HI2-200/883 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> The signal circuit> HI2-200/883

HI2-200/883: DescriptionDUAL 1-CHANNEL, SGL POLE SGL THROW SWITCH, MBCY10, METAL CAN, TO-100, 10 PIN; CategoryAnalog mixed-signal IC The signal circuit; File Size249KB，11 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/

Download Datasheet Parametric View All

HI2-200/883 Overview

DUAL 1-CHANNEL, SGL POLE SGL THROW SWITCH, MBCY10, METAL CAN, TO-100, 10 PIN

HI2-200/883 Parametric

Parameter Name	Attribute value
package instruction	,
Reach Compliance Code	unknown
Analog Integrated Circuits - Other Types	SPST
JESD-30 code	O-MBCY-W10
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of channels	1
Number of functions	2
Number of terminals	10
Nominal off-state isolation	55 dB
Maximum on-state resistance (Ron)	70 Ω
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	METAL
Package shape	ROUND
Package form	CYLINDRICAL
Certification status	Not Qualified
Filter level	MIL-STD-883
Nominal supply voltage (Vsup)	15 V
surface mount	NO
Maximum disconnect time	500 ns
Maximum connection time	500 ns
technology	CMOS
Temperature level	MILITARY
Terminal form	WIRE
Terminal location	BOTTOM
Base Number Matches	1

Preview

Download Datasheet

View All

ODUC MENT

TE P R

OBSO DED REPLA enter at

MMEN al Support C om/tsc

RE CO

hni c

Data

Sheet

rsil.c

our Te or www.inte

contac TERSIL

1-888-

HI-200/883

September 2004

FN6059.1

Dual SPST CMOS Analog Switch

The HI-200/883 is a monolithic device comprising two

independently selectable SPST switchers which feature fast

switching speeds (240ns typical) combined with low power

dissipation (15mW typical @ +25°C)

Each switch provides low “ON” resistance operation for input

signal voltages up to the supply rails and for signal currents

up to 25mA continuous. Rugged DI construction eliminates

latch-up and substrate SCR failure modes.

All devices provide break-before-make switching and are

TTL and CMOS compatible for maximum application

versatility. HI-200/883 is an ideal component for use in high

frequency analog switching. Typical applications include

signal path switching, sample and hold circuits, digital filters,

and op amp gain switching networks.

HI-200/883 is available in a 14 pin Ceramic DIP package

and a 10 pin Metal Can (TO-100) package.

Features

• This Circuit is Processed in Accordance to MIL-STD-883

and is Fully Conformant Under the Provisions of

Paragraph 1.2.1.

• Low “On” Release . . . . . . . . . . . . . . . . . . . . . . .100Ω Max

• Wide Analog Signal Range . . . . . . . . . . . . . . . . . . . .±15V

• TTL/CMOS Compatible . . . . . . . . . . . . . . 2.4V (Logic “1”)

• Turn-On Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 500ns

• Analog Current Range (Continuous) . . . . . . . . . . . . 25mA

• No Latch-Up

• Replaces DG200

Applications

• High Frequency Analog Switching

• Sample and Hold Circuits

• Digital Filters

Functional Diagram

V+

REF

INPUT

SOURCE

LOGIC

INPUT

GATE

REFERENCE,

LEVEL SHIFTER,

AND DRIVER

SWITCH

CELL

GATE

• Op Amp Gain Switching Networks

Pinouts

HI1-200/883 (CERDIP)

TOP VIEW

NC 2

14 A

13 NC

12 V+

11 NC

10 IN1

9 OUT1

8 V

REF

DRAIN

OUTPUT

GND 3

NC 4

IN2 5

OUT2 6

V- 7

V-

HI2-200/883 (METAL CAN)

TOP VIEW

V+

IN1

OUT2

V-

OUT1

REF

GND 3

IN2

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

1-888-INTERSIL or 321-724-7143

Intersil (and design) is a registered trademark of Intersil Americas Inc.

All other trademarks mentioned are the property of their respective owners.
