low insertion loss, this coupler is ideal for critical high power applications.
Ultra High Return Loss, 30 dB Typ
Outstanding Return loss makes this coupler ideal for sensitive power measurement and other signal distribu-
tion applications.
Up to 250W CW power handling, combined with low insertion loss and excellent VSWR support operation in
high power applications such as transmitters, base stations and high power device characterization.
Covering 380-3600 MHz, the ZGDC10-362HP+ covers the most popular Cellular, PCS, DCS, WiMAX, and
LTE bands.
Typical 28 dB directivity and ±0.6 dB of Coupling flatness provides accurate signal sampling of forward or
reflected power.
Capable of passing 3A current, input to output; this coupler is suited for application using remote antenna
control or other remote motorized requirements.
With an Ingress Protection rating of IP67, the ZGDC10-362HP+ is designed to operate in harsh outdoor
applications.
High Power Handling, 250W
Wide bandwidth
Excellent Directivity and Coupling Flatness
Passes DC Current, 3A
IP67 Weatherproof Case
*Does not include coupling loss
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
TM
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
Page 1
